Power Climber TITAN PI Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATING MANUAL - TITAN PI
•
All persons operating this equipment must read and completely understand this manual.
•
Only authorized and trained persons, capable of carrying out the daily checklist, shall
operate the equipment.
•
Any operation in violation of these instructions is at one's own risk and may result in
serious injury.
•
Keep this manual with the equipment at all times.
•
Only use POWER CLIMBER original spare parts and steel wire ropes.
Manufacturer
POWER CLIMBER B.V.
Satenrozen 7
B- 2550 Kontich
BELGIUM
Reference: 38761-E
Tel. +32-3-451 05 00
This document and all copies are the property of Power Climber BVBA. All dimensions and data are indicative only.
OPERATING MANUAL
CONFORM TO EUROPEAN NORM
EN 1808:2015
MACHINE DIRECTIVE 2006/42/EC
Issue date: 2023AUG09
E-mail: Info@PowerClimber.com
Website: www.PowerClimber.be
The user must ensure that the equipment complies with local rules and regulations.
WARNING:
Website: www.PowerClimber.be
Tel: +32-3-451.05.00
E-mail: info@PowerClimber.com
Revision: C
Page: 1 of 20
Fax +32-3-451 05 01
