Model #
1333AUF
McKenzie Cal-King
Storage Bed
Assembly Instructions
Congratulations!
This fine piece of furniture will make a gorgeous
addition to your home. For the best results, read the
Assembly Instructions and Finishing Hints before
you begin your project.
CALL US FIRST!
Service Policy: We will replace any part that is
defective, missing or damaged during assembly.
Please contact Whittier Wood Products customer
service department directly by phone, fax, mail or
email for a replacement part.
Hours: Our friendly customer service staff can be
reached Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific
Time). You may leave a message 24 hours a day,
seven days a week.
800-653-3336
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
Do not return this item to the store.
To Order: Provide the furniture model number (upper
left corner of this page), the part letter, production
code, quantity needed, reason for replacement, your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one
or two business days from the time we receive your
request. Please allow five to ten business days for delivery.
• Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
Production Code:
VN
IMPORTANT NOTES:
For normal household use only. Not recommended
for commercial use.
Remove items before you move this unit.
Before you load or move this item, check to make
sure all screws and supports are tight.
Do not overload the drawers in this unit.
Before you begin your project, completely read the
Assembly Instructions and Finishing Hints.
Store this item: 1- in its box; 2- in a dry place; 3- in
temperatures that range from 40° F to 90° F (not on
a cold and possibly damp cement floor).
Periodically inspect your furniture for any loose
glue joints, screws or any other problem that might
affect the stability of your furniture. Tighten or
repair as needed.
This assembly requires two people.
.
07/10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whittier Wood Furniture McKenzie 1333AUF
Summary of Contents for Whittier Wood Furniture McKenzie 1333AUF
- Page 1 Model # 1333AUF McKenzie Cal-King Storage Bed Assembly Instructions IMPORTANT NOTES: For normal household use only. Not recommended for commercial use. Remove items before you move this unit. Before you load or move this item, check to make sure all screws and supports are tight. Do not overload the drawers in this unit.
- Page 2 1333AUF McKenzie Cal-King Storage Bed — Parts List Please identify the parts and check that quantities received match what is on this list. If you need to replace a part, refer to the following letter and item name. 1336AUF Headboard/Footboard Kit (x1) U —...
- Page 3 1333AUF McKenzie Cal-King Storage Bed Assembly Instructions This assembly requires two people Tools Required: Phillips screwdriver, 7/16" wrench and tape measure Shipping Straps Fig. 1 Fig. 1a Remove the Trestles (C and D), Long Center Deckboard (R), Short Center Deckboard (S) and Foot Assemblies (U) from the back of the Headboard (A) and Footboard (B) as seen in Figure 1 and place them off to the side.
- Page 4 Fig. 3a Fig. 3 Drawer Release Lever Remove the Drawers (J) from the Pedestal Kits (I). To remove the drawers, pull up on the left side of the Drawer Release Lever while pushing down on the right Drawer Release Lever. See Figure 3a.
- Page 5 Fig. 5 5. Rotate the Pedestal Assembly upside down so the plywood deckboards are on the floor. G x 16 H x 16 Fig. 6a Fig. 6 NOTE: Do not tighten the bolts with a wrench until the final assembly in step 10 is completed.
- Page 6 Fig. 7a T x 6 Fig. 7 On each inner Pair of Trestles (C & D), place a Foot Assembly (U) between the two middle trestles as shown in Figure 7. Attach with three #8 x 2" Black Screws (T), making sure the screws penetrate both the Trestle and Foot.
- Page 7 Fig. 9a Fig. 9 Attach the Footboard (B) to the Pedestal Assembly as in Figure 9. Align the brackets as shown in Figure 9a and slide the Pedestal Assembly down on to the Footboard (B). Fig. 10 Attach the Headboard (A) to the Pedestal Assembly as in the previous step. NOTE: Now use a wrench and tighten all of the bolts on the trestles.
- Page 8 Fig. 12 To make sure the bed is square, measure the distance between opposing corners. If one of the measurements is larger, tap on a footboard leg until the measurement is equal. See Figure 12. E x 24 Fig. 13 Place the Deckboards (P) as shown in Figure 13 and secure with #8 x 1-1/4"...
- Page 9 E x 12 Fig. 14a Place three additional #8 x 1-1/4" Black Screws (E) along the seam between the Deckboards (R) and (S). See Figure 14a. Fig. 14 Place the Long Center Deckboard (R) and Short Center Deckboard (S) as shown in Figure 14 and secure with #8 x 1-1/4"...
- Page 10 Finishing Hints Choosing the Finish: Rubber Tack cloth #220 & #320 1. Choose a finish that will meet your expectations for gloves sandpaper Drop cloth the product you are finishing. Are you matching Rags Mineral spirits Paint brushes existing furniture or do you want a “natural” finish? Paper towels (bristle and Masking Tape...
