OWNERS MANUAL | Cobolt 06-01 Series | D0951-A
Cobolt 06-01 Series
Plug and play | Modulatable | CW lasers
375 nm
473 nm
395 nm
488 nm
405 nm
505 nm
415 nm
515 nm
425 nm
520 nm
445 nm
532 nm
457 nm
553 nm
561 nm
690 nm
594 nm
705 nm
633 nm
730 nm
638 nm
760 nm
647 nm
785 nm
660 nm
808 nm
685 nm
830 nm
852 nm
915 nm
940 nm
975 nm
1064 nm
1 | 52
Advertisement
Table of Contents
Related Manuals for Cobolt 06-01 Series
Summary of Contents for Cobolt 06-01 Series
- Page 1 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Cobolt 06-01 Series Plug and play | Modulatable | CW lasers 375 nm 473 nm 561 nm 690 nm 852 nm 395 nm 488 nm 594 nm 705 nm 915 nm 405 nm...
- Page 2 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 2 | 52...
-
Page 3: Table Of Contents
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A CONTENTS Introduction Safety 2.1. Symbols in the manual 2.2. General 2.3. Accessible Emission 2.4. Safety features 2.5. Equipment Safety 2.1. Warning and Identification Labels Quick Start Guide 3.1. Mounting and connecting the laser 3.2. - Page 4 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 4 | 52...
-
Page 5: Introduction
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Introduction The Cobolt 06-01 Series offers a compact form factor and a wide wavelength range in a plug and play format, consisting of high-performance fixed wavelength laser modules; modulated laser diodes (MLD) and diode pumped lasers (DPL) cover a spectral range between 375 nm and 1064 nm, with complete green coverage including 532 nm, 553 nm, 561 nm and 594 nm. -
Page 6: Safety
General All Cobolt 06-01 Series lasers are Class IIIB (CDRH), Class 3B (IEC) laser products emitting less than 500 mW of laser radiation within the ultraviolet (UV), visible (VIS) and near Infrared (NIR) spectrum. The residual at wavelengths not specified on the warning label does not exceed Laser Class 1. -
Page 7: Accessible Emission
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 2.3. Accessible Emission The table below describes the irradiance in W/cm and appropriate level of eye protection in terms of optical density (OD) for each laser product. CAUTION Always wear the appropriate eye protection for all the specified emitted wavelengths. Verify the accessible emission wavelengths and power levels on the warning label before operating. -
Page 8: Safety Features
The laser is equipped with all required safety features as described in the laser safety standard IEC 60825-1. If any part of the delivered equipment is replaced with a part not supplied by Cobolt or if the equipment is not properly grounded system may not conform to CE / CDRH compliance standards listed in section 12. -
Page 9: Equipment Safety
Fiber Pigtailed Option All safety recommendations in section 2 are also valid for the Cobolt 06-01 series fiber pigtailed laser heads. Additionally, heat generated from absorption of laser radiation by particles on the fiber end may increase the probability of ignition hazards in certain environments. -
Page 10: Warning And Identification Labels
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 2.1. Warning and Identification Labels The upper face of the laser head contains a yellow label with laser safety warning and classification information, the wavelength and maximum power of the unit. It also shows the location of the laser beam aperture and indicates the open and closed positions of the manual shutter. - Page 11 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Fiber pigtailed laser head Manufacturer Identification Labels OEM Label Aperture Warning Labels CE / CDRH compliant label Laser Notice No. 56 Label CDRH models shipped to USA 11 | 52...
