  • Page 1 Handheld Professional Thermal Camera Product Manual...

  • Page 2: Table Of Contents

    4.1. Device Description ....................10 4.2. Functions and Features .....................14 4.3. Operation Guide .......................15 5. Specification Parameters ....................32 6. Application Field ......................34 7. FAQs ..........................36 8. Warranty Service ......................37 Appendix A Ordering Information ..........错误!未定义书签。 Appendix B Emissivity Table of Common Objects .............37 www.dyt-ir.com...

  • Page 3: Product Introduction

    1. Product Introduction 1.1. Product Description DYT HandHeld Professional Thermal Camera DP-38/DP-64 is a new generation of handheld thermal imaging product integrating visible light and infrared light, with built-in high sensitivity infrared detector and high resolution visual camera, which can sense the ambient temperature changes quickly and accurately measure the temperature of high temperature targets in the environment.

  • Page 4: Product Appearance

    1.2. Product Appearance DYT Handheld Professional Thermal Camera adopts 4.3-inch high-light LCD touch screen, front fill light hole, laser hole, visible lens hole, infrared lens hole, tripod fulcrum, trigger, battery; Rear on-off button, direction keyboard, baffle zero calibration button, laser button, return button, lens cover, charging indicator hole, speaker hole, microphone hole, and LCD screen.
  • Page 5 Figure 1.2 Product Size Diagram (Unit: mm) www.dyt-ir.com...

  • Page 6: Configuration List

    Handheld thermal camera Including 1 battery UGREEN USB 3.0 dual card Card Reader with dual read TF card Qualification Certificate Warranty card UGREEN qc 3.0 charger Power adapter +USB 18W quick charge with 1 cable meter Type-C data cable www.dyt-ir.com...
  • Page 7 Battery holder 1 battery + 1 battery base Charging base Wrist strap 10.2 inch, inner box size Packing box 390*270*155mm EVA Inner Village EVA lining www.dyt-ir.com...

  • Page 8: Button & Interface

    3.1. Front Buttons DYT Handheld Professional Thermal Camera contains the front fill light hole, laser hole, visual camera lens hole, infrared lens hole, tripod fulcrum, trigger, battery and other key/display holes. The front structure of the device is shown in Figure 3.1.

  • Page 9: Rear Buttons

    Used to power the thermal camera 3.2. Rear Buttons The Rear of DYT Handheld Professional Thermal Camera contains switch button, direction keyboard, baffle zero setting button, laser button, back button, lens cover, charging indicator hole, speaker hole, microphone hole, LCD screen and other buttons/display holes.
  • Page 10 To control the movement and confirmation of the selected position on the Directional Keys interface Baffle Zeroing For zeroing of infrared lens baffle of thermal camera Laser For laser indication and ranging Return User thermal camera interface returns to upper level Lens Cover To protect lens and prevent lens damage www.dyt-ir.com...

  • Page 11: Peripheral Interface

    4.3 "LCD screen, excellent imaging and touch 3.3. Peripheral Interface DYT Hand-Held Professional Thermal Camera has three external ports: HDMI, SD card and USB. Figure 3.3 shows the positions of peripheral interfaces. Figure 3.3 Peripheral Interfaces Table 3.3 shows the corresponding names and uses of peripheral interfaces.

  • Page 12: Basic Operations

    ⚠ Note: charging base equipped with charging indicator light, it can be finished according to the color of the charge indicator to determine whether it charged. (2) USB cable  Unfractionated battery, connect the USB cable with infrared thermal camera on the www.dyt-ir.com...
  • Page 13 3s to shut down the device. (4) Wrist strap installation  Wrist band installation location, as shown in the figure will respectively installed on both sides of wrist strap on this location (as shown in figure 4.2). Figure 4.2 Wrist strap installation diagram www.dyt-ir.com...
  • Page 14 (6) Shoot 1) Snap photos  In the observation interface, adjust the screen to the required state and press the trigger button to enter the capture mode. To save the captured image, touch and click www.dyt-ir.com...
  • Page 15 USB icon appears in the status bar on the left side of the user interface.  The computer side recognizes the connected disk, enters the corresponding folder, can view or copy the video file and capture the picture file;  After the operation is complete, disconnect the USB cable from the computer. www.dyt-ir.com...

  • Page 16: Functions And Features

    4.2. Functions and Features DYT Hand-Held Professional Thermal Camera featured global cutting-edge hardware, comprehensively innovated temperature image algorithm, combined with breakthrough production technology and manufacturing process, challenging extremely harsh environment with core, precision, clarity, stability, portability and durability, with the...

