- Page 1 POWER DISTRIBUTION UNIT PD14PMiD Single and Dual Input 14 Output Mains Distribution Units. Handbook TSL Products Limited. Unit 1-2, First Avenue, Globe Park, Marlow, Buckinghamshire, SL7 1YA Telephone +44 (0)1628 564610, support@tslproducts.com...
- Page 2 This Page is Blank PD14PMiD Handbook Issue 1.0 March 2024...
-
Page 3: Table Of Contents
WARRANTY, MAINTENANCE AND REPAIR ....................6 Installation............................. 7 Description ..........................8 Introduction ..........................9 Operation (Front Panel) ......................10 4.1. Input A/B select (PD14PMiD-CO) ......................11 4.2. LCD Menu Structure..........................13 4.3. Monitoring modes ..........................13 4.3.1. Home page ............................13 4.3.2. - Page 4 This Page is Blank PD14PMiD Handbook Issue 1.0 March 2024...
-
Page 5: Safety Information
Hazardous voltage exposure is possible. Do not operate in wet/damp conditions. Be aware that condensation may occur if a unit is moved from a cold to a warm environment. Do not operate in an explosive atmosphere. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 6: Warranty, Maintenance And Repair
WARRANTY, MAINTENANCE AND REPAIR All TSL equipment is guaranteed for one year from the date of delivery to the customer’s premises. If the equipment is to be stored for a significant period, please contact TSL concerning a possible extended warranty period. -
Page 7: Installation
It is recommended that any branch circuit protection device is rated at 125% of the maximum continuous load current. Unless otherwise stated TSL equipment may be installed at any angle or position within an ambient operating temperature range of 5° ~ 30° C . -
Page 8: Description
Power Distribution Unit - PD14PMiD Description Part Number Definitions: PD14PMiD-32A 32 Amp Power Distribution Unit with output monitoring & SNMP alarms over IP networks. PD14PMiD-20A 20 Amp Power Distribution Unit with output monitoring & SNMP alarms over IP networks. PD14PMiD-CO-32A 32 Amp Dual input Power Distribution Unit with auto-failover, manual changeover, SNMP changeover with output monitoring &... -
Page 9: Introduction
Introduction The PD14PMiD is a 14-output power distribution unit with either single or dual inputs, intended for racks where equipment needs a constant uninterrupted Mains power supply. This 1RU unit is designed to fit into a rack in any position. The inlets are via Neutrik powerCON connectors, and cable mounted connectors are supplied free with each unit. -
Page 10: Operation (Front Panel)
100% of current load reached or exceeded Input Over Current Protection The PD14PMiD includes an over current protection feature that will automatically switch off the selected input relay should the following input current thresholds be breached: Input current between 100 – 110% for 10 minutes... -
Page 11: Input A/B Select (Pd14Pmid-Co)
LED shows that the LAN is connected and active, while LED OFF indicates the loss of LAN connection. 4.1. Input A/B select (PD14PMiD-CO) The tricolour LEDs A (left) & B (right) above the POWER SELECT buttons show 3 states: GREEN –... - Page 12 Release the Active Input A or B button before 7 seconds (after LCD blanks) to avoid a Hardware reset and the associated output interruption. However, if the Active Input A or B button is pressed for longer than 7 seconds, the unit will perform a hardware reset with default Config parameters. PD14PMiD Handbook Issue 1.0 March 2024...