-
Page 12: Quick Start Guide
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Quick Start Guide 3.1. Mounting and connecting the laser Mount the laser on a heat sink or suitable flat surface that provides adequate heat dissipation and connection to ground. Use the four holes on the laser’s base plate to secure it. -
Page 13: Shutting Down The Laser
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Connect the supplied 12V power supply unit to the 12V socket on the laser head and plug it in to the mains. 6. To start the laser, turn the key on the Control Box clockwise to the ON position. If it is already in the ON position, turn it to OFF and then ON again. -
Page 14: Controlling Emission
Controlling Emission All Cobolt 06-01 lasers are available with emission controls for continuous wave (CW) or modulation mode operation. In this section the different ways to control the emission of each laser will be introduced. It is not recommended to use the continuous wave emission or power level controls to turn the laser ON and OFF with high speed. - Page 15 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Laser ON and Laser OFF Button The Laser ON and Laser OFF buttons can be used to stop and start emission regardless of the laser run mode (constant power, constant current, power modulation or current modulation mode). Access to the Laser ON and Laser OFF buttons is available in the summary level of the user interface as well as the ‘More’...
-
Page 16: Modulation Quick Start
Modulation inputs are design to allow the user to control the laser emission using external signals. Below is a quick reference list for correct modulation inputs for the 06-01 series. In the case of integration into a larger system, when using the laser in modulation mode, the laser safety compliance of the system must be evaluated in the final application. - Page 17 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Power modulation Digital Modulate the laser ON and OFF to the set power with active power stabilization to ensure a uniform emission within a pulse. Modulation Frequency: ▪ 06-DPL: DC – 1 kHz ▪...
- Page 18 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Current modulation Digital High speed ON OFF modulation to a set current level. Modulation Frequency: ▪ 06-DPL: DC – Up to 10 kHz ▪ 06-MLD: DC – 150 MHz Input signal: 0 – 5 V TTL signal, square wave ▪...
-
Page 19: Operation Via Data Port
Product ID: 0x03EC = 06-MLD, ox03ED = 06-DPL • Laser serial number When using the Cobolt laser with a Windows 8 or earlier (e.g Windows 7, Vista, XP) it is necessary to install the Cobolt signed USB driver, please refer to the Hübner Photonics website https://hubner-photonics.com/ RS-232 communication To communicate with a laser, a PC needs to have a serial port. -
Page 20: Cobolt Monitor Software
Save the .zip file to any storage device and extract all files. The folder created after extracting the files can be placed on any storage device and Cobolt Monitor™ can be run from there. All files and folders contained in the .zip file must be present for the program to function properly. - Page 21 Opens a command communications window to send commands directly to the laser. Disconnect Allows the user to disconnect from the Cobolt Monitor™ software in a controlled way. More An additional Cobolt Monitor™ window will open containing more detailed information of that laser’s status and operational settings.
- Page 22 Input fields for settings such as the constant power settings and constant current setting, digital power modulation setting and digital current modulation setting. In power modes the current will be set by Cobolt Monitor to reach the power level input into the setting field. Autostart Program Displays whether the laser is CDRH (key switch enabled) or OEM (key switch disabled) configured and displays the current laser state.
-
Page 23: Command Syntax
Analog input voltage of the laser to the range 0 – 5 V. To get started using a Cobolt laser with a program written C++ or Python, please refer to our example codes at the Hübner Photonics GitHub: https://github.com/cobolt-lasers. - Page 24 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A INTerlock[:state] TEC<x>:ENAbled TEC<x>:TEMPerature:SETPoint TEC<x>:TEMPerature[:reading] STATe SYSTem:INPut:ANAlog:IMPedance SYSTem:INPut:ANAlog:VOLTage:RANGe:MAX SYSTem:INPut:ANAlog:VOLTage:READing FAULt FAULt:STATe FAULt:CODE FAULt:DESCription FAULt:CLEar Emission control and laser status See pg. 26 AUTOstart:RESTart AUTOstart:ABORt STARt STOP LASer:PAUSed LASer:RUNMode LASer:POWer[:reading] LASer:CURRent[:reading] LASer:CURRent:SETPoint:MAX LASer:POWer:SETPoint:MAX LASer:POWer:SETPoint:NOMInal Constant power mode See pg.
