  • Page 2: Table Of Contents

    To stay up to date with the latest version of this document, we recommend that you periodically consult Pro DG Systems website. When reselling this product, give this document to the new owner. If you supply Pro DG Systems products, please inform your customers about this document. Index Precautions ………………………………………………………….……..…………….…………… 4 - 5 Warranty …………………………………………………………………...….……………………..……..
  • Page 3 Amplifier ……..……………….……………………………………………………………………….. 18 DSP - Software ProDGnet Description …….……………………………………………………………………..…………… 19 Usage guide in PC ………...…………………………………………………………...…. 20 to 29 Selecting presets in the unit itself ……………….…………………………...………………… 30 Flight Hardware Usage in combo format with subwoofer ……..………………………...……………………... 31 Rigging points ………….…………………………...……………………………………………. 32 Safety instructions in case of flying the system ……………………..…………………..

  • Page 4: Precautions

    Precautions Please read, keep and follow all safety and use instructions. Important Safety Instructions. 1. Heed all warnings. 2. Do not overload the box to avoid damage to the speakers. 3. Do not use this product near water. If the box is used outdoors, make sure that no humidity can enter the box.

  • Page 5: Warranty

    Contains small parts which may be a choking hazard. Not suitable for children under age Warranty All the Pro DG Systems products have a 24-month warranty period, which begins from the invoice date of the first purchase. Consult everything relevant to the warranty conditions at Pro DG Systems website: https://prodgsystems.com/20-vc-warranty.html...

  • Page 6: Declaration Of Conformity

    Declaration of conformity Pro DG Systems declares that the product with reference AVIATOR 112 A complies with the objectives expressed in the following European Directives: - Low voltage 2014/35/UE. - Electromagnetic compatibility 2014/30/UE. - RoHS 2011/65/UE. About restrictions on the use of certain dangerous substances in electrical and electronic equipment.

  • Page 7: Description

    AVIATOR Series. The new AVIATOR Series from Pro DG Systems has been developed with the purpose of offering the best quality-price ratio on the market. It has a completely modernized appearance, great power and reduced weight thanks to the incorporation of state-of-the-art Lavoce Italiana components.
  • Page 8 Ease Focus prediction software is available. At Pro DG Systems we know the importance for professionals of having a flexible, easily configurable system that guarantees maximum sound performance without the cost of external processors or additional wiring. The joint use of ProDGnet processing software and Ease Focus prediction software allows you to achieve this objective in seconds, achieving: - Remote SPL level control.

  • Page 9: Technical Datasheet

    The perfect solution as main PA, frontfill and sidefill at outdoor events or permanent installation. Ideal for working in live concerts, theaters, coverage under amphitheaters, places of worship, corporate applications and all types of events where high performance and versatility are necessary.

  • Page 10: Architectural Specifications

    Controls On / off switch and master volume. Preset selector cursor. Power supply AC 90~265V - 50 / 60HZ. Construction Birch plywood using CNC machining. 2mm thick perforated steel front grille, with oven- dried black electrostatic powder paint finish. Includes acoustic foam. Includes stand socket to attach extendable bar.

  • Page 11: User Guide. First Steps

    User guide. First steps Turning On / Off Turning on any sound system must be done from back to front. Turn on sources such as CD players first, then the mixer, then the processors, and finally the self-powered loudspeakers. If you have several self-powered loudspeakers, it is advisable to turn them on sequentially one by one.

  • Page 12: Troubleshooting

    User guide. Troubleshooting Problem Cause Solution The unit does not sound. 1. The signal source is not 1. Check the mixer output sending a signal over the indicator to see if the signal cable. is being sent. 2. Defective cable. 2.
  • Page 13 3. Contact your Systems distributor authorized professional to perform the repair. If you have any technical problem or questions about Pro DG Systems products; contact our technical support department at: sat@prodgsystems.com...

  • Page 14: Speaker

    Speaker AVIATOR 112 A includes one 12” Lavoce Italiana speaker with neodymium magnet, in charge of reproducing low and medium frequencies. Main characteristics Power handling of 500 W RMS / 1000 W program Optimized cooling system Optimized neodymium magnetic circuit 3”...

  • Page 15: Compression Driver

    Architectural Compression driver The HF section of the AVIATOR 112 A has one 1” Lavoce Italiana compression driver with ferrite magnet, in charge of reproducing high frequencies.
  • Page 16 Main characteristics Power handling of 50 W RMS / 100 W program optimized motor, phaseplug diaphragm Bobina CCA de 1,7” High temperature polymeric diaphragm State-of-the-art HF design Voice coil copper demodulation ring 1,6 Kg weight Architectural...

  • Page 17: Horn

    Horn The compression driver of the AVIATOR 112 A is coupled to a rotatable diffuser (horn) to offer a dispersion of 90ºx50º (H x V), specifically designed to achieve maximum performance and acoustic quality in high frequencies. Made of ABS material to offer a low weight. Specially designed to achieve a perfect blend between medium and high frequencies.

  • Page 18: Amplifier

    Amplifier AVIATOR 112 A has a new state-of-the-art Class-D amplifier module and own DSP, very intuitive to use for easy handling and absolute control. Incorporates one channel with 800 W RMS for LF and MF + one channel with 300 W RMS for HF. Input type: balanced.

