Summary of Contents for MedPro DEFENCE nocospray
-
Page 3: Table Of Contents
INTRODUCTION ..................................4 I.1. General information ................................4 I.2. Classification / Regulation ..............................4 I.2.1. Warranty purpose ................................ 4 I.2.2. Transport ..................................4 I.2.3. Warranty duration ................................ 4 I.3. Technical characteristics ............................... 5 PRECAUTIONS FOR USE ................................. 6 II.1. Safety instructions ................................. 7 III. -
Page 4: Introduction
I. INTRODUCTION I.1. General information This user manual describes the functioning of the NOCOSPRAY® diffuser and includes essential information to ensure the safe use of the machine. The documentation applies to Nocospray® diffusers in their original manufacturer’s condition and which have not been altered. Review this manual before using the NOCOSPRAY®... -
Page 5: Technical Characteristics
I.3. Technical characteristics Power: 850VA Tension: 120V mono Frequency: 50 à 60 Hertz Nominal intensity: 4,5A Maximum intensity: Compatible bottle: 1 Litre Weight: 6,2Kg Package weight: 8,3Kg Maximum room volume to be treated: 1000m Average flow of the liquid: 1000 ml/h Environmental conditions: In condition of use : Temperature between 0°C and 40°C... -
Page 6: Precautions For Use
PRECAUTIONS FOR USE The manufacturer cannot be held responsible for any material or bodily harm resulting from the abnormal or faulty use of the device, or the disregard for guidance below: Use only with Nocospray® product • Modifying the machine is forbidden. •... -
Page 7: Ii.1. Safety Instructions
II.1. Safety instructions The device diffuses a chemical substance and makes noticeable sound, therefore it is necessary to pay attention to following recommendations. IMPORTANT RECOMMENDATIONS - Always consult the accompanying documents - For indoor use only. - Do not inhale the product - Do not direct the spray toward an incandescent source - Do not smoke close to the device - Grounded connection only... -
Page 8: Description
III. DESCRIPTION III.1. NOCOSPRAY® description Bottle Mini USB port Nozzle and nozzle holder Fuses (5x20 10A T) Nose of the diffuser (venturi) Power cable Handle Power switch Nozzle release button Control touch pad... -
Page 9: Iii.2. Nocospray Dimensions
III.2. NOCOSPRAY dimensions ® Instructions for USE IV.1. Positioning of the device The NOCOSPRAY® must be placed on a hard and flat surface and if possible in a corner of the room to treat. IMPORTANT RECOMMENDATION Before starting a cycle, check that there are no obstacles within 2 meters from the device. -
Page 10: Iv.2. Installation Of The Bottle
IV.2. Installation of the bottle Follow instructions below to install the bottle. Open the bottle and screw on the nozzle. Remove the diffuser nose by pressing When opening a new bottle make sure to Place the nozzle back on the device. And the button write the date in the area provided press gently until you hear the «click». -
Page 11: Iv.3. Diffusion Duration And Consumption
IV.3. Diffusion duration and consumption Volume setting (m Consumption (ml) Duration of diffusion 36 seconds 54 seconds 1 minute & 12 seconds 1 minute & 30 seconds 1 minute & 48 seconds 2 minutes & 6 seconds 2 minutes & 24 seconds 2 minutes &... -
Page 12: Iv.4. Functioning In " Standard " Mode
IV.4. Functioning in « standard » mode Select the volume by dragging your The light indicates the volume chosen, finger on the clear part of the Connect the power cable and put the if two lights are illuminated, the touchpad. main switch on «... -
Page 13: Iv.5. Using Traceability Function
IV.5. Using traceability function A mini USB connector enables transferring the treatment history to a computer (see installation of the traceability software) The device will not diffuse when in USB mode. To exit USB mode, unplug the cable from the computer Plug the mini USB cable where The 10m and 1000m... -
Page 14: Iv.5.1. Installation
IV.5.1. Installation Click on “NocoSprayTacker_Setup.exe” on the CD ROM or USB key supplied. Allow the program to install the software if Windows asks. 1°) Click on « Next » 2°) Click again on « Next » 3°) Click on « Install » 4°) Click on «... - Page 15 Nocospray Tracker software runs: Connect Nocospray® on the USB port of your computer: An icon on bottom right might appear to indicate that the device driver is running. If your computer doesn’t allow an automatic installation, the driver « .inf » is provided with the software, please contact your system manager.
-
Page 16: Iv.5.2. Use
IV.5.2. a) General information Nocospray tracker software will launch automatically once installed. If it does not, it can be initiated manually. « Device Name »: Name of the device (editable parameter) « Device date »: Date and time of the device (to be set the first time – it will automatically update afterwards) «... -
Page 17: C) Export Records
Export records This icon enables exporting the recorded treatments to a PDF. It brings you to the following window: Using this icon , you can choose the folder where you want to save the data (PDF file). « PDF Name »: enter the name of the record file. Then, click to «... -
Page 18: Maintenance
MAINTENANCE The NOCOSPRAY® device requires regular maintenance. - Switch off the device before any cleaning. - Do not use abrasive products, bleach, acetone or solvents for maintenance or cleaning operations of the device. These aggressive agents may damage the surface materials (discoloration, tasks, drips, microcracks…) - For the cleaning of external surfaces, use a slightly damp cloth or wipes.