-
Page 25: Command Descriptions
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Current modulation mode See pg. 28 LASer:CurrentModulation:DIGital:ENAbled LASer:CurrentModulation:ANAlog:ENAbled LASer:CurrentModulation:CURRent:HIGH:SETPoint LASer:CurrentModulation:CURRent:LOW:SETPoint LASer:CurrentModulation:TEC<x>:TEMPerature:SETPoint 4.6. Command Descriptions Commands to query system information including identification, configuration, state, and fault information. System Commands Command description Argument Return (data type) [units]... - Page 26 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A TEC<x>:TEMPerature:SETPoint Returns the set point temperature at TEC <x>. Query only (float) [°C] <x> is either 1 [default], 2, 3 TEC<x>:TEMPerature[:reading] Returns the measured temperature at TEC <x> Query only (float) [°C] <x>...
- Page 27 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A STARt Starts the autostart sequence and results in laser emission once the ‘Laser ON’ state is reached, regardless of the autostart enabled state. STOP Stops the laser emission and will set the laser in the ‘Standby’...
- Page 28 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A LASer:PowerModulation:DIGital:ENAbled Set / returns the digital power modulation enabled state. If 0 – Disabled 0 – Disabled enabled, the laser will require a high signal on the appropriate 1 – Enabled 1 – Enabled input to emit.
- Page 29 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A LASer:CurrentModulation:CURRent:HIGH:SETPoint Set / returns the ON level power set point for digital current float) mA float) mA modulation operation. This level is factory set to be give a digital ON at 100 % of nominal power when the digital high signal is applied without attenuation via the analog modulation input.
-
Page 30: Hardware Overview
Hardware overview Cobolt 06-01 Series laser systems consist of four main parts: the laser head, key control box, cable between laser head and key control box, and the power supply (not shown). Always install the laser system to a properly grounded power outlet. -
Page 31: Configurations
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 5.2. Configurations CE/CDRH Compliant The CE/CDRH compliant system is supplied with a key control box, which must be connected, along with a remote interlock connector. Once power is supplied, laser emission starts when the key is turned from the OFF position to the ON position. -
Page 32: Laser Head
06-01, 06-51 and 06-91 Free beam lasers Cobolt model 06-01 and 06-91 are beam lasers. See section 6.1 for available wavelengths and power levels. The mini-USB is used to communicate with the laser. In addition, the laser head supplies a Molex 14-pin connection, of which the pin 1 and pin 2 are used for the remote interlock function. -
Page 33: Thermal Management
Power supply requirements An appropriate Power Supply Unit (PSU) is supplied by Cobolt with the laser and can be plugged into a standard power outlet. The power supply accepts 90 - 264 VAC and 47-63 Hz. Ripple and noise 1 % peak-peak max. Accepted voltage range for the laser head is (12.0 ±... -
Page 34: System Specifications
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A System Specifications The information presented here is believed to be accurate and is subject to change without notice. The specifications contained herein cannot be guaranteed outside of normal operational conditions. 6.1. Optical specifications - free beam lasers... -
Page 35: Optical Specifications - Fiber Pigtailed Lasers
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 6.2. Optical Specifications - fiber pigtailed lasers Product type 06-MLD 06-DPL Center Wavelength (nm) Power (mW) Power stability over 8 hrs (%) < 3.0 Noise, 20 Hz – 2 MHz (RMS, %) <... -
Page 36: Modulation Specifications
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 6.4. Modulation specifications Product 06-MLD 06-DPL Nominal Wavelength 375 - 520 nm, 633 - 1064 nm Digital power modulation Modulation frequency DC - 10 MHz DC - 1 kHz Rise/fall time < 2.5 ns <... -
Page 37: Mechanical Specifications
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 6.5. Mechanical Specifications Laser Head dimensions 100 x 40 x 40 mm = 4 x 4.2 mm; 90 mm x 30 mm Fixation holes, Laser head Weight < 0.3 kg Mechanical Drawings 6.5.1. -
Page 38: Electrical Interfaces
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A 6.5.2. Key control box 06-01 Series Key control box, mechanical outline. Dimensions in mm [inches]. 6.6. Electrical interfaces All equipment connected to the system should be limited energy as described by IEC 61010:1. - Page 39 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Pin assignment Power supply connector on laser head Connector 2 pin Molex Function +12 V USB connector on laser head Connector USB-type, mates with connector mini-B. Function +5 V Not connected 0 V (GND) Laser head I/O –...
