Pivot Door
Instruction Manual
V2INP
Be aware toughened glass can shatter if not handled correctly. It should not
be subjected to any sharp impact and it is essential to protect the glass by
resting it on a soft protective surface during installation such as cardboard
or carpeting. It is recommended to wear PPE at all times during installation.
PRE-INSTALLATION CHECKS
1.
Check you have the correct product. Please look at the labels on the side of the product packaging.
2.
Check all the product components are in the box and the fixing kits.
3.
Unpack your product and handle it with care.
4.
Please check the product for defects or damage, once the installation has commenced we cannot accept responsibility for any defects or damage.
5.
Please take time to read these instructions prior to installing your product.
6.
Before you commence any drilling check there are no hidden electrical cables and/or water pipes.
7.
No attempt should be made to re-work the toughened safety glass.
8.
The installation of the product should be performed by two persons.
9.
It is strongly recommended that the walls the product is going to be installed on are vertical.
10. It is strongly recommended the product is fitted on a tiled surface or similar waterproof surface.
11. It is strongly recommended the walls are tiled and grouted before the product is installed.
12. If the walls and/or the tray are not level you will not achieve maximum adjustment of the product.
13. Pictures used are for illustration purposes only, product designs may alter slightly as a result of continuing product development.
14. We do not stipulate where the European Standard Kite Mark should be positioned on the glass when being factory assembled.
15. Please note that some natural misting may occur when you remove this product from its packaging, due to the addition of the glass protection pre-
coating. If this does occur this can easily be removed with a soft, dry cloth.
Component Check List: Supplied
Description
Wall Profiles
Pivot Door
Top Caps
Pivot Side Vertical Seal
Door Magnet
Frame Magnet
Bottom Seal (Long)
Bottom Seal (Short)
Handle
Fixing Kit Components
Description
Wall Plugs
40mm Screws
9mm Screws
Screw Bases
Screw Cover Caps
Top Cap (Left Hand)
Top Cap (Right Hand)
2.5mm Drill Bit
IMPORTANT INFORMATION
Quantity
Description
2
4.5mm drill bit
1
Electric / Battery Drill
2
6mm Masonry Drill Bit
1
Silicone Sealant Gun
1
Bathroom Sealant
1
Screwdriver
1
Spirit Level
1
Tape Measure
1
Pencil
Wall Plugs (for Plasterboard if necessary)
Quantity
6
6
6
12
to validate the Guarantee will mean only the 1
12
1
1
1
Equipment Check List: Not Supplied
CONSUMER GUARANTEE
Please make sure the purchaser/end user
completes and returns the guarantee card
which is enclosed with this product. Failure
Year Statutory Guarantee will apply.
Ref: HV2INP REV3 - JAN 2020
Advertisement
Table of Contents
Related Manuals for Instinct V2INP
Summary of Contents for Instinct V2INP
- Page 1 Pivot Door Instruction Manual V2INP IMPORTANT INFORMATION Be aware toughened glass can shatter if not handled correctly. It should not be subjected to any sharp impact and it is essential to protect the glass by resting it on a soft protective surface during installation such as cardboard or carpeting.
-
Page 2: Step 1 - Pre-Installation Checks
Step 1 - Pre-Installation Checks 1. Check the tray is level on all sides (the bubble on the spirit level must be in the centre of the 2 lines). 2. Stand in the tray and check that there is no adverse movement (correct if necessary). 3. - Page 3 Step 2 - Wall Profile Positioning ① Drill this face ② 10mm ② ③ Screw Base ④ ④ ⑤ ① 1. On both Wall Profiles drill three 4.5mm holes through the lip. Place them 7mm in from the edge and approximately 100mm from each end and the other positioned in the centre.
- Page 4 Step 3 - Installing the Door, Handle and Fixing the 2nd Wall Profile NOTE: The stages below will require 2 people to carry them out. On stage 6 when lifting the Door Assembly to seal the inside of the 2nd wall profile place a wooden chock or similar between the enclosure and the top of the tray to prevent it from falling and causing injury (carefully remove when done).
-
Page 5: Step 4 - Fitting The Enclosure
Step 4 - Fitting the Enclosure NOTE: This part of the installation requires 2 people. ③ 6mm Minimum ① ④ 50mm ⑤ Cover ⑥ 9mm Screw Screw Base ⑦ 1. Make sure the Frame is positioned equally between both Wall Profiles with a minimum of 6mm for drilling. 2. - Page 6 Step 5 - Sealing ① ② Snap off ③ here 1. Seal the Wall Profile vertically, both internally and externally where they meet the tiles. 2. Seal the base of the enclosure to the top of the tray from wall to wall on the outside only. •...
-
Page 7: Spare Parts
Spare Parts If you need to replace any damaged parts please see illustration below for parts list then call Customer Relations on 01325 328033 Part No. Description Q’ty Part No. Description Q’ty Part No. Description Q’ty Wall Profile Bottom Seal (Short) Vertical Frame (Hinge Side) Horizontal Frame (Bottom) Top Cap (Left Hand) -
Page 8: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Problem Solution Leaking 1. Check the tray is sealed correctly along the tiled walls prior to installation. 2. Check that the inside gap between the Tray and Wall profiles has been sealed correctly. 3. Check the base of the enclosure is sealed on the outside only. 4.
