Summary of Contents for Hyundai HYMW-GP108
- Page 1 HYMW-GP108 HYMW-GP109 MICROWAVE OVEN BUILD-IN...
-
Page 2: Important Safeguards
Household use only SAVE THESE INSTRUCTIONS .IMPORTANT SAFEGUARDS …… 。。……………… ……… WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a trained person. WARNING: It is hazardous for anyone other than a trained person to carry out any service or repair operation, which involves the removal of any cover, which gives protection against exposure to microwave energy. - Page 3 12. The appliance must not be installed equal or higher than 900 mm above the floor. Minimum height of free space necessary above the top surface of the oven: See the installation drawing. Warning: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated.
- Page 4 taken to avoid touching heating elements inside the oven. WARNING: Accessible parts may become hot during use. Young children should be kept away. WARNING: The appliance and its accessible parts become hot during use. 22. Care should be taken to avoid touching heating elements. 23.
- Page 5 .INSTALLATION… ………… …… ……………………… ……..…… ….… a) Put the microwave oven into built-in cabinet and push it forward to the end. (Fig.1) Fig.1 b) Push the microwave oven till to the end. (Fig.2) Fig.2...
- Page 6 c) Move the product in parallel in the kitchen cabinet according to the direction of the arrow in the figure, and keep it centered. (Fig.3) Fig.3 d) Use the screws of parts packing to secure the microwave oven in the cabinet. (Fig.4) Fig.4...
- Page 7 Cabinet details: Product size: (W)595x(H)385x(D)367.5(mm) Opening size: (D)560±2 x (E)360±2 x (F)550±2 (mm) as shown in Fig.5 “D”,“E”,“F”. G (The thickness of board): 20mm I (The thickness of board):20mm H (The deepness of wrong layer): 20mm exhaust port G(20mm) intake Fig.5...
-
Page 8: Microwave Oven Care
.CLEANING …………………… …………… MICROWAVE OVEN CARE The oven should be cleaned regularly and any food deposits removed. a. Remove the power cord from the wall outlet before cleaning. After cooling products. Don't immerse the appliance in water or other fluids when cleaning. b. -
Page 9: Tips For Cleaning
by dry cloth to remove any food splashes and grease. Built -up grease may overheat and begin to cause smoke or catch fire. TIPS FOR CLEANING Details for cleaning door seals, cavity and adjacent parts: Exterior: Wipe the enclosure with a dampened soft cloth Door: Using a dampened soft cloth, wipe clean the door and window Wipe the door seals and adjacent parts to remove any spill or... -
Page 10: Product Instruction
.PRODUCT INSTRUCTION …… …………… ....② ⑦ ⑧ ① ③ ④ ⑥ ⑤ 1) Door lock Microwave oven door must be properly closed in order for it to operate. 2) Viewing window Allow user to see the cooking status 3) Rotating axis The glass turntable sits on the axis;... -
Page 11: Operation Of Control Panel
See below in details (the control panel is subject to change without prior notice) 7) Waveguide cover It is inside the air fryer oven, next to the wall of control panel. Never remove the waveguide cover. 8) Grill rack Use to place the roasting food. .OPERATION OF CONTROL PANEL …。... -
Page 12: Before Cooking
1. BEFORE COOKING The display lit up when plugged in power supply, then enter the standby state and display shows 1:00. 2. MICROWAVE FUNCTION There are five firepower levels, 100P, 80P, 50P, 30P and 10P, respectively. Turn the knob above to select the desired microwave power. - Page 13 must press STOP/LOCK button once to clear the preset procedure to avoid unintended operation of next time use. 3. DEFROST The defrost function is to defrost by weight, and corresponding to "dEF" display. Turn the knob above to select the defrost function and the "dEF"...
-
Page 14: Auto Cooking
Turn the knob above to select the clock function, press “START/+30s” button for more than 3 seconds to enter the clock setting interface. At the same time, the display screen blinks in hours. The hour time can be set by turning the knob below. After setting the hour, press the "START/+30s"... - Page 15 Beverage The optional weight is 1 cup, about 250ml Meat The optional weight is 400g Fish The optional weight is 400g a. The temperature of food before cooking would be 20-25℃. Higher or lower temperature of the food before cooking would require increase or decrease of cooking time.
- Page 16 Grill, the heat element will be energized during operation time. Which is applicable for rolling thin meats or pork, sausage, chicken wing as good brown color can be obtained Combination of grill and microwave cooking. 30% microwave and 70% grill. Combination of grill and microwave cooking.
-
Page 17: Child Lock Function
9. CHILD LOCK FUNCTION Use this feature to lock the control panel when you are cleaning or so that children cannot use the oven unsupervised. All the buttons are rendered inoperable in this mode. 1) Set lock: In standby mode, press the "STOP" button for more than 3 seconds, the child lock function is locked, and all buttons of the microwave oven cannot be operated. -
Page 18: Cooking Tips
be used in Grill mode. It should not be used in microwave oven. Metal container Microwave cannot penetrate through metal. Poor heat-resistant. Cannot used lacquer High-temperature cooking Poor heat-resistant. Can Bamboo wood used and paper High-temperature cooking COOKING TIPS …… ..…... - Page 19 Color and hardness of food help to determine if it is done, these include: - Steam coming out from all parts of food, not just the edge - Joints of poultry can be moved easily - Pork or poultry shows no signs of blood - Fish is opaque and can be sliced easily with a fork Browning dish When using a browning dish or self-heating container, always...
-
Page 20: Maintenance
.MAINTENANCE … 。…… ………………… …… SERVICING Please check the following before calling for services. 1. Place one cup of water (approx.150ml) in a glass measure in the oven and close the door securely. Oven lamp should go off if the door is closed properly. Let the oven work for 1 min. - Page 21 exposure during servicing. ● Improper fitting of magnetron; ● Improper matching of door interlock, door hinge and door; ● Improper fitting of switch support; ● Door, door seal or enclosure has been damaged. Correct disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU.