- Page 40 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Key box to laser head connector The pin configuration of the Molex connector on the laser head and the 15-pin D-SUB connector on the key control box is described in the table below.
- Page 41 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Remote Interlock Connector The laser is equipped with a remote interlock connector that prevents current flow through the diode when the circuit is open. After the remote interlock connector has been opened the laser will need to be reset by disconnecting from and then reconnecting to the power supply to start up the laser again or toggling the key switch.
-
Page 42: System States And Run Mode Descriptions
Standby can be reached intentionally by sending the ‘STOP’ command. While the laser is in the Standby state the enabled TECs are running, maintaining the lasers internal operating temperatures. The laser can be restarted, or turned ON, with the Cobolt Monitor software, by sending the ‘STARt’ command, the ‘AUTOstart:RESTart’... -
Page 43: Laser Run Modes And Settings
Warming up Cobolt 06-01 lasers are factory set to have no warmup, that is the ‘Warm Up Current’ is set to 0 mA and the ‘Warm Up Time’ is set to 0 seconds. Where applicable, the laser provides a fixed current for a fixed number of seconds. - Page 44 Constant power mode is designed to allow operation of the laser at a fixed output power. The user may input any power setting up to the nominal power. The specified performance of Cobolt 06-01 Series is only guaranteed at 100 % of nominal power.
- Page 45 Digital power modulation: Command modulation Power Modulation run mode in the Cobolt 06-Series can also be utilized to modulate the lasers by software commands in optional combination with external input signals. This part of the run mode is only accessible through software integration and not through the Cobolt Monitor user interface.
- Page 46 The voltage input will determine the ON level of the digital pulses. The power level of Cobolt 06-DPL lasers the exact threshold voltage may vary from laser to laser but is specified to be less than 10 % of the selected voltage range due to the power feedback loop. The modulation speed is not limited and can be used up to 1 kHz.
-
Page 47: Fault Descriptions
OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Current modulation Current modulation is intended for maximum modulation bandwidth, where modulation speed is more important than power accuracy. Digital current modulation Digital current modulation mode gives the user access to the full bandwidth, in this mode there is no optical feedback loop so the pulse shape of the 06-DPLs may vary. -
Page 48: Troubleshooting
Ensure the laser has adequate heat sinking. 2. Check the base plate temperature (this is displayed in the Cobolt Monitor™ software). If it is outside of the range 20-50 °C the laser may take longer to stabilize the temperature or be unable to do so. - Page 49 OWNERS MANUAL | Cobolt 06-01 Series | D0951-A Low power Check that the laser is in constant power mode (using the GUI or the ‘Laser:RUNMode ConstantPower’ command). 2. Check the power reading using the GUI or the ‘LASer:POWer:reading?’ command. Remove any connector from the modulation inputs socket on the key control box then restart the laser.
-
Page 50: Warranty And Maintenance
Warranty and Maintenance The Cobolt lasers should not be opened for any reason. The warranty will be void if any of the system units are opened. All laser parameters are set at the factory, and there are no adjustments required (other than those described in this manual for operating in different modulation modes and at different power levels). -
Page 51: Compliance (Cdrh Models Only)
All equipment must be mounted on a common ground plane, such as an optical table. If any part of the delivered equipment is replaced with a part not supplied by Cobolt or if the equipment is not properly grounded, the system may not conform to CE / CDRH compliance standards listed here. - Page 52 Our Locations Cobolt AB (Sales in Norway, Sweden, Finland and Denmark) Solna, Sweden Phone: +46 8 545 912 30 Fax: +46 8 545 912 31 E-mail: info@coboltlasers.com HÜBNER Photonics GmbH (Sales in Germany, Switzerland and Austria) Kassel, Germany Phone: +49 561 994 060-0...
