- Page 1 CONDO AIR HOCKEY INSTALLATION MANUAL rev 2023-07-05 CANADA BILLIARD & BOWLING INC. 4050 Industriel blvd, Laval, QC, H7L 6C3 450-963-5060 W W W.CANADABIL LIARD.COM...
-
Page 2: Lifetime Guarantee
LIFETIME GUARANTEE CANADA BILLIARD is pleased to offer an unsurpassed LIFETIME GUARANTEE TO THE ORIGINAL PURCHASER against defects in material and workmanship, provided installation and/or service is performed by an Authorized Dealer or a factory-approved installer. Cloth, pockets and rail cushions are not covered under this guarantee. - Page 3 CONDO AIR HOCKEY...
- Page 4 1 Unwrap legs and unscrew leg levellers for about 1/2”. 2 Install the 3/8”-16 x 3” full threaded rods into legs. 3 Install the dowel pins at the end of side sills and at 4 Fasten the end sills to the legs with flat washers the ends of end sills.
- Page 5 7 Install the surface support on the crossmembers 8 Fix the supports to the crossmembers using the #8 1 alligning them to the dowels. The cut corners on the 1/4" flat headed wood screws. At his point, the supports goes next to the legs. wood screws's head MUST be flush to the plywood.
- Page 6 Making sur that the rails are perfectly aligned with 14 Secure the machines screws. the frame of the table, use the #8 2" rounded head. This operation will ensure a flat playing surface. 15 Fix goals with 1 1/2" machine screws and 5/16" flat After removing the plastic protector from underneath surface, fix the blower under the surface with washers.
- Page 7 YOU ARE NOW READY TO PLAY YOUR FIRST GAME OF AIR HOCKEY ON YOUR MAGNIFICENT TABLE FROM CANADA BILLIARD ! CONGRATULATIONS ! CANADA BILLIARD & BOWLING INC. 4050 Industriel blvd, Laval, QC, H7L 6C3 450-963-5060 W W W.CANADABIL LIARD.COM...
