- Page 1 TUNDRA COLD STORAGE MONITORING User Guide Document Number: T0006940 - TUNDRA Document Version: Release Date: May 24, 2024...
-
Page 2: Table Of Contents
Digital Probe Operation ..................14 3.4.2 Analog Probe Operation ..................14 Basic Downlinks ......................15 Device Configuration with ATLAS ................17 Data converters ......................19 Safety Precautions ..................... 20 Compliance Statements ..................... 21 TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential Page 2 of 25... -
Page 3: Product Description
Offering versatile mounting options (refer to Table 1-1 and Table 1-2), TUNDRA sensors are can be deployed directly into a cold storage environment, or placed outside with a digital or analog probe wired in. -
Page 4: Specifications
1.2 Specifications TUNDRA specifications are listed in Error! Reference source not found.. The main sensing functions are described in the following subsections. Table 1-2: TUNDRA Specifications Parameter Specification Environmental Rating IP67 Enclosures and mounting Custom design by TEKTELIC Operating Temperature -40°C to 70°C... -
Page 5: Operating Instructions
You can find the commissioning keys inside the box. If you don’t have the box, please raise a ticket in our support portal and provide the Tcode and serial number on the tag placed on the device. Figure 2-1 TUNDRA Commissioning Keys... -
Page 6: Activation
2. Apply the magnet for 3-10 seconds while device is in state of network search (process is indicated by GREEN LED active blinking) 2.5 Default Configuration Table 2-1 lists the default reporting behaviour of TUNDRA. Reporting behaviour can be changed from default through OTA DownLink commands (see how to do it in Basic Downlinks section). -
Page 7: Reconfiguration
On event 2.6 Reconfiguration TUNDRA variants support a full range of OTA configuration options once the sensor has joined the network. Specific technical details are available in the corresponding TRM documents. All configuration commands need to be sent OTA during the sensor’s DownLink Rx windows. -
Page 8: Battery Replacement
1. Remove the battery cover by unscrewing the 4x Phillips head screws using a size #1 Phillips head screwdriver (see Error! Reference source not found.). TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential... - Page 9 3. Before reattaching the battery cover, ensure the proper orientation of the cover by placing the battery symbol next to the mounting feature.as seen in Figure 2-8. Figure 2-8 Proper Replacement Orientation of the Battery Cover TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide...
-
Page 10: Reset Function
0.3 Nm of torque. 2.10 Reset Function To physically reset TUNDRA perform same steps as to get in out of DEEP SLEEP state: 1. Place magnet against the enclosure at the magnetic activation site as shown in Error! Reference source not found.. - Page 11 JOIN ACCEPT. Unsuccessful Flash Every 8 s Green stops blinking; Red flashes network join after twice twice every 8 seconds during join 1 hour back-off to conserve power. TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential Page 11 of 25...
-
Page 12: Sensing Functions
3 Sensing Functions 3.1 Magnetic Sensor TUNDRA variants are equipped with a magnetic hall-effect sensor to address these purposes: 1. To wake the device from sleep as described in Section 2.4. 2. To put the device to sleep. 3. To reset the device. -
Page 13: Accelerometer Transducer
3.4 External Probe TUNDRA Probe variants can be ordered with the choice of either a digital reed switch or an analog thermistor. The default input mode (digital or analog) depends on whether a digital or analog Sensor variant was ordered. -
Page 14: Digital Probe Operation
The sensor FW can convert the measured probe voltage to temperature and report either the raw voltage or converted temperature. By default, the sensor reports probe temperature. The actual ADC output has a resolution of 0.61 mV. TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide... -
Page 15: Basic Downlinks
4 Basic Downlinks TUNDRA use a "tick" system for reporting data. Generally, the sensor will report most important data every tick. A tick can be measured in seconds. There are two sets of settings that must be configured in conjunction - "Core reporting tick in seconds"... - Page 16 "data": { "raw": "07 CE 03 67 00 CE 04 68 24", "fPort": 32, "tag_entry": 1998, "tagged_ambient_temperature": "20.6", "tagged_relative_humidity": "18.0" }, Example 2 "data": { "raw": "02 67 00 C8", "fPort": 10, "ext_probe_temperature": "20.0" }, TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential Page 16 of 25...
-
Page 17: Device Configuration With Atlas
5 Device Configuration with ATLAS To perform more configuration or read the data of TUNDRA device you can use TEKTELIC’s complementary service, ATLAS at www.atlas.tektelic.com. There are two ways to access ATLAS: 1) Using in Offline mode Figure 5-1 Login as offline mode... - Page 18 Figure 5-3 Login with Network server credentials Figure 5-4 Select TUNDRA Decoder, application and the device For more information follow this link https://support.tektelic.com/portal/en/kb/articles/kona- atlas TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential Page 18 of 25...
-
Page 19: Data Converters
TEKTELIC’s data converters conform to the LoRa Alliance Payload Codec Specification and can be used with any 3 party Network Server / Application Server that supports this specification. https://resources.lora-alliance.org/technical-specifications/ts013-1-0-0-payload-codec-api TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential Page 19 of 25... -
Page 20: Safety Precautions
7 Safety Precautions The following safety precautions should be observed for all TUNDRA sensor variants: • All installation practices must be in accordance with the local and national electrical codes. • Replace only with approved batteries (see Section 2.9). • The following sensor variants are intended for indoor use only: T0006779, T0007380. -
Page 21: Compliance Statements
8 Compliance Statements Federal Communications Commission: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. - Page 22 WARNING: This product can expose you to chemicals including lead, nickel, and carbon black, which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide...
- Page 23 Rx ....... Receive, receiver, etc. SW ......SoftWare TRM ......Technical Reference Manual Tx ........ Transmit, Transmitter, etc. UG ......User Guide UL ....... UpLink US ....... United States v ........Version TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential Page 23 of 25...
- Page 24 Network Server. In the TEKTELIC NS under the "advanced network settings" tab change the configuration of the "default channel mask" to reflect the number of channels used by the gateway used. TEKTELIC Communications Inc. T0006940-TUNDRA_UG_v3 User Guide Confidential...
- Page 25 Wijesinghe use only (non-IP67) as per CSA results. Corrected the default battery UL June 11, 2021 Obsolete Carter Mudryk interval for TUNDRA sensors to 1 hour. Corrected model T-code (T00006909 August 10, 2022 Released Shawn Morrison should be T00006906) • Updated to include only...
