- Page 1 CURTIS (C1 / C2) HIKERBOY ELECTRIC SCOOTER USER MANUAL...
-
Page 2: Table Of Contents
This manual contains the latest product information at the beginning of printing. Hikerboy will continue to pursue the improvement of product design and quality, and may update the product design at any time, which may lead to some inconsistencies between the manual and the real object without notice. -
Page 3: Safety Instructions
1. Safety Instructions 1. Please read this instruction manual carefully before riding, If the rider is inexperienced or does not use this product according to this manual, neither the manufacturer nor the seller is responsible for incidental damage or direct / indirect damage caused by the use of this product. 2. - Page 4 Others 1. Only parts and accessories designated or approved by Hikerboy can be used. Please do not modify your scooter. The modification of the scooter may affect the operation of the scooter and cause serious damage and void the limited warranty.
-
Page 5: Packing List
2. Packing List Mainframe User Materials User Manual Handlebar Accessories Battery Charger Hex Wrench Screws M5 × 6... -
Page 6: Function Diagram
3. Function Diagram LED Display Handlebar Front Brake Lever Accelerator Bell Power Rear Brake Lever Snap Hook Headlight Front Turn Signals Turn Signals Control Stem Quick-release Lever Folding Mechanism Footboard Front Fork Front Fender Buckle Rear Fender Front Drum Brake Taillight Charging Port Rear Disc Brake... - Page 7 Turn Signals Control Dashboard Speedometer Unit of Speed Bluetooth Speed Mode Headlight Walk Mode Error Turn Signals Press the two buttons respectively to toggle Battery Level the turn signal's left and right directions, then Power Button press again to turn it off. Speedometer: It displays the current speed of the scooter, as well as error codes.
-
Page 8: Vehicle Assemble
4. Vehicle Assemble 1. Turn the handlebar to a horizontal position and remove all 2. Rotate the handlebar until it is perpendicular to the wheels protective styrofoam blocks around the area. and stem, push the cables gently inside the tube, then move Hold the stem and close the quick-release lever until it is fixed on the handlebar slowly downwards until it sits perfectly inside. -
Page 9: Charging
5. Charging Each scooter is equipped with a charger. Do not charge your electric scooter with other brands of chargers. Be sure to switch off your scooter before charging. Always check for any abnormalities before charging the electric scooter. The charger indicator light is red when charging and turns green when charging is complete. Charging steps: Lift the cover of the Insert the charge plug to... - Page 10 3. Place one foot on the footboard while keeping the other on the 4. Put your other foot on the footboard to keep both feet stable. ground to keep your balance. Press the throttle to speed up when you are balanced. Then push off with the other foot to start gliding.
-
Page 11: Fold & Unfold
7. Fold & Unfold NOTE: You need to turn off the scooter before folding or unfolding. 1. Turn off the scooter. Hold the stem and open the quick-release lever 2. Lower the stem and press the top of the snap hook to attach it to by pushing the button up, then the lever down. -
Page 12: App Installation
8. App Installation Thanks to the Hikerboy application, you can control your electric scooter via Bluetooth from your smartphone: lights, speed modes, charge level, locker, mileage ... You can follow the performance of the scooter in real time, without creating a customer account. - Page 13 4. Now you can start riding and access the status by using the app. 3. The scooter is succes fully connected when the Bluetooth icon lights up. System Settings Vehicle Details Speed Settings 5. Select the ‘System Settings’ button to enter system settings. Select ‘Vehicle Details’...
-
Page 14: Warnings
9. Warnings Riding in the rain or water is Do not ride in motorized traffic. Do not ride up and down steps or prohibited. jump over obstacles. Do not carry another person. Hanging or transporting heavy No talking on the phone or objects is prohibited. - Page 15 Avoid hitting high obstacles such Do not pass through obstacles at Do not ride with one hand or one foot. as door frames. high speeds. It is prohibited to perform stunts. Do not accel rate while pushing forward. Do not touch the motor and disc Do not store in an environment lower brake area after riding.
-
Page 16: Maintenance
10. Maintenance Storage When not in use, please park the scooter indoors or inside the car to avoid damage caused by water ingress into the scooter in rain, snow and other harsh environments. The scooter needs to be stored in a cool, dry location. Please do not leave the scooter outdoors for a long time. Exposure to sunlight and extreme temperature conditions (too hot and too cold) will accelerate the deterioration of the plastic and may result in reduced battery life. -
Page 17: Specifications
11. Specifications Item Parameter Model Curtis (C1) Curtis (C2) Fold (length × width × height) 1138 × 570 × 525 mm Product Unfold (length × width × height) 1138 × 570 × 1225 mm Net weight 16 kg Max. load 100 kg Rider User age... -
Page 18: Troubleshooting
12. Troubleshooting Diagnosis of common anomalies Scenarios Possible Cause Most Common Solutions 1. Insufficient battery power 1. Charge the battery 2. Faulty connections 2. Clean and repair connections It doesn't work 3. Improper turn on sequence 3. Turn on the scooter with the proper sequence 4. -
Page 19: Certifications
Error messages If the electric scooter has a fault, the display screen will indicate the origin of the problem with one of the following codes: Code Possible Cause Common Solutions (for reference only) Short circuit fault Consult the dealer, replace parts if needed Instrument/controller communication failure Consult the dealer, replace parts if needed Accelerator failure... - Page 20 Batteries or packaging for batteries are labeled in accordance with European Directive 2006/66/EC and amendment 2013/56/EU concerning batteries and accumulators and waste batteries and accumulators. The Directive determines the framework for the return and recycling of used batteries and accumulators as applicable throughout the European Union. This label is applied to various batteries to indicate that the battery is not to be thrown away, but rather reclaimed upon end of life per this Directive.
-
Page 21: Trademark And Legal Statement
Yunyun Internet of Things and Technology (Suzhou) Co., Ltd. reserves the rights of their trademarks referred to in this manual. Please note that there are multiple Hikerboy models with different functions, and some of the functions mentioned herein may not be applicable to your unit. - Page 22 Warranty Card Name Model Number Serie Product Name Telephone Zip Code User Address Name Telephone Purchase Date Distributor Address Fault Date Fault Maintenance History NOTE: The serial number can be found under the electric scooter. Other Information Yunyun Internet of Things and Technology (Suzhou) Co., Ltd. Bldg.
- Page 24 ALPMARS SA 36 Boulevard Helvétique | 1207 Geneva | Switzerland Tel: +41(0)21 311 51 60 | www.hikerboyscooter.com | service@hikerboy.net...
