Quick Installation Guide
Outdoor Wi-Fi Camera
CT3/CT4/CT5/CT6/CT7/CT8/CT9
This guide instructs how to install and connect the device. For more information, such as the description of symbols displayed
on relevant materials, please visit www.tendacn.com or scan the Product Documents QR code of this guide.
The CT6 is used for illustration unless otherwise specified.
The product name and model are specified on the label of the device.
Package contents
Camera x 1
Anchor x 3
(Height: 6.6 mm, Inner diameter: 2.4 mm, Length: 26.4 mm)
Waterproof kit x 1
Power adapter x 1
Screw x 3
(BA3 x 25 mm, Head diameter: 6.0 mm)
Quick installation guide x 1
Installation template x 1
Advertisement
Table of Contents
Related Manuals for Tenda CT3
Summary of Contents for Tenda CT3
- Page 1 Quick Installation Guide Outdoor Wi-Fi Camera CT3/CT4/CT5/CT6/CT7/CT8/CT9 This guide instructs how to install and connect the device. For more information, such as the description of symbols displayed on relevant materials, please visit www.tendacn.com or scan the Product Documents QR code of this guide.
- Page 2 Appearance LED indicator IR lights Spotlights Microphone Micro SD card slot (Behind the cover) Reset button (Behind the cover) Speaker Ethernet port Orientation knob Power port LED indicator Solid red: Initializing and starting. Blinking red slowly: Disconnected from a 2.4 GHz Wi-Fi network. Blinking red quickly: Connecting to a 2.4 GHz Wi-Fi network.
- Page 3 Add the camera to TDSEE App Before adding your camera, ensure that the router is connected to the internet successfully and the filter function is disabled. 1. Download the TDSEE App onto your mobile device by searching for TDSEE in the Google Play or App Store or by scanning the QR code.
-
Page 4: Install The Device
Install the device Install the camera The camera supports ceiling and wall mounting. (1) Please make sure the ceiling is strong enough to withstand three times the weight of the camera. (2) You may need a hammer drill, a drill bit, a rubber hammer, a screwdriver, and a ladder for the installation. (3) The camera is suitable for mounting at heights >2m. - Page 5 Adjust the monitoring angle Loosen the orientation knob, adjust the orientation of the camera as required, then tighten the knob. 0 – 360 ° 0 – 90 °...
- Page 6 Install waterproof kit Install the waterproof kit for the Ethernet port if the camera is installed outdoors. The included waterproof kit is not suitable for the Ethernet cable with protection cover on the crystal head. See the example on the right. When the Ethernet port of the camera is connected to an Ethernet cable, the waterproof installation steps are as follows.
- Page 7 Q1: What should I do if I failed to add the camera? A1: Try the following solutions: Ensure that the router is connected to the internet successfully. The camera only supports 2.4 GHz Wi-Fi network. When adding the camera, you need to connect the smartphone to a 2.4 GHz Wi-Fi network.
- Page 8 Q4: How to get full-color monitoring video through the camera no matter in the daytime or at night? A4: Set Night Vision Mode of the camera to Full-color Mode. Method: Run the TDSEE App, choose the camera on the Home page, then tap Settings （ in the upper right corner ）...
-
Page 9: Ce Mark Warning
(2) To avoid unnecessary radiation interference, it is recommended to use a shielded RJ45 cable. Declaration of Conformity Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the device is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.tendacn.com/download/list-9.html... - Page 10 El texto completo de la declaración UE de conformidad está disponible a través de la siguiente URL: https://www.tendacn.com/download/list-9.html Čeština ZJEDNODUŏENÉ EU PROHLÁŏENÍ O SHODč Tímto SHENZHEN TENDA TECHNOLOGY CO., LTD. prohlašuje, že zařízení je v souladu se směrnicí 2014/53/EU. Úplné znĎní EU prohláŐení o shodĎ je k dispozici na této internetové adrese: https://www.tendacn.com/download/list-9.html Deutsch VEREINFACHTE EU-KONFORMITÄTSERKLÄRUNG...
- Page 11 Português DECLARAÇÃO UE DE CONFORMIDADE SIMPLIFICADA Por este meio, a SHENZHEN TENDA TECHNOLOGY CO., LTD. declara que o dispositivo está em conformidade com a Directiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet: https://www.tendacn.com/download/list-9.html...
- Page 12 Ελληνικά ΑΠΛΟΠΟΙΗΜΕΝΗ ΔΗΛΩΣΗ ΣΥΜΜΟΡΦΩΣΗΣ ΕΕ Με το παρόν, η SHENZHEN TENDA TECHNOLOGY CO., LTD. δηλώνει ότι η συσκευή συμμορφώνεται με την Οδηγία 2014/53/ΕΕ. Το πλήρες κείμενο της δήλωσης συμμόρφωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα στο διαδίκτυο: https://www.tendacn.com/download/list-9.html Magyar EGYSZERŰSÍTETT EU-MEGFELELŐSÉGI NYILATKOZAT Ezennel a SHENZHEN TENDA TECHNOLOGY CO., LTD.
-
Page 13: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 14: Precauciones De Seguridad
Do not use the power adapter if its plug or cord is damaged. If such phenomena as smoke, abnormal sound or smell appear when you use the device, immediately stop using it and disconnect its power supply, unplug all connected cables, and contact the after-sales service personnel. Disassembling or modifying the device or its accessories without authorization voids the warranty, and might cause safety hazards. -
Page 15: Précautions De Sécurité
Halten Sie das Gerät von Wasser, Feuer, hohen elektrischen Feldern, hohen Magnetfeldern sowie brennbaren und explosiven Gegenständen fern. Ziehen Sie bei Gewitter oder wenn das Gerät längere Zeit nicht benutzt wird, den Netzstecker und trennen Sie alle Kabel Verwenden Sie den Netzadapter nicht, wenn sein Stecker oder Kabel beschädigt ist. Wenn bei der Verwendung des Geräts Phänomene wie Rauch, abnormale Geräusche oder Geruch auftreten, beenden Sie sofort die Verwendung des Geräts und trennen Sie es von der Stromversorgung, ziehen Sie alle angeschlossenen Kabel ab und wenden Sie sich an das Kundendienstpersonal. - Page 16 Non utilizzare il dispositivo in un luogo in cui i dispositivi wireless non sono ammessi. Si prega di utilizzare l'adattatore di corrente incluso. La spina di rete è usata come dispositivo di disconnessione e deve rimanere facilmente utilizzabile. La presa di corrente deve essere installata vicino al dispositivo e facilmente accessibile. Ambiente operativo: Temperatura: -30 - 50 ;...
- Page 17 RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment. User has the choice to give his product to a competent recycling organization or to the retailer when he buys new electrical or electronic equipment.
-
Page 18: Nombre Del Producto
© 2022 Shenzhen Tenda Technology Co., Ltd. All rights reserved. Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and product names mentioned herein are trademarks or registered trademarks of their respective holders. Specifications are subject to change without notice.
