Inner Range 996520PCB Installation Manual

4
Comms Task Formats supported by each UART Serial Port.
Port 1 (Connector P3). Modem:
All formats listed for Port 2 below plus E Modem.
Port 2 (Connector P4). Comm:
Integriti Monitor GSM
EMS Securitel Intercom
Check "Communications Programming" in the Integriti Programming Reference manual
for latest details of Comms Task formats.
Pre-assembled Cables for UART Serial Ports.
993009: Computer interface cable. (DB9)
993025: Computer interface cable. (DB25)
993026: Serial Printer interface cable. (DB25)
993027: Modem interface cable. (DB25)
993035: Securitel interface cable. (Flying leads)
995009: Internal PC Interface cable kit. Installed inside the cabinet to the DB9
knockout, to provide an external DB9 serial connection.
Specifications
Power Supply Input: 11V to 14V DC from Host Module
Current Consumption: 40mA plus 5mA per active Port.
Physical dimensions: Length:
Width:
Depth:
Installation environment: 0º to 40º Celsius
15% to 85% Relative humidity (non-condensing)
While every effort has been made to ensure the accuracy of this manual, the manufacturer
assumes no responsibility or liability for any errors or omissions.
Due to ongoing development, this manual is subject to change without notice.
Designed & manufactured in Australia.
© 2013 - 2014. Inner Range Pty. Ltd.
UniBus 2 P UniBus 2 Port U UniBus 2 P UniBus 2 P UniBus 2 P ort U ort U ort UART ort U ART ART ART. . . . . Installation Manual. ART
Automation
BMS
105mm. 94mm with snap-off strip removed.
94mm
28mm with UniBus cable connected.
Part No: 636520
Revision 1.10 April. 2014.
Integriti UniBus 2 P Integriti UniBus 2 P
Integriti UniBus 2 P Integriti UniBus 2 P Integriti UniBus 2 Port U
P/N P/N : 996520PCB&K : 996520PCB&K
P/N P/N P/N: 996520PCB&K : 996520PCB&K : 996520PCB&K
INSTALLATION MANUAL
The UniBus 2 Port UART provides 2 high speed, software configurable, Serial Ports
allowing connection of peripheral serial devices. Up to 4 UniBus UART Boards may be
connected to an Integriti Controller.
DIPswitch options allow each Port to be configured for RS-232 or RS-485 operation.
Specific RS-232 cables are available for the connection of a Computer, Modem or other
serial device including the Inner Range GSM modem or Multipath IP STU.
The board is connected directly to the Host Module or another UniBus Board via the
UniBus cable supplied.
IMPORTANT NOTE: Ensure that the current required by UniBus Boards does not cause
the Host Module's ancillary current limit to be exceeded.
SERIAL PORT APPLICATIONS.
Port 1 (Modem): Supports any Comms Task format that requires UART Serial Port
communications, including all "Modem" Comms Task formats.
Port 2 (Comm): Supports the Comms Task formats that utilize TXD/RXD and CTS/
RTS for UART Serial Port communications.
"E Modem" and any formats that require CD, DSR, DTR or RI signals
are not suported. Use Port 1 for these formats.
See Page 4 for full details of Comms Task Formats supported by each Port.
Parts List
- UniBus 2 Port UART PCB sub-assy.
- 2 x 4 way plug-on screw terminals.
- 1 x UniBus Cable. 270mm.
- 4 x Metal M3 Mounting Clips.
- 4 x M3 screws.
- Installation Guide. (This document)
ort U ort U ART ART
ort UART ort U ART ART
Introduction
UniBus Cable options
Supplied:
996791L 270mm
Purchased separately:
996791SS 150mm
996791LL 475mm
996791XL 675mm
1
