TECWELD MIG 200HD Operating Manual

Inverter synergic semi-automatic welding machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V1.4 14.09.21
OPERATING MANUAL
INVERTER SYNERGIC
SEMI-AUTOMATIC
MIG 2OOHD WELDING MACHINE
ATTENTION!
Before installation and start-up of the device, please read this manual
1. GENERAL NOTES
Start-up and use of the device may only be performed after carefully reading this User's Manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIG 200HD and is the answer not in the manual?

Questions and answers

Related Manuals for TECWELD MIG 200HD

Summary of Contents for TECWELD MIG 200HD

  • Page 1 V1.4 14.09.21 OPERATING MANUAL INVERTER SYNERGIC SEMI-AUTOMATIC MIG 2OOHD WELDING MACHINE ATTENTION! Before installation and start-up of the device, please read this manual 1. GENERAL NOTES Start-up and use of the device may only be performed after carefully reading this User's Manual.
  • Page 2 Due to the continuous technical development of the device, the external appearance and some of its functions may be modified and their operation may differ in details from the descriptions in the manual and on the carton. This is not a device error, but the result of progress and continuous modification of the device. The standard equipment of the device may also change.

  • Page 3: General Description

    3. GENERAL DESCRIPTION Synergistic MIG 200HD welder is used for manual welding of steel and non-ferrous metals. It enables welding with MMA (coated electrode), TIG Lift and MIG / MAG methods in synergic and manual mode. Thanks to the change of polarity, the device allows welding with the MIG / MAG method using both standard wires in a protective gas shield and self-shielding flux-cored wires.

  • Page 4: Technical Parameters

    4. TECHNICAL PARAMETERS 4.1. Welding machine Supply voltage: AC 230V 50Hz Maximum power consumption: 6.6 kVA Rated welding current: / MIG duty cycle : 200A / 45%; MMA: 180A / 60%; TIG: 180A / 60% Nominal voltage in no-load condition 65 V Diameter of wire spools: 100mm, 200mm...
  • Page 5 Maximum current load: 200 A (CO Type of cooling: Cooling gas flow: 10-18 l / min Length: Work cycle The work cycle is based on a 10-minute period. Duty cycle of 45% means that after 4.5 minutes of operation, a 5.5-minute break is required.

  • Page 6: Preparing The Device For Work

    5. PREPARING THE DEVICE FOR WORK If the device is stored or transported in frost, before starting work, bring the device to a temperature above zero.
  • Page 7 7. Power switch 1. Control panel 8. CableThe 2. Remote control / Spool Gun 9. Shielding gas connector connector socket 3. MIG 10. Fan 4. Polarity change plug 11. Wire spool pin 5. "+" 12. Spool Gun switch 13. Wire socket 6.
  • Page 8 DCEP DCEN 5.1.2 TIG method For welding with this method it is necessary to use an additional TIG torch. A gas cooled torch with 200A amperage and a shielding gas control valve is required. The torch's current clamp should be connected to the negative polarity socket (6), and the gas hose to the regulator on the gas cylinder.
  • Page 9 of polarity reversal (4) into socket (5). The negative pole of the source (6) should be connected to the work piece by means of a wire with a clamp. Set the switch (12) inside the feeder chamber to the standard MIG gun position ( .
  • Page 10 1. The device should only be used in a single-phase, three-wire system with an earthed neutral point. 2. The MIG 200HD inverter rectifier is adapted to work with a 230V50 Hz network, protected by 25 A fuses with time-delayed action. The power supply should be stable, without voltage drops.

  • Page 11: Operation

    5.5 Preparing the MIG torch to work Depending on the type of material to be welded and the diameter of the electrode wire, attach a suitable contact tip and a wire guide to the MIG torch. For welding steel, use contact tips for welding steel and a steel insert. When welding aluminum, use contact tips for aluminum welding and a Teflon insert.
  • Page 12 button is used to select the welding method. Pressing the button briefly changes the method. The lit LED indicates the currently selected welding method. During MIG welding, pressing the button for 3 seconds will return to the initial parameters. C - Inductance adjustment / loading button for settings Press 3s to load Short press of the button will switch to inductance adjustment by means of the knob (D).

  • Page 13: Parameter Settings

    Press 3s to save The button is active only during MIG / MAG welding. It is used to select the welding mode control mode (two-stroke / four-stroke) and save the settings. Pressing the button briefly selects the device control mode. The selected control mode is confirmed by lighting up the corresponding LED.
  • Page 14 After switching the device on, it is possible to use the knob (D) to synergistically select the voltage and the corresponding welding current. The wire feed speed will be automatically adjusted to the set welding current. After initial setting of these parameters, manual correction of both welding voltage and current is possible. The transition between the adjustable parameters is done by pressing the knob (D).
  • Page 15 deformation and problems in the welding process. • Make sure the feed rollers are not too tight. Excessive wire tension may cause a feed problem. • Make sure the handle is equipped with a Teflon guide liner designed for aluminum. Using steel components used to feed the steel wire will cause feed problems.
  • Page 16 10.3 MIG / MAG method 1. Move the holder closer to the welded elements so that the distance between the nozzle and the welded elements is approx. 10 mm. 2. Press the button on the welding torch and start welding. 11.
  • Page 17 0.8.0.9 0.8.0.9 17．5 0.8.0.9 18．5 ～ 1.0.1.2 19．5 1.0.1.2 1.0,1.2 thickness diameter Torch current voltage speed Free flow Sheet Wire tilt Welding Welding Welding outlet (cm / min) electrode (°) （l/ min） （mm） （mm） （A） （V） （mm） 0.8,0.9 70 ～ 80 17 ～...
  • Page 18 0．8 0.8,0.9 60 ～ 70 16 ～ 17 40 ～ 45 10 ～ 15 0.8.0.9 80 ～ 90 18 ～ 19 45 ～ 50 10 ～ 15 0.8 , 0.9 90 ～ 100 19 ～ 20 45 ～ 50 10 ～ 15 speed 0.8,0.9 100 ～...
  • Page 19 Wrong diameter Insert the correct guide roller guide Dirty wire guide in the holder Clean the electrode wire guide Blocked electrode wire in Irregular feed of Damaged contact tip a Replace the contact tip the electrode feed roll groove is dirty or Clean the roll groove or replace the roll damaged Spool of wire rubs against the walls of...

  • Page 20: Maintenance Instructions

    MIG 200HD welder should be operated in an atmosphere free from corrosive components and large dust. Do not place the device in dusty places, near working grinders, etc. Dust and contamination with metal filings on control boards, wires and connections inside the device may lead to an electric short circuit and, consequently, damage to the welding machine.

  • Page 21: Warranty

    In the event of a warranty repair, please contact TECWELD, which will arrange for the device to be picked up by a courier company. Shipments sent in any other way at the expense of TECWELD will not be accepted! The welder must be delivered with the welding torch.
  • Page 22 Krzyżowa 1G POLAND We declare that the following product: Inverter welder Type: MIG 200HD The manufacturer's trademark: to which this declaration relates, meets the requirements of the following European Union directives and national regulations implementing these directives: Low Voltage Directive LVD 2014/35 / EU...
  • Page 23 and complies with the following standards: PN-EN IEC 60974-1: 2018-11 / A1: 2019-06 arc welding equipment - Part 1: Welding energy sources , PN-EN 60974-10: 2014-12 arc welding equipment - Part 10: Requirements for electromagnetic compatibility (EMC), PN-EN IEC 63000: 2019-01 Technical documentation for the assessment of electrical and electronic products with regard to substance restriction dangerous.
