- Page 1 User Manual H0300A Delegate / Chairman Unit Before using this system, please read this manual carefully...
- Page 2 Notification WARNING To ensure the reliability of the equipment and the safety of personnel, please observe the following when installing, using and maintaining: ● If any of the following conditions are found, please immediately turn off the power, plug out and quickly contact your nearest dealer.
- Page 3 ● This product uses a power plug or appliance input socket as a disconnecting device with the power supply, and must be disconnected if necessary for safety reasons. ● This equipment is only suitable for safe use at altitudes under 2000 meters. Precautions 1.
- Page 4 5. Agreement Please strictly follow the instructions in this manual. The software, hardware and appearance of this product will be upgraded and updated continually. The above changes will be made without notice. Non-professional maintenance personnel, do not remove the product, to avoid damage and electric shock.
-
Page 5: Table Of Contents
EATURE 2.2 P ....................- 6 - RODUCT FUNCTION INTRODUCTION 2.3 S ..........................- 7 - PECIFICATION 3. H0300A Instruction........................- 9 - 3.1. B ............................- 9 - 3.2. U ........................... - 9 - NIT TYPE 3.3. M ......................- 10 - EETING MANAGEMENT 3.4. -
Page 6: System Introduction
System introduction The wireless all-digital conference system adopts Heinrich’s original network communication and digital transmission processing technology with completely independent intellectual property rights. The digital technology and network technology are applied to the conference system products. The perfect combination of wireless wifi and wired all-digital makes new breakthrough in the conference field. -
Page 7: Product Function Introduction
capacitive buttons. Support clock display function. It can display date and time: year, month, day, hour, minute. With a 3.5mm stereo headphone jack and built-in speakers, and a volume adjustment function. Come standard with 6 large-capacity lithium batteries with a battery capacity of 12900mA/h, which can last for 15 hours of speech or work continuously for 24 hours. -
Page 8: Specification
Specification Model H0300A Microphone type Cardioid directional electret Frequency response 80Hz~16kHz Microphone input impedance 1KΩ Sensitivity -46 dBV/Pa Maximum SPL 100dB(THD>3%) >80dB(A) Crosstalk >70dB Dynamic range >80dB <0.1% Maximum power consumption Headphone load >16Ω Headphone volume Max 40mW Headphone jack 3.5mm mono jack... -
Page 9: Boot
Instruction 3.1 Boot Turn on the power of the controller to start the conference system, and the controller will display on the screen"System Loading...", The page is as follows: After the boot, the touch screen displays the LOGO interface; enter the home page after connecting to the controller network, the interface is as follows: 3.2 Unit type On the touch screen of the chairman unit, you can switch microphones, turn off all delegate... -
Page 10: Meeting Management
On the touch screen of the delegate unit, you can switch the microphone, switch between Chinese and English, and adjust the brightness. 3.3 Meeting management The microphone switch of the unit is controlled by the conference management, and its permission is configured by the conference controller. Refer to the controller's conference mode description for the logic of use. -
Page 11: Sign In
Press the priority button of the chairman unit to turn off the microphones of all delegate units. The chairman unit turns on the microphone delegate unit and the display is as follows: 3.4 Sign in The wired chairman machine or PC software initiates sign-in, and the corresponding light is on, and the display is as follows. -
Page 12: Vote
3.5 Vote The wired chairman unit can initiate 3-button voting for fixed options; PC software can initiate 3-button voting for fixed options, 5-button elections for fixed options, 5-button ratings for fixed options, and custom options 2/3/4/5 key elections. The display is as follows: The 3-button voting process for fixed options: 3-button voting for fixed options, press the button to display accordingly: The 5-button election process for fixed options:... - Page 13 5-button rating process for fixed options: The 5-button rating of the fixed options will be displayed when the button is pressed: Custom option 2/3/4/5 button election process: Custom option 2/3/4/5 button election, press the button to display correspondingly: - 12 -...
-
Page 14: Fire Alarm
3.6 Fire alarm When the controller sends a fire alarm message, the controller screen will display “Fire warning “Prompt, the red light of the microphone pole will flash until the controller cancels the fire alarm and the controller resumes its pre-alarm state. In the fire alarm, the button is invalid. 3.7 Menu page Enter the menu page as shown in the figure below. -
Page 15: Language Setting
backlight settings. 3.9 Language setting Click the language setting button to enter the Chinese-English switching page to switch the four languages of Chinese, English, Russian, French, and save when power off. The setting page is as follows: 3.10 System status page Click the system status button to enter the query system, the page is as follows: MAC address: wireless network card MAC address. -
Page 16: Screen Brightness Adjustment
3.11 Screen brightness adjustment Click the brightness adjustment button to enter the menu page, you can adjust the brightness of the machine, the adjustable range of brightness is 1 to 64, 64 is the maximum brightness. Support power-off memory. 3.12 Service application Participants can send "tea application", "paper and pen application", "manual service application"... -
Page 17: Wireless Ap Drop Detection Function
When the application item is selected, the software will prompt whether to send the application, if yes, send it, otherwise it will return. After sending the application, you can see the corresponding prompt on the PC, and the unit will also display the corresponding prompt. 3.13 Wireless AP drop detection function Turn off the wireless AP power for about 10 seconds, the interface will pop up the following dialog box. -
Page 18: Controller Offline Detection Function
3.14 Controller offline detection function Turn off the power of the controller or the controller network cable fails for about 60 seconds, the interface will pop up the following dialog box. If the controller works normally, the interface will return to the main page. 3.15 WIFI SSID and password modification In the boot state, the USB port of the wireless controller is connected to the PC. -
Page 19: Edit Id Function
3.17 Edit ID function After the controller presses the Edit ID, it enters the Edit ID mode. At this time, press the set button or press the microphone button to set the ID. 3.18 Speech countdown and speech timekeeping This function needs to be controlled by the conference PC software. For details, please refer to the PC operating instructions. -
Page 20: Charge, Battery Level, Wifi Signal Strength, Charging Mode Indication
In the speech timekeeping, the PC designates the unit for speech timekeeping, and the unit accounting displays the speech time. 3.19 Charge, battery level, WIFI signal strength, charging mode indication WIFI signal strength, a total of 4 white bars, no signal means no icon: There are 4 bars in full charge, the icon is: The icon of the charging plug is Fast charge mode:... -
Page 21: Automatic Low-Battery Shutdown
Custom message: 3.21 Automatic low-battery shutdown When the battery is too low, the wireless controller will automatically shut down after prompting the following picture. 3.22 Switch button function In the shutdown state, short press the button to turn on the system. In the power-on state, long press the button for 3s, system shutdown. -
Page 22: Quick Charge Mode Description
3.24 Quick charge mode description Type-C port supports USB Power Delivery (PD2.0/PD3.0) protocol, supports FCP/AFC/SFCP fast charge protocol. Compatible with BC1.2, Apple, Samsung mobile phone fast charge, etc. Appendix 1. Microphone frequency response curve 2. Microphone cardioid curve - 21 -...
