Air conditioner WDH-9000K
Dear customer,
You have chosen a high-quality product. Here are some tips that will help you enjoy this product:
After transport:
Because the appliance runs on refrigerant, improper transport can sometimes occur despite careful labeling on the packaging.
Therefore, we ask that you leave it upright for at least 4 hours before using it for the first time so that the refrigerant in the
appliance can stabilize again.
In case of problems:
We hope the device meets your expectations! If, despite the utmost care, there should be any grounds for complaint, please
contact us briefly, as we value your satisfaction and would like to clear up any misunderstandings.
Important notes:
It is essential to read the following instructions before use to avoid injury or damage and to get the best results with the device.
Keep these operating instructions in a safe place. If you give the appliance to another person, be sure to hand over these
operating instructions as well.
In the event of damage caused by failure to follow the instructions in this operating manual, the warranty shall be void. The
manufacturer/importer shall not be liable for damage caused by failure to follow the operating instructions, negligent use, or
use not in accordance with the requirements of these operating instructions.
(Read and keep these instructions !)
Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany
www.AKTOBIS.de
Email: Info@Aktobis.de

Advertisement

loading
Need help?

Need help?

Do you have a question about the WDH-9000K and is the answer not in the manual?

Questions and answers

Summary of Contents for Aktobis AG WDH-9000K

  • Page 1 (Read and keep these instructions !) Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 2 The appliance is filled with the flammable refrigerant R290, so the instructions in these operating instructions must be strictly adhered to and read in full. (Fig. 5) ! Do not carry out any repairs to the device yourself! (Fig. 5) ! Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 3 Note: After each mode is turned on, the appliance fan runs for 30 seconds. The appliance then runs according to the function of the desired mode. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 4 Do not personally make repairs or modifications to the device ! Maintenance and repair work requiring the assistance of other qualified persons must be carried out under the supervision of specialists in the use of flammable refrigerants. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 5 Piping or cooling components are installed in locations where a hazard from other substances that can corrode refrigerant-containing components is unlikely, unless the components are made of corrosion-resistant materials due to their substance or are protected from corrosion adequately. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 6 (through gate valves) to a part of the system away from the leak. Next, oxygen-free nitrogen (OFN) should be used to flush the system before and during brazing work. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 7 All shut-off valves in the system should be locked. The collected refrigerant should not be fed into another refrigeration system unless it has been cleaned and checked. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de...
  • Page 8 Ensure that the workshop area is sufficient for refrigerant charge or that the ventilation line has been properly installed. Connect the lines and perform a leak test before filling with coolant. Check safety devices before commissioning. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 9 Attention is drawn to the fact that additional transport regulations may exist for systems with flammable gases. The maximum number of system components or system configuration that can be transported together are determined by the applicable transportation regulations. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 10 Water inlet and screw Water discharge and screw Cable storage Water inlet/outlet pipe Exhaust opening 10. Plug 11. Exhaust pipe For respective water connections, please refer to the attached sheet ! Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 11 18. Water drainage function 8. Cooling mode 19. Low/medium/high ventilation speed 9. Powerful cooling mode 20. Automatic ventilation speed 10. Dehumidification mode 21. Swivel function 11. Heating mode 22. Temperature display Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 12 When the water level reaches the operating level, the water inlet valve automatically closes to cut off the water supply. Remove the water inlet/outlet tube and tighten the water inlet screw again. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de...
  • Page 13 4. Dehumidification Press the mode button to select the dehumidification mode. Press the rotation button to turn the rotation function on/off. Note: During dehumidification, the unit displays the room temperature. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 14 Press and hold the "+" and "-" buttons at the same time for 3 seconds to turn off child protection or directly disconnect the device. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 15 Now you can operate the device through the app interface. Tap the buttons to set up the device. Note: The device is compatible with Alexa, Google Home and Smartlife. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 16 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 17 Note: The "No fan" and "Very strong fan" options in the fan speed selection list are determined by the application's default setting. They are not valid for this device. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 18 Note: There is no preset button in the app. Users can set start and shutdown times for all modes, including cold storage and hot storage, by adding programs to the timer function. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de...
  • Page 19 For example, the valid temperature range for heating mode is 16°C to 32°C. However, the list of set temperatures shows -9°C to 32°C in the app. Remember to set a temperature between 16°C and 32°C when selecting the heating mode. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de...
  • Page 20 Check if there is water in the water tank or if the amount of water meets the requirements. A voice message is played when the device starts. Follow the prompt. Check that the power cord is in good condition. Do not use it if it is damaged. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 21 Compressor does not work Compressor protection (delay on relay Wait more than 3 minutes and turn on activation) is activated. the appliance after the temperature has dropped. Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 22 Net dimensions (H/W/D): 92 x 33 x 49.5 mm Max. Transmission power: 15.3 dBm Frequency range: 2412-2472 MHz Frequency band: 2.4 GHz (WLAN) with: < 20 dBm power of transmission Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
  • Page 23 They will arrange for recycling of the appliance. We hope that the use of this device will be enjoyable Keep these operating instructions in a safe place ! Aktobis AG, Borsigstr. 20, D-63110 Rodgau / Germany www.AKTOBIS.de Email: Info@Aktobis.de...
