HESCH HE 5413 Operating Instructions Manual

3-channel differential pressure transmitter
Hide thumbs Also See for HE 5413:

Advertisement

Quick Links

HE 5413
3-channel differential pressure transmitter
Operating instructions
(Translation of Original German version)
#340435 | Version 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HE 5413 and is the answer not in the manual?

Questions and answers

Summary of Contents for HESCH HE 5413

  • Page 1 HE 5413 3-channel differential pressure transmitter Operating instructions (Translation of Original German version) #340435 | Version 1.2...
  • Page 2 Editor: AXXERON HESCH electronics GmbH, documentation department Copyrights © Copyright 2024 AXXERON HESCH electronics GmbH. All rights reserved. The content including pictures and the design of these operating instructions are subject to copyright protection and other laws for the protection of intellectual property. These operating instructions may only be distributed as a complete document and only with reference to the source.
  • Page 3: Table Of Contents

    SSEMBLY OF MEASURING HOSE TO PRESSURE CONNECTION INDICATION ELEMENTS .......................... 22 PARAMETRISATION WITH SERVICE PC ....................23 PC ........................23 ONNECTING WITH SERVICE ............................. 24 ARAMETER TABLE MAINTENANCE AND SERVICE ......................... 29 HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 4: Legal Provisions

    Legal Provisions Manufacturer AXXERON HESCH electronics GmbH, Boschstraße 8, 31535 NEUSTADT, GERMANY Intended use  The 3-channel differential pressure transmitter is used for measuring up to 3 differential pressures and is mainly applied in the dust extraction and ventilation industry.
  • Page 5: Safety Information

    Indicates a potentially hazardous medium risk situation which, if not avoided, can result in death or serious injury. CAUTION! Indicates a hazardous low risk situation, which, if not avoided, could result in minor or moderate injury. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 6: Safety In The Individual Operating Phases

    22 (applies to all device versions). Before opening the device, you must ensure that there is no explosive atmosphere. Before closing the device, make sure that the inside of the device is free of dust. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 7: Special Regulations

    (see chapter 2.4 Device identification and name plates). Note! Close unused cable glands with locking bolts and housing bores with blanking plugs. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 8: Device Identification And Name Plates

    Name plates (left) and channel labelling (right) (exemplary) Note! The name plate of your device and the labelling of the measuring channels are located right next to each other on the top side of the device. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 9: Technical Data

    Optional: 5-pole, only for 24 V DC devices without Electrical connection via M12 connector galvanic separation plug Abbreviation for American Wire Gauge Abbreviation for Kilo Circular Mils HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 10 ≤ 0.1 % / 10 K Temperature drift Voltage output: 0…10 V Effective dynamic range Load >= 1 kΩ Output load Linearity < 1 % Precision < 1 % ≤ 0.1 % / 10 K Temperature drift HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 11 The burst pressure is defined as the maximum pressure, which can affect a pressure connection relative to the other connection (or if just one pressure connection is connected), without causing leakages in the sensor. Abbreviation for Full Scale Output HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 12: Mounting

    Dimensions Figure 2 Dimensions of HE 5413 with M12 connector plug (24 V DC) Dimensions of HE 5413 with cable glands (100…240 V AC, 24 V DC) Figure 3 HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 13: Opening The Device

    Open the housing lid to the left up to an angle of 105° (see step 3 in Figure 4). Optionally, the housing lid can in addition be closed with 4 screws in order to protect it from unauthorised access. For further information, please contact the service of AXXERON HESCH electronics GmbH (see chapter 9 Maintenance and Service).
  • Page 14: Mounting The Device

    Housing rear with bore holes Note! Alternatively the wall mounting can be done with wall brackets. For further information, please contact the service of AXXERON HESCH electronics GmbH (see chapter 9 Maintenance and Service). HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 15: Device Description

    Device Description HE 5413 is a differential pressure transmitter, which can measure up to three differential pressures. Up to 3 differential pressure modules are mounted onto the circuit board, in order to be able to record the differential pressures (see Figure 6).
  • Page 16: Overview Of Device Versions

    Before closing the device, make sure that the inside of the device is free of dust. Note! The advantage of devices with M12 connector plug is that they do not need to be opened for electrical commissioning. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 17 HE 5413 with cable glands: Version with 100…240 V AC: Version with 24 V DC: HE 5413 with M12 connector plug (only with 24 V DC and without galvanic separation): Figure 8 Overview of device versions HE 5413 Operating Instructions...
  • Page 18: Electrical Commissioning

    Before commissioning, please observe the information on the name plate! Note! Please connect the cables properly to the cable glands. Note! The given temperature limitations for device application, must be observed before and during operation. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 19: Connection Of He 5413 With Cable Glands

    Connection of HE 5413 with cable glands Figure 9 Electrical connection via cable glands M20 and M12 HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 20: Connection He 5413 With M12 Connector Plug

    Connection HE 5413 with M12 connector plug Note! The channels 1, 2 and 3 are not galvanically separated from each other in devices with M12 connector plug. M12 connector plug, 5-pin, A-coded Figure 10 Electrical connection via M12 connector plug HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 21: Assembly Of Measuring Hose To Pressure Connection

    Hose connection Insert hose with 6 mm outer diameter into the connection. Hose disconnection 1. Press the blue retaining ring to open the lock. 2. Pull the hose out of the connection. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 22: Indication Elements

    The LED is off, when the device is not working or when there is no valid firmware available. LED error Lights up green permanently, when an error occurred. On dp modules: LED status Lights up yellow permanently, when the dp module is active. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 23: Parametrisation With Service Pc

    Parametrisation with service PC For parametrisation with a service PC, the software EasyTool Controls 4.0 is required. The also required USB-TTL adapter is available at AXXERON HESCH electronics GmbH (article number: #61000011). With this programme you can save a configuration or restore a saved configuration.
  • Page 24: Parameter Table

    “Characteristic line” is set to table, the characteristic line can be defined with the parameters “Base Output Signal 1”, “Base Input Signal 1” and “Base Output Signal 2”, “Base Input Signal 2”. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 25 0…100 Base output signal 2 100.00 Sensor min…Sensor Base input signal 2 5.00 mbar Anzahl Stützstellen sowie darunter aufgeführte Stützpunkte erscheinen in EasyTool Controls, wenn der Parameter Kennlinie auf Tabelle eingestellt ist. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 26 Input Indication / output signal Figure 15 Example for damping of a fluctuating signal Damping ×5 Indication / output signal Input Figure 16 Example for step response HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 27 10.00 from max. Min. = Indication value start Max. = Indication value end Creep flow suppression and creep flow threshold appear in EasyTool Controls, when the parameter Characteristic line is set to square-rooted. HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 28 None Step (threshold = 10) Creep flow suppression ‘ step’ Figure 17 None linear (threshold = 15) Figure 18 Creep flow suppression `linear HE 5413 Operating Instructions #340430 | Version 1.2...
  • Page 29: Maintenance And Service

    Dispatch metals and plastics for recycling. Electrical and electronic components must be collected separately and disposed of properly. Dispose of equipped printed circuit boards properly. Service AXXERON HESCH electronics GmbH Boschstraße 8 31535 NEUSTADT, GERMANY Phone: +49 5032 9535-0 Web: www.hesch-automation.com Email: info@hesch.de HE 5413 Operating Instructions #340430 | Version 1.2...
