Instruction Manual
UPSOTEC 2440
1. General ...................................................................................................................... 2
1.1
General Safety Instructions ..........................................................................................................2
1.2
Short description ...........................................................................................................................3
1.3
Intended Use ................................................................................................................................3
2
Transportation and Storage .................................................................................... 4
3
Installation and Connection .................................................................................... 4
3.1
Installation .....................................................................................................................................4
3.2
Dimensions UPSOTEC 2440 .......................................................................................................4
3.3
Dimensions DIN-Rail ....................................................................................................................5
3.4
Connection ....................................................................................................................................5
3.5
Circuit Diagram .............................................................................................................................7
4
Operation .................................................................................................................. 8
4.1
Mains Operation ...........................................................................................................................8
4.1.1
Final Charging Voltage Battery ...................................................................................... 8
4.1.2
Battery Aging .................................................................................................................. 9
4.1.3
ESR Monitoring .............................................................................................................. 9
4.1.4
Capacitor Modules (UC-Modules) .................................................................................. 9
4.2
Back-up Operation .......................................................................................................................10
4.2.1
Shut-down Terminal (SH-terminal) ............................................................................... 10
4.2.2
Umin ............................................................................................................................. 10
4.2.3
Back-up time................................................................................................................. 11
4.2.4
IPC ................................................................................................................................ 11
4.3
Status Display ..............................................................................................................................12
4.4
Control Input ................................................................................................................................13
5
Maintenance ............................................................................................................. 15
5.1
Battery exchange .........................................................................................................................15
6
Putting out of operation .......................................................................................... 15
7
Disposal ................................................................................................................... 15
8
Technical Data ......................................................................................................... 16
9
Norms and regulations ........................................................................................... 17
10 Error Elimination ..................................................................................................... 18
Snaptec Australia Pty. Ltd.
Email: sales@snaptec.com.au
DC-UPS
NBUA1531Gxxxx
https://www.snaptec.com.au
Seite
1/18
Advertisement
Table of Contents
Related Manuals for Snaptec Australia UPSOTEC 2440
Summary of Contents for Snaptec Australia UPSOTEC 2440
-
Page 1: Table Of Contents
General Safety Instructions ......................2 Short description ...........................3 Intended Use ..........................3 Transportation and Storage ..................4 Installation and Connection ..................4 Installation .............................4 Dimensions UPSOTEC 2440 .......................4 Dimensions DIN-Rail ........................5 Connection ............................5 Circuit Diagram ..........................7 Operation ........................8 Mains Operation ...........................8 4.1.1... -
Page 2: General
In case of error we recommend to send the unit back to the manufacturer. NOTICE The unit must be operate with a corresponding pre-fusing. NOTICE The energy storage must be operated with a corresponding pre-fusing. Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 2/18... -
Page 3: Short Description
The UPSOTEC is designed and developed for the industrial and plant engineering sector. The installation of the UPSOTEC is to be carried out exclusively by qualified electricians. If the UPSOTEC is operated outside of its intended use, the protection supported by the UPSOTEC cannot be guaranteed Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 3/18... -
Page 4: Transportation And Storage
The unit is a built-in unit. The operation is only permissible in closed cabinets of housings. The unit is designed for pollution degree 2. NOTICE Please observe the maximum admissible load of your top hat rail corresponding to EN 60715 ! Dimensions UPSOTEC 2440 Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 4/18... -
Page 5: Dimensions Din-Rail
Dimension the cable cross section of the supply and output cables according to EN 62368-1 table G.5; see also table above. If the system is installed in accordance with EN 62368-1 and supply lines leave the room (building wiring), ob- serve section 6.5.3 of EN 62368-1 Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 5/18... - Page 6 In case of non-observance risk of strong heat generation, which may cause severe burns! WARNING Only SELV or PELV voltage sources are permitted for supplying the device. Failure to observe this may result in electric shock with fatal consequences Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 6/18...
-
Page 7: Circuit Diagram
LED Operation Geräte Status Device status LED Battery Akku Status accu status Shutdown Eingang Batterie Fehler Netzausfall Shutdown input Battery error Mains failure BAT ok Uin OK Uin OK Bat OK Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 7/18... -
Page 8: Operation
Operation The UPSOTEC 2440 is connected between the DC supply and the load. If the input voltage exceeds 22,5 V DC, the unit is ready for operation and displays this status with the illumination of both LEDs and the tightening of the message contact „U... -
Page 9: Battery Aging
In UC mode, the battery checks and the temperature-controlled charge end voltage are disabled and the capac- itors are charged from 0V. The PC software are used to configure additional parameters such as the final charg- ing voltage and the deep discharge voltage Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au... -
Page 10: Back-Up Operation
Min discharge voltage The load is buffered until the adjusted final deep discharge voltage. The threshold can be adjusted with the PC software „TECControl“. (factory setting: 19,8 V ± 2%). This operation is always preferential. Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au... -
Page 11: Back-Up Time
PC software (factory setting: 48sec.) NOTICE If the minimum discharge current is reached before another shutdown incident occurs, the back-up is aborted to protect the accumulator against deep discharge. Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 11/18... -
Page 12: Status Display
No battery Mains failure Mains failure Keine voltage Einschaltvorgang Switch on Netzausfall Netzausfall Batteriespg. Behavior message contact ‚Bat OK‘ Ubat Bat ok Einschaltvorgang Keine Switch on ESR error No battery Fehler Batteriespg. voltage Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 12/18... -
Page 13: Control Input
Power switch off delay at SH-Pin (Back-up)buffer time min. discharge voltage operation mode: Umin operation mode: (Back-up) buffer time operation mode: IPC operation mode: Shutdown pin (SH) Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 13/18... - Page 14 Exceeding the counter of the operation hours of the battery is signaled via message contact and LED.. Operation options: signal Lifetime Bat. Activation of the accelerated temperature dependent counter of battery operation hours. Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au...
-
Page 15: Maintenance
This symbol indicates, that the device must not be disposed with the normal domestic waste. Please dispose the product professionally as electronic scrap. Herewith materials are separated and recycled according to their qualities and you contribute in environmental protection. Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au... -
Page 16: Technical Data
Max. mounting height (without load reduction) 2000 m above sea level Dimensions (H x W x D) 123 mm x 85 mm x143 mm (±0,5mm) Weight appr. 0,8 kg Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 16/18... -
Page 17: Norms And Regulations
EN 61000-4-2 (ESD) EN 61000-4-3 (EM - fields) Noise immunity EN 61000-4-4 (Burst) EN 61000-4-5 (Surge) EN 61000-4-6 (Induced HF-fields) EN 61000-4-8 (Magnetic fields) EN 60068-2-6 (vibrations (sin)) Mechanical Test EN 60068-2-27 (Shocks) Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 17/18... -
Page 18: 10 Error Elimination
10 Error Elimination Error Note The UPS must be reset: Switch the device voltage- No output voltage present after a short-circuit free for approximately 20s. (separate supply U and U from the unit) Snaptec Australia Pty. Ltd. Email: sales@snaptec.com.au https://www.snaptec.com.au 18/18...