-
Page 13: Lcd Menu Structure
Monitoring modes 4.3.1. Home page Network Settings Allows the unit’s IP settings to be configured. Unit Information Gives an overview of the unit’s attributes, such as its MAC address, Serial Number, Firmware and Boot versions. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 14: Output
The output will now switch OFF. The output indicator will turn off to show this as will the front and rear output LEDs To switch the output on again follow the above procedure highlighting ON then SET. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 15: Temperature Monitoring
On this page, the voltage of the active input and the sum of the current load for all outputs are displayed. Display brightness can also be adjusted in this mode, as indicated by the icon on the top right corner. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 16: Operation (Web User Interface)
‘Outputs’ or ‘Inputs’ for example. The default login credentials are the following: The Username is root The Password is telsys These can be changed after the first successful login using the ‘Change Password’ menu. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 17: The Home/Status Page
Watts, VA, and current in amps with the power factor. To navigate back to the Home page from any other webpage, click on the Home link or the TSL Logo at the top left of screen. 5.3. -
Page 18: Outputs Page
The Hard Reset button will perform a complete reboot and restart the unit completely. Soft Reset: Resets the CPU only. Outputs remain latched to their ON/OFF states. Hard Reset: Reboots the whole system as from a power off state. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 19: System Page
5) The input voltage breaks the upper or lower threshold values as set on the System page. Click on APPLY when done. NB: Allow the page to refresh before clicking on the READ button to read back the modified settings. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 20: Status Page
Output 5 is switched OFF • Output 6 showing an under current • Alarm The Status page also includes a reset function for the Cumulative Active Power measurement to return the value to 0.0 if required. PD14PMiD Handbook Issue 1.0 March 2024... -
Page 21: Charts Page
Neutrik powerCON connector – L – Brown (Phase), N – Blue (Neutral), E – Green/Yellow (Earth or Ground). GPI & Sensor Connector RJ45 GPI & SENSOR CONNECTOR RJ45 SOCKET RS422/485+ GPI2 RS422/485- GPI3 GPI1 One Wire 1 PD14PMiD Handbook Issue 1.0 March 2024... -
Page 22: Specification
Depth: 364.0mm (14.3”) Weight 2.85kg (approx.) Colour TSL Blue (RAL-5011) M6 bonding stud on rear panel adjacent to inlet connector(s) M6 bonding stud on rear cable support arm (right side). Earth Bonding All panels are bonded to primary ground point on chassis top panel (internal) - Page 23 (e.g. 10A/13A/16A). 1x LAN LED on front panel above USB connector = No network connected LAN Indicator Green = Network connected (will flicker based on activity) (Front) << Continued on the next page… >> PD14PMiD Handbook Issue 1.0 March 2024...
- Page 24 2x LEDs labelled ‘Ethernet’ on RJ45 connector on rear panel Indicators Green = Connected / Orange = Activity on network (Rear) 2x LEDs labelled ‘Sensor Link’ on RJ45 connector on rear panel not used – Orange LED will be lit in normal operation PD14PMiD Handbook Issue 1.0 March 2024...
-
Page 25: Tsl Snmp Mibs
This is a fail-safe method should only ever trigger changeover if the CPU has failed Method TSL SNMP MIBs The Unit generates SNMP trap alarms (.1.3.6.1.4.1.6853.2) to the IP addresses configured in the SNMP setup web page when the following events occur: A GPI input changes state. - Page 26 TSL Control Settings + Status Values TSL MIB String Name Value Type, Set and/or Get .1.3.6.1.4.1.6853.3.1 Equipment alarms description String (e.g. "PD14PM-iD-xx-V1.03") - (get) and version. .1.3.6.1.4.1.6853.3.2 MDU power-on output sequence Integer { simultaneous(1), sequential(2), delayed(3) } - (get + set) .1.3.6.1.4.1.6853.3.3...
-
Page 27: Unit Upgrade
PS_ACTIVE_INPUT_AB_OFF PS_ACTIVE_INPUT_AB_A_ON PS_ACTIVE_INPUT_AB_B_ON Unit Upgrade Firmware updates for the PD14PMiD may be available from time to time. The unit can be upgraded using the USB port on the Front Panel following the procedure below. Contact https://tslproducts.com/support/ for information on the latest Firmware versions. -
Page 28: Upgrading The Unit - Method 2
Select the unit information screen front panel menu and check the Firmware version matches the expected upgrade version. Alternatively, connect to the unit’s web interface Home page and check the Firmware version matches the expected upgrade version. PD14PMiD Handbook Issue 1.0 March 2024...
