Hardware Installation
Note: Before installing or removing the mouse to or from your computer, always re-
member to turn off your computer. Installing or removing the mouse when your com-
puter is running will cause permanent damage to the mouse or your computer.
1.
For PS/2 model, you can connect the mouse to the PS/2 port.
For the USB model, connect your mouse to the USB port on your computer.
2.
For the USB & PS/2 model, you need to use the 6-pin PS/2 adapter.
3.
Turn on your computer.
4.
Warning: Please do not use this optical mouse on a desk which is made of glass, mir-
ror, iron, or black velvet. Also, a flat surface is necessary or the Optical Sensor will
not work properly.
Software Installation
Installing the MouseMate software
For PCs, start Windows, insert the software CD into the computer's CD-ROM
1.
drive, then follow the on-screen instructions. (If Autorun is not enabled, select
Run from the Start Menu on the Taskbar. Next, type D:\Setup.exe, where D: is
the designation of the CD-ROM drive.)
For the Macintosh, start the Macintosh operating system, insert the software CD
2.
into the computer's CD-ROM drive, find the Installer icon in the appropriate
language folder, double-click the icon, then follow the on-screen instructions.
Factory Settings
Hardware Installation
1
Advertisement
Related Manuals for Genius NS O
Summary of Contents for Genius NS O
-
Page 1: Hardware Installation
For the USB & PS/2 model, you need to use the 6-pin PS/2 adapter. Turn on your computer. Warning: Please do not use this optical mouse on a desk which is made of glass, mir- ror, iron, or black velvet. Also, a flat surface is necessary or the Optical Sensor will not work properly. - Page 2 Horizontal Hold the Shift key while pressing the Magic-Roller in the direc- Scrolling tion you want to go or move the cursor over the horizontal scroll bar and press the Magic-Roller. Button Assignments The Button Assignment feature...
- Page 3 This option makes it easier to find the cursor when using an LCD monitor. This option cannot be used if your monitor does not support it. When you move the cursor to the top (or bottom) of the Loop screen, it will automatically move the cursor to the bot- tom (or top) of the screen.
- Page 4 MouseMate Software Features Once you press the button you assigned, “Office EasyJump” will be displayed on a Frisbee. Note that the functions are only available in the applications they belong to. Click this application button to show the mouse control panel. You can check or modify the mouse properties.
- Page 5 Click this function to return to the previous web page in your open Internet browser. Click this function to more forward to the next web page in your open Internet browser. Click on this application to launch Windows media player or any other multi- media player installed in your system.
- Page 6 Click this button to open the Help button. Click this button to open the Genius Mouse Control Panel. Click the button and you can move the mouse in any direction in a document or a spreadsheet. The farther you move the pointer from the pan icon, the faster you can pan in that direction.
-
Page 7: Auto-Panning
Press the “Ctrl” key and move the “Magic-Roller” forward (or backward) to set the Zoom In/Out function. You can also use just one hand to Zoom In/Out: set the right button to be the “Ctrl” function, press the right button and move the “Magic-Roller”...
