Fienza KAYA Installation Manual

INSTALLATION GUIDE
BEFORE INSTALLATION: CHECK ALL PARTS OF PRODUCT THOROUGHLY.
INSTALLATION IS ACCEPTANCE OF GOODS AND WILL VOID WARRANTY. MIRRORS
ARE FRAGILE. TAKE EXTRA CARE WHILE TRANSPORTING AND HANDLING GOODS.
KAYA
Round LED Mirror
with Touch Sensor & Demister
LED696
5mm thick pencil edge mirror with frosted glass frame
●
Illuminating on/off touch sensor
●
Demister function
●
Low energy consumption allows the light to be left on as a night light
●
Cool white colour temperature (4000K)
●
Two wall mounting hooks
●
220-240V AC 50/60Hz
●
IP44 rating
●
SAA approved
●
LED module: 17W, Demister: 16W
●
Net weight: 6kg
●
INSTALLATION
This mirror must be installed by a licensed electrician in
accordance with local regulations. Ensure mains power has been
turned off before installation. Do not install within 1.2 metres of
direct wet area contact (e.g. bath or open shower).
NOTE: Ø5 x 50mm screws and anchors are included. It is
recommended that the mirror is installed onto a flat uniform wall,
and must be screwed into studs or suitable anchors.
CLEANING
For best results, clean mirrors with a combination of 30%
methylated spirits to 70% water and a soft, non-abrasive cloth
designed for use on glass surfaces.
ITEM CODE: LED696
Installation must be carried out by a qualified electrician in compliance with any Federal, State, or Local Authority Regulations. All measurements are
in millimetres and are subject to change without notice. Please refer to fienza.com.au for the latest product specification.
UPDATED: 01-MAY-2020
Hook
696
Switch
OPERATION
Touch the relevant icon to turn the LED light or demister on or off.
LED ON/OFF
fienza.com.au
407
220
Demister
Transformer
696
600
DEMISTER ON/OFF
696 600
20
5
