- Page 1 XESS ION 5120 QUICK START GUIDE www.xess.energy...
-
Page 2: Box Contents
Due to the weight of the battery module, it is recommended that installation be carried out by at least two people. Use appropriate tools as necessary for installation. Part Box Contents Termination Plug Comms Cable M6 × 16 Bolt XESS ION 5120 Quick Start Guide - REV 001... - Page 3 Max. Qty of Modules 10 (50kWh) 6 (30kWh) Max. Continuous Current 625A 1250A IP Rating IP20 Weight 120 kg 90 kg Tools Cabinet 10 Utility Knife Cabinet 6 Insulated Gloves Goggles Drill XESS ION 5120 Quick Start Guide - REV 001...
-
Page 4: Minimum Clearance Requirements
Interface & Status LEDs There are LEDs on the front panel of XESS ION 5120 that indicate the battery state (Status, Error, and SOC). Letter Label Function Letter Label Function COMMS XESS One Comms SOC Indicator Battery Comms Out On/O Switch... - Page 5 Power Lug Torque: 15 N·m Inserting and Fastening the Modules Module Bolt Torque: 3 N·m Insert the Modules into the Cabinet XESS ION 5120 Quick Start Guide - REV 001...
- Page 6 Start at the Out Port of the first battery module. (This battery will be the Master Battery) OUT: To the next COMM: Battery Module To the XESS One PE Torque: 3 N·m Termination Plug Insert the termination plug into the "OUT" port of last battery in the chain.
- Page 7 Connecting to the XESS ONE Connect the DC power cables and comms cable between Master Battery and XESS One. Important Note The comms cable should be Cat 5 or greater. DC Breaker DC + Cable DC - Cable Comms Cable (≥Cat 5)
- Page 8 (Master to XESS One) Note: DC+ Cable A maximum of 64 XESS ION 5120 modules can be connected in parallel. 2. A combiner box with an appropriately rated DC Bus is needed to DC- Cable combine the DC power cabling from the parallel cabinets.
- Page 9 Thank you for choosing XESS. Your decision to trust our product means a lot to us. At XESS, our focus is on technical excellence. Our batteries are the result of rigorous engineering and precise craftsmanship, and we have invested heavily in ensuring that each battery delivers outstanding performance and reliability.
- Page 10 XESS Energy Pty Ltd View 2/75 Bluestone Circuit, Seventeen Mile Rocks, QLD +61 1800 950 865 sales@xess.energy www.xess.energy...