  • Page 17: Operation Guide

    9) Digital doubling: 1-8x digital doubling function can be realized. 4.3. Operation Guide (1) Main menu introduction After the thermal camera is powered on normally, the real-time observation interface is entered. The main menu of the product is shown in Figure 4.4. Figure 4.4 Main menu interface www.dyt-ir.com...
  • Page 18 Step 3: Touch or press the physical button to switch to "Image Settings", and press the physical "OK" button to enter the image setting interface (Figure 4.5), and adjust the gain level (PHE: plateau histogram equalization algorithm (PHE), algorithm type). Figure 4.5 Image Settings www.dyt-ir.com...
  • Page 19 Observe the screen, the temperature areas above the high temperature level are shown as the highest temperature color in the temperature width distribution bar; www.dyt-ir.com...
  • Page 20 Step 2: Touch or click the physical button to switch to the fourth function icon from the left of the main menu, and press the physical "OK" key to call up the temperature menu (as shown in Figure 4.6); Figure 4.6 Temperature measurement object www.dyt-ir.com...
  • Page 21 "OK" key to call up the imaging mode menu (as shown in Figure 4.7); Figure 4.7 Temperature measurement object 1) Touch and click or switch the physical button to , press the physical "OK" key to switch to the infrared screen. www.dyt-ir.com...
  • Page 22 Step 2: Touch or click the physical button to switch to the third function icon from the left of the main menu and press the physical "OK" key to call up the fake color menu (as shown in Figure 4.8); www.dyt-ir.com...
  • Page 23 Step 2: Touch or click the physical button to switch to the third function icon from the left of the main menu. Press the physical "OK" button to call up the fake color menu (as shown in Figure 4.9); www.dyt-ir.com...
  • Page 24 (as shown in Figure 4.10); Figure 4.10 Setting the temperature value Step 4: Touch or physical button to switch to "Apply", press the physical "OK" key, or touch and tap "Apply" to apply the mark temperature threshold set in the current mark mode. www.dyt-ir.com...
  • Page 25 (as shown in Figure 4.11); Figure 4.11 Setting interface Step 3: Touch or click the physical button to switch to "Alarm Setting" and press the physical "OK" button to enter the alarm setting interface (as shown in Figure 4.12); www.dyt-ir.com...
  • Page 26 , press the physical "OK" key to enter the setting screen. Step 3: Touch or press the physical button to switch to "System Settings" and press the physical "OK" button to enter the system Settings interface (as shown in Figure 4.13); www.dyt-ir.com...
  • Page 27 Step 4: Touch and click the photo mode to enter the photo mode selection page (as shown in Figure 4.14); Figure 4.14 Photo Mode Step 5: There are two optional photo modes: single photo and continuous photo. For continuous photo, the number and interval of photos should be set (as shown in Figure 4.15). www.dyt-ir.com...
  • Page 28 ）：make sure to save the current snapshot and its remarks; captured images. Save（ ）：delete the current snapshot and its remarks. Delete（ Figure 4.16 Capture Settings (9) File viewing and editing Step 1: Touch and click the blank area of the screen in the user interface or press the www.dyt-ir.com...
  • Page 29 When the real-time monitoring interface is normally entered, the digital doubling interface can be entered by using physical arrow keys (as shown in FIG. 4.18). The scale can be changed by touching the sliding slider or the left and right physical keys. www.dyt-ir.com...
  • Page 30 , and press the physical "OK" key to enter the setting interface; Step 3: Touch or press the physical button to switch to "Temperature Correction" and press the physical "OK" button to enter the temperature correction interface (as shown in Figure 4.19). www.dyt-ir.com...
  • Page 31 , and press the physical "OK" key to enter the setting interface; Step 3: Touch or press the physical button to switch to "Temperature Setting" and press the physical "OK" button to enter the temperature setting interface (as shown in Figure 4.20); www.dyt-ir.com...
  • Page 32 Step 3: Touch or press the physical button to switch to "System Settings" and press the physical "OK" button to enter the temperature setting interface (as shown in Figure 4.21); Step 4: Select the appropriate automatic shutdown time, photo mode, etc. www.dyt-ir.com...
  • Page 33 Product Info, and press the physical OK key to enter the product Info screen, and choose Format Data or Restore Factory Settings. ⚠ Note: the formatting data can lead to empty, please use caution; After factory Settings are restored, all parameter modification states are cleared and parameters are restored to factory defaults. www.dyt-ir.com...

