Please read carefully before use
The main body of the device generates some heat when the power is turned on. Normal use of the device will not affect the
human body or cause the device to catch fire.
Please pay attention to the following points when using the device.
-
Do not stack the main unit on top of each other.
-
Do not disassemble the main unit.
-
Do not disassemble the main body of the equipment.
-
Excessive dust may cause equipment failure.
Check Packaged Items
The product package contains:
Device
・
DIN rail mounting bracket
・
Wall mounting bracket (2pcs)
・
Screw (4pcs)
・
Model Definitions
Product Number
MGS-0800-TBB0
Product Panels
8 port Gigabit Ethernet Switching hub DC24V PoE/PSE
【MGS-0800-TBB0】
User's Manual
TP port
PoE/PSE port
8
Transmission rate
#1～#8
10/100/1000Mbps
Japan Telegaertner Ltd.
GUI-CNEJAN24-0091Ae
PoE power supply
80W＠DC+24V
Advertisement
Related Manuals for Telegärtner MGS-0800-TBB0
Summary of Contents for Telegärtner MGS-0800-TBB0
- Page 1 Japan Telegaertner Ltd. GUI-CNEJAN24-0091Ae 8 port Gigabit Ethernet Switching hub DC24V PoE/PSE 【MGS-0800-TBB0】 User’s Manual Please read carefully before use The main body of the device generates some heat when the power is turned on. Normal use of the device will not affect the human body or cause the device to catch fire.
- Page 2 LED Indication State color Description Green The power is supplied to the switch The power is not supplied to the switch Green The power is supplied to the switch The power is not supplied to the switch Green TP port link up RJ45 左...
- Page 3 <Installation work> Remove the terminal block from the device. Insert the harness into PW1 and PW2 (and the alarm output section if necessary). Attach the terminal block to the device. Ground the device using the ground connection screw. After turning on the DC power, check the indicator LED on the main unit. <Terminal block specification>...
- Page 4 Distance Max. 100m Grand 1 port Cable core 1 core Warranty 【Warranty period】 5 years 【Warranty process】 Send back ※Only for Japan. Please contact us for overseas transportation. The following cases will be handled for a fee. In addition, you will be charged for the cost of shipping the product back and forth. Warranty period has expired.
