- Page 1 Single- and Dual-Mount Back-to-Back Pedestal Installation Manual Cat. Nos. EPED1, EPED2 For use with Cat. Nos. EV320, EV32W, EV480, EV48W, EV48S, EV48G, EV800, EV80W, EV80S, AND EV80G PK-A3430-10-00-5C-W...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 WARNINGS .............................4 INSTALLATION ..........................5 2.1 Making Drill Holes ......................5 2.2 Thread in Cable .........................6 2.3 Anchoring ..........................6 2.4 Bracket Installation ......................7 2.5 Connector Base and Hook Installation ................8 2.6 Mounting and Connecting the Charging Station ............9 STANDARD STATEMENTS AND WARRANTY ................ -
Page 4: Warnings
1 WARNINGS Safety Instructions Failure to follow the safety instructions can result in risk of death, injuries and damage to the device. The seller assumes no liability for claims resulting from this. Electrical hazard! • The installation, commissioning and maintenance of the charging station may only be performed by correctly trained, qualified and authorized electricians who are fully responsible for the compliance with existing standards and installation regulations. -
Page 5: Installation
2 INSTALLATION 2.1 Making Drill Holes Mark four (4) holes on the concrete foundation using the base-plate of the pedestal. Make sure that the connection cable is located precisely underneath the opening in the base-plate. 2. Drill four (4) mounting holes: Diameter: 0.39 in. -
Page 6: Thread In Cable
2 INSTALLATION 2.2 Thread in Cable Thread the connection cables from the bottom through the pedestal upwards through the cable opening. 2.3 Anchoring Position the pedestal directly over the cable outlet. 2. Anchor the pedestal to the foundation using four (4) sets of M8 nut, M8 flat washer, M8 spring washer. -
Page 7: Bracket Installation
2 INSTALLATION 2.4 Bracket Installation Insert the cable gland into the pedestal. 2. Install the mounting plate to the pedestal with screws provided. -
Page 8: Connector Base And Hook Installation
2 INSTALLATION 2.5 Connector Base and Hook Installation Use four (4) of M5 x 22 mm. screws to fix the connector base and hook in the corresponding position. -
Page 9: Mounting And Connecting The Charging Station
2 INSTALLATION 2.6 Mounting and Connecting the Charging Station Mount the charging stations on the pedestal using two (2) M5 x 12 mm screws on both sides of the charger. 2. Release the four (4) M5 x 12 mm screws from the wiring window at the back. 3. -
Page 10: Standard Statements And Warranty
LIMITED 1 YEAR WARRANTY AND EXCLUSIONS Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by Leviton is free of defects in materials and workmanship under normal and proper use for one year from the purchase date. Leviton’s only obligation is to correct such defects by repair or replacement, at its option.