  • Page 34: Specification Parameters

    5. Specification Parameters Features/Performance DYT DP Series Model Parameters Model DP-38 DP-64 IR Resolution 384×288 640×480 Focal Length 15mm/F1.0 25mm/F1.0 Pixel Size 17μm ≤50mK@25℃ Thermal Sensitivity/NETD Detector Type Uncooled microbolometer Digital Zoom 1x-8x (integer) Image Frequency 30Hz Focus Mode Manual focus...
  • Page 35 Lithium-ion batteries, 7.4V 2600mAH Battery Operating Time Double battery 8h total, can be replaced on site Charging type Charging base charging or Type-C interface charging Operating Temp Range -10℃～+50℃ Protection Level IP54 Grade of fall protection Volume 275mm×123mm×130mm ≤900g Weight www.dyt-ir.com...

  • Page 36: Application Field

    6. Application Field DYT Hand-Held Professional Thermal Camera is widely used in metallurgy, hazardous waste environmental protection, coal mine, medical, construction, scientific research, effective prevention and other application scenarios, can be suitable for ladle resistant material defect monitoring, power failure monitoring, etc.
  • Page 37 Figure 6.2 shows the actual application scenario. Figure 6.2 Power Failure Monitoring www.dyt-ir.com...

  • Page 38: Faqs

    A2: Try to turn the focus wheel and observe the picture until it is clear. Q3: Can't historical files be viewed? A3: Ensure that the SD card status is normal. Q4: Unable to capture/record? A4: Ensure that the SD card status is normal and the storage space is sufficient. www.dyt-ir.com...

  • Page 39: Warranty Service

    This warranty is non-transferable only to the original purchaser. 3) DYT Infrared can repair or replace any such defective products free of charge at its sole discretion after testing and confirming that the products are within the scope of warranty.
  • Page 40 Aluminium 390(199) 0.11 Lead 500(260) 0.08 (oxidation) (polished) Aluminium 1110(599) 0.19 Lead (rough) 100(38) 0.43 (oxidation) Aluminum 212(100) 0.09 Lead 100(38) 0.43 (Highly (oxidation) polished) Aluminum 212(100) 0.18 Magnesium 500(260) 0.10 (rough polished) Aluminium 212(100) 0.09 Magnesium 1820(1000) 0.16 www.dyt-ir.com...
  • Page 41 0.46 (non-oxidized) Brass 476(247) 0.03 Nickel 77(25) 0.05 (polished) (unoxidized) Brass 392(200) 0.61 Nickel 100(38) 0.04 (oxidized) (electrolysis) Brass 752(400) 0.60 Platinum 100(38) 0.05 (oxidized) Brass (matte) 68(20) 0.07 Platinum 100(38) 0.93 (black) Brass 77(25) 0.04 Platinum 1340(727) 0.14 www.dyt-ir.com...
  • Page 42 Steel 212(100) 0.08 (graphitized) (non-oxidized) Carbon 572(300) 0.75 Mild steel 75(24) 0.10 (graphitized) (polished) Copper 100(38) 0.87 Mild steel 75(24) 0.12 (cuprous (smooth) oxide) Copper 500(260) 0.83 77(25) 0.04 (cuprous (non-oxidized) oxide) Copper 100(38) 0.22 212(100) 0.05 (matte) (non-oxidized) www.dyt-ir.com...
  • Page 43 0.05 Uranium 1880(1027) 0.79 (unoxidized) oxide Iron (red rust) 77(25) 0.70 Zinc 100(38) 0.28 (galvanized) Iron (rust) 77(25) 0.65 Zinc 500(260) 0.11 (oxidation) Cast iron 390(199) 0.64 Zinc 100(38) 0.02 (oxidized) (polished) Cast iron 212(100) 0.21 Zinc 500(260) 0.03 www.dyt-ir.com...
  • Page 44 Basalt 68(20) 0.72 Slate 68 (20) 0.69 Firebrick 1832(1000) 0.75~0.80 Silk wadded 68(20) 0.78 Grey brick 2012(1100) 0.75 Snow (fine 20(-7) 0.82 grain) Emery 1850(1010) 0.92 Snow (coarse 18(-8) 0.89 grain) Earthenware 70 (21) 0.69~0.45 Emery 392(200) 0.90 (matte) www.dyt-ir.com...
  • Page 45 0.95 White oil 200 (93) 0.94 Water glass 68(20) 0.96 paint Black oil paint 200 (93) 0.92 Wood 0.85 Red oil paint 200 (93) 0.95 White marble 100(38) 0.95 Green oil 200 (93) 0.95 Cultivated 68(20) 0.38 paint field www.dyt-ir.com...
