Summary of Contents for Hunter Hydrawise Ready

  • Page 2: Table Of Contents

    HPC - Installing Decoder Module Installing the PC-DM Decoder Module Installing Additional Station Modules EZ-1 Decoder Connections and Programming Wire Table HPC - Connecting Station Wires HPC - Connecting Sensors or Flow Meters (Optional) Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 3: Hpc - Install Guide

    Note: Install screw anchors if attaching to drywall or masonry wall. 2. Align controller with the screw and slide the keyhole on top of the controller over the screw. 3. Secure controller in place by installing screws in the holes. Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 4: Hpc - Connecting Ac Power

    Improper installation could result in shock or fire hazard. This device is not intended for use by young children. Never let children play with this device. HPC - Connecting AC Power Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 5: Hpc - Installing Station Modules

    Always use UL listed ½" (13 mm) conduit with male adapter when installing AC wiring. HPC controllers are intended to be supplied AC power with a 15A rated overcurrent protected device. HPC - Installing Station Modules Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 6 3. Once all modules are in place, slide the POWER LOCK into the POWER ON (locked) position to energize and secure the modules into the controller. 4. The controller will automatically recognize the correct number of stations. In some Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 7: Hpc - Installing Decoder Module

    The PC-DM can only be installed in the last two station output slots (similar to PCM-900 and PCM-1600 installation). The PC-DM will not physically fit or operate in any other station output slot. IMPORTANT: While adding this module increases the total station count to 32, the first 4 Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 8: Installing Additional Station Modules

    EZ-1 Decoder Connections and Programming 1. Remove wire insulation, and insert red and blue wires from the decoder into the Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 9 P/MV terminal on the 4-station master module (as shown in the icon next to the P/MV terminal). This wire can be a simple 18G station wire stripped 1/2" on each end that bridges these two terminals to allow operation. See the illustration below. Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 10: Wire Table

    Wire Table Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 11: Hpc - Connecting Station Wires

    SEN-SEN terminals from the original HPC Controllers have been split into SEN and SEN-2 to allow for two separate sensor installations (i.e., flow + rain sensor). Sensors now wire separately across the Common terminal (COM). Front Panel (Old vs New) Terminals Notes Copyright 2024 Hunter Industries. All Rights Reserved.
  • Page 12 Wire Color Sensor Terminal Block Blue SEN or SEN 2 White COMMON Clik Sensor Wiring Wire Sensor Terminal Block Normally Open (NO) or Normally Closed (NC) SEN or SEN 2 Secondary Wire COMMON Copyright 2024 Hunter Industries. All Rights Reserved.
