- Page 1 Base manual Arcade(BASE)
- Page 3 List of materials for the base package ① 6 metal bracket parts *Open both packages and check the quantity of all items Top part Console bracket Side part Side part Back part Bottom part...
- Page 4 ② Accessories box: 6x50mm screw x 16, 6x30mm screw x 8, Phillips screwdriver x 1, USB cable x 4, 6-inch cable tie x 12, 10-inch cable tie x 25 6x50mm 6x30mm Phillips screwdriver screw（x 16） screw（x 8） 6-inch cable tie（x 12） 10-inch cable tie（x 25）...
- Page 5 List of materials prepared before installation Installation preparation:6 metal bracket parts * Please read the installation manual carefully Top part Console bracket Side part Side part Back part Bottom part...
- Page 6 Preparing accessories for installation 6x50mm screw x 16, 6x30mm screw x4, Phillips screwdriver x 1, Storage basket x 2, Floor Protector Mat x4 (in 2009-1P/2009-2P box) Storage baskets（x2） Floor Protector Mat(2) 6x50mm 6x30mm Phillips screwdriver screw（16） screw（x 8）...
- Page 7 Installed base Step 1: Screw the 4 floor protector mat (G) into the bottom of the 2 side parts (B). Clockwise tightening...
- Page 8 Step 2: Lay the back part (A) flat on the floor. back part...
- Page 9 Step 3: Connect the back part (A) and side part (B) and tighten the 6x50mm screws (F) to 80%, not completely. Clockwise tightening...
- Page 10 Step 4: Repeat Step 3 to install another side part (B), Clockwise tightening...
- Page 11 Step 5: Install the top part (C) and tighten the 6x50mm screw (F) to 80%, do not tighten it completely. Clockwise tightening...
- Page 12 Step 6: Install the console support (D) and tighten the 6x50mm screw (F) to 80%, not completely. Clockwise tightening...
- Page 13 Note: The arrow of the sticker is directed towards the indicator, and the front side has a collision avoidance sticker. Please follow the diagram with the jack facing up and the large hole facing out.
- Page 14 Step 7: Install the bottom part (E) and tighten the 6x50mm screw (F) to 80%, not completely. Clockwise tightening...
- Page 15 * The bottom component (E) can be installed in different positions according to your needs...
- Page 16 Step 8: Tighten all the 6x50mm screws (F)(x16) on the base. Clockwise tightening...
- Page 17 Step 9: Flip the entire base...
- Page 18 Step 10: Adjust the height of the Floor Protector Mat(G) to balance the base horizontally.
- Page 19 Step 11: Tighten the four 6x30mm screws (Q) to 80%. Do not tighten completely. Clockwise tightening...
- Page 20 Step 12: Hang the storage basket (J) on 4 screws to completely tighten 4 6x30mm screws (Q) Clockwise tightening...