  • Page 19: Dsp - Software Prodgnet

    (unit by unit). To operate with ProDGnet software from your PC you will only need: - Download ProDGnet software at Pro DG Systems website (section “Support” > “Software”): https://prodgsystems.com/19-scrpt-software.html Easy to download, all the necessary drivers for installation are included.
  • Page 20 Once the software is downloaded on your PC; create your network of Pro DG Systems systems, to do this connect the Ethernet cabling to the different units; When you start the software, the general menu will be displayed by default. (OVERVIEW);...
  • Page 21 When clicking “Connect” > “Remote mode”, in the top bar; The following dialog box will appear; Allowing connection to the DSP module of each unit connected to the Ethernet network. After pressing “OK” all connected units will be displayed (in green) to the left of the menu;...
  • Page 22 By clicking on the INPUT menu, a 31-band parametric equalizer is displayed, allowing you to select the type of Filter, Frequency, Bandwidth (Q), Gain and Bypass;...
  • Page 23 On the left of the menu, you can manually modify Gain, Mute, Delay, Bypass and input channel selection. To the right of the menu is a noise gate where we find Threshold, Attack, Release and a Bypass of the input noise gate. To apply changes to any of the units connected to the ProDGnet network, simply click on the desired unit.
  • Page 24 Then, the factory stored preset selection menu will be displayed; The meaning of the colors shown next to each preset is as follows: Empty Preset. Preset stored in memory. Preset that we want to appear by default when turning on the unit. Currently selected preset.
  • Page 25 To Import or Export presets individually (preset by preset), from PC to amplifier unit or vice versa, it will necessary to click “Memory” > “PC preset”. The “Export all presets” tab allows exporting all the presets stored on the PC to the unit. The “Import presets package”...
  • Page 26 By having a network of systems connected to each other through Ethernet cabling and RS485 protocol, you have the possibility of creating a group of systems, which allows any change or equalization made to be applied to all the units that are part of the same network. For example, if we have twelve units AVIATOR 112 A, when creating a group made up of these units, any change or equalization made will be applied to all units;...
  • Page 27 The following dialog box will appear. Click “OK” button”. Once the previous step has been completed, all the units connected to the network will be displayed on the left of the menu (the group has not been created yet). Then click “Device List” button”.
  • Page 28 Next, we will select all the units that will be part of the group and click on the right arrow icon, the units that are displayed in the box on the right are the ones that will be part of the same group;...

  • Page 29: Usage Guide In Pc

    We will press “OK” button, which will cause the following dialog box to appear, in which we can modify the name of the created group, as well as different parameters of it; By pressing “OK” button in the previous step, the group creation process will be completed.

  • Page 30: Selecting Presets In The Unit Itself

    - Preset nº4: to combine AVIATOR 112 A with AVIATOR S 115 A. - Preset nº5: to combine AVIATOR 112 A with AVIATOR S 118 A. If you have any technical problem or questions about Pro DG Systems products; contact our technical support department at:...

  • Page 31: Usage In Combo Format With Subwoofer

    AVIATOR 112 A features a stand socket to attach an extendable bar, allowing it to work together with a subwoofer unit in combo format. Extendable bar is not included, possibility of being supplied by Pro DG Systems as optional equipment. AVIATOR 112 A AVIATOR 112 A...

  • Page 32: Rigging Points

    Hardware. Rigging points AVIATOR 112 A has 12 M8 rigging points for fixing bolts, allowing a wide variety of installation possibilities on wall or ceiling.

  • Page 33: Safety Instructions In Case Of Flying The System

    Safety instructions in case of flying the system Before flying the system, it is mandatory to take into account the following safety instructions: - Always carry out a visual and functional inspection of the various components before use. In case of doubt about the correct functioning and safety of the components, they must be removed from use immediately.
  • Page 34 As well as the correct signage of the space in which work is being done. - All accessories used to fly a Pro DG Systems sound system not provided by Pro DG Systems are the responsibility of the user(s).

  • Page 35: Flight Hardware Components

    Flight hardware components At Pro DG Systems we know the importance for the professional of installing the different systems in a simple, fast and safe way. AVIATOR 112 A flight system has been designed to guarantee these purposes. The different components are detailed below:...
  • Page 36 Note: the specifications of these components may be changed without prior notice. To be aware of the latest modifications, please consult Pro DG Systems website periodically.

  • Page 37: How To Fly The System Up

    How to fly the system up Important: before flying the system, carefully read the subsection “Safety instructions”, located in the “Flight hardware” section (pages 33 - 34). In case of using two units in cluster format: Remove the screws located at the top and bottom, indicated below: Screw the lower hardware link and the fly bar into the indicated points:...
  • Page 38 Install the shackle to the fly bar to raise the assembly. The fly bar 112 has different accommodations to provide angulation to the assembly, depending on where the shackle is fixed to the fly bar.
  • Page 39 In case of using three units in cluster format: You will only have to remove the screws indicated at the top: The rest of the steps to follow are the same as those described above, when using two units in cluster format.

  • Page 40: Ease Focus Prediction Software

    SPL and general behavior of the system, in a simple and comfortable way for the user. It is very easy to use and we have training courses for users of Pro DG Systems products. For more information, consult our technical service at: sat@prodgsystems.com...

  • Page 41: Accessories

    Accessories Cableado completo del sistema listo para funcionar.
