- Page 1 AC2600 MU-MIMO Wi-Fi Router QUICK INSTALL GUIDE DIR-882...
-
Page 2: Package Contents
Package Contents DIR-882 AC2600 High Power Wi-Fi Gigabit Router Power Adapter Ethernet Cable Wi-Fi Configuration Card Quick Install Guide If any of the above items are missing, please contact your reseller. Minimum Requirements Network Requirements: • An Ethernet-based broadband modem App Configuration Requirements •... -
Page 3: Hardware Overview
Hardware Overview 2 3 4 5 6 10 11 12 13 14 15 A solid light indicates a proper connection to the power supply. The light will be a solid orange Power LED during boot up. A solid light indicates connection on the Internet port. If the LED is orange, the router cannot Internet LED connect to the Internet. -
Page 4: Before You Start
Configuration There are two ways to configure your router: A. D-Link Wi-Fi app - Use a mobile device with the D-Link Wi-Fi app. B. Web Browser - Use a web browser from your computer. Refer to the Web Browser Configuration section for more information. - Page 5 B. Web Browser Configuration Connect your Router Unplug the power to your DSL or Cable modem. NOTE: If your DSL or cable modem uses a battery backup, please remove the backup battery and ensure all lights are off on the modem. Refer to the modem’s user manual if required.
- Page 6 Plug the power back into your DSL or cable modem. Please wait about one minute before continuing. - • + USB 2.0 INTERNET RESET WiFi 12V. . . 1.5A POWER DIR-882 Modem Plug the power adapter into your router and connect to an available power outlet or surge protector.
- Page 7 Connect another Ethernet cable from the Ethernet port on your computer to one of the LAN ports on the router. You can also connect wirelessly to the router with your computer. Use the supplied Wi-Fi Configuration Card for the Wi-Fi network name (SSID) and Wi-Fi password of the router. INTERNET 12V --1.5A POWER...
- Page 8 When the Welcome screen appears, click Next to continue. The router will automatically detect your Internet connection type. If it cannot, then select your Internet connection and click Next to continue. For DSL (PPPoE) users, enter your PPPoE user name and password supplied by your ISP.
- Page 9 If you have a Static IP connection, enter the IP information and DNS settings supplied by your ISP. Click Next to continue. Create a name and password for your Wi-Fi Network. Your wireless devices (i.e., tablets, smartphones, and laptops) will need to have this information entered to be able to connect to your wireless network.
-
Page 10: Troubleshooting
Troubleshooting How do I connect my wireless devices to the DIR-882 router? 1. Open your wireless network utility that displays available wireless networks. 2. Select the Wi-Fi Network name you assigned in the wizard and connect. Note: If you did not run the setup wizard or you reset the router to its default settings, refer to the Wi-Fi Configuration Card included for the default Wi-Fi Network Name and Wi-Fi Password. -
Page 11: Gpl Code Statement
Where such specific license terms entitle you to the source code of such software, D-Link will provide upon written request via email and/or traditional paper mail the applicable GPL and LGPLsource code files via CD-ROM for a nominal cost to cover shipping and media charges as allowed under the GPL and LGPL. -
Page 12: Technical Support
610000009802 ©2019 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. iPhone, iPad, and iPod touch are registered trademarks of Apple Inc.
