Inward Folding Bath Screen
Instruction Manual
IND9CS
Be aware toughened glass can shatter if not handled correctly. It should not
be subjected to any sharp impact and it is essential to protect the glass by
resting it on a soft protective surface during installation such as cardboard
or carpeting. It is recommended to wear PPE at all times during installation.
PRE-INSTALLATION CHECKS
1.
Check you have the correct product. Please look at the labels on the side of the product packaging.
2.
Check all the product components are in the box and the fixing kits.
3.
Unpack your product and handle it with care.
4.
Please check the product for defects or damage. once the installation has commenced we cannot accept responsibility for any defects or damage.
5.
Please take time to read these instructions prior to installing your product.
6.
Before you commence any drilling check there are no hidden electrical cables and/or water cables.
7.
No attempt should be made to re-work the toughened safety glass.
8.
The installation of the product should be performed by two persons.
9.
It is strongly recommended that the walls the product is going to be installed on are vertical.
10. It is strongly recommended the product is fitted on a tiled surface or similar waterproof surface.
11. It is strongly recommended the walls are tiled and grouted before the product is installed.
12. If the walls and/or the tray are not level you will not achieve maximum adjustment of the product.
13. Pictures used are for illustration purposes only, product designs may alter slightly as a result of continuing product development.
14. We do not stipulate where the European Standard Kite Mark should be positioned on the glass when being factory assembled.
15. Please note that some natural misting may occur when you remove this product from its packaging, due to the addition of the glass protection pre-
coating. If this does occur this can easily be removed with a soft, dry cloth.
Component Check List: Supplied
Description
Wall Profile
Fixed Panel
Moving Panel
Deflector
Brace Bar Assembly
Fixing Kit Components
Description
2.5mm Drill Bit
9mm Screws
40mm Screws
Screw Bases
Cover Caps
Top Cap (Left Hand)
Top Cap (Right Hand)
Wall Plugs (for brick and block only)
Branding Badge (where applicable)
4mm Allen Key
IMPORTANT INFORMATION
Quantity
Description
1
Electric / Battery Drill
1
6mm Masonry Drill Bit
1
Bathroom Sealant Gun
1
Bathroom Sealant
1
Screwdriver
Spirit Level
Tape Measure
Pencil
Wall Plugs (not supplied)
Stanley Knife / Snips
Quantity
1
3
3
3
3
1
1
3
1
1
Equipment Check List: Not Supplied
CONSUMER GUARANTEE
Please make sure the purchaser/end user
completes and returns the guarantee card
which is enclosed with this product. Failure
to validate the Guarantee will mean only the 1
Year Statutory Guarantee will apply.
Ref: IND9CS - Rev 3 September 2019
Advertisement
Related Manuals for Instinct IND9CS
Summary of Contents for Instinct IND9CS
- Page 1 Top Cap (Left Hand) to validate the Guarantee will mean only the 1 Top Cap (Right Hand) Year Statutory Guarantee will apply. Wall Plugs (for brick and block only) Branding Badge (where applicable) Ref: IND9CS - Rev 3 September 2019 4mm Allen Key...
- Page 2 IMPORTANT PRE-INSTALLATION CHECKS 1. Ensure the bath is completely level. 2. Check for any movement in the bath by standing in it. 3. The walls should be tiled and grouted up to the bath. 4. Fill the bath with water and check the plumbing for leaks. 5.
- Page 3 Step 1 - Wall Profile Position NOTE: Two people will be required to do the following procedures. ① Align to the top inside edge ① Pivot Assembly Inside edge of bath ② Lightly mark position using a pencil 1. Dry fit the Bath Screen on top of the Bath. Position the Fixed Panel so that the curved face of the bottom Pivot Assembly falls in line with the inside of the Bath.
- Page 4 Step 2 - Fixing Wall Profile ① Pencil Mark ④ ⑤ ⑦ ⑥ 1. Position the inside edge of the Wall Profile onto the pencil mark you have just made. 2. Make sure the Wall Profile is vertical using a spirit level. 3.
- Page 5 Step 3 - Fitting the Fixed Panel ① ② ④ ⑤ Cover 9mm Screw Base 10mm Minimum 1. Before fitting the Fixed Panel, please ensure that the Bottom Pivot Assembly is fully tightened using the 4mm Allen key. 2. Slide the Fixed Panel fully over the Wall Profile, the Fixed Panel must overlap by at least 10mm. 3.
- Page 6 Step 4 - Fitting the Moveable Panel 1. Using the 4mm Allen key (supplied) remove the countersink screw and Top Pivot Assembly from the Fixed Panel. 2. Ensure that the Moveable Panel is the correct way before fitting, the “P” shaped extrusion should be positioned so that the Flat Face is to the inside of the showering area and the Round Face to the outside.
- Page 7 Step 5 - Fitting the Bracing ② ③ ④ ⑦ ⑤ ⑤ ⑧ 1. Place the Brace Bar over the top of the glass on the Fixed Panel; ensure the Brace Bar is completely level and in line with the panel. 2.
- Page 8 Step 6 - Sealing ① ③ Top Cap Grooves ③ Snap off here ④ Deflector 1. Seal both sides of the Wall Profile inside and outside only where it meets the tiles. 2. Fully seal the base of the Fixed Panel to the Bath top from the wall to the end of the Pivot Assembly. •...
-
Page 9: Spare Parts
Spare Parts If you need to replace any damaged parts please see illustration below for parts list then call Customer Relations on 01325 328033 Part No. Description Q’ty Part No. Description Q’ty Part No. Description Q’ty Wall Profile Tube Cap (Left Hand) Top Cap (Left Hand) Deflector Fixed Panel Assembly... -
Page 10: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Problem Solution 1. Check the internal gap between the Bath and the Wall Profile has been sealed correctly. Leaking 2. Ensure the Bath is fully sealed along the tiled walls prior to installation. 3. If the Fixed Panel is sealed on the inside along the Bath top, this will cause leakage - sealant must be removed.
