QOM-eLED+DMX
Installation Instructions
Must be installed by licensed electrician.
•
Installation must be in accordance with DMX512-A standard
•
DMX Shield must be grounded to Earth Ground at a single point external to power supply
•
LOW VOLTAGE LIGHTING SYSTEM &
LANDSCAPE LIGHTING SYSTEMS
COMPLIANT
CLASS: 3425-15
3425-95
© 2024 QTL. All rights reserved | 155 Hill St. Milford, CT 06460 | 203-367-8777 | sales@QTL.lighting | QTL.lighting
•
•
•
•
•
•
3402-15
3402-95
Wear rubber shoes and work on a sturdy wooden or fiberglass ladder.
This power supply must be installed according to the National Electric
Code and local codes and ordinances.
This power supply is to be installed and serviced only by an licensed
electricians.
This power supply is to be installed so that it is not likely to be
contacted by people.
To avoid a hazard to children, account for all parts and destroy all
packaging materials.
Specification subject to change. Rev-06-11-24
