AlterPath KVM/netPlus Specifications
Hardware
C P U : M P C 8 5 9 P ( Powe r P C ) @ 13 3 M H z
M e m o r y : 12 8 M B D I M M S D R A M / 2 5 6 M B c o m p a c t f l a s h
I n t e r f a c e s : 1 E t h e r n e t 10 / 10 0 B T o n R J - 4 5
1 R S - 2 3 2 c o n s o l e o n R J - 4 5
2 R S - 2 3 2 a u x i l i a r y p o r t s o n R J - 4 5
16 o r 3 2 R J - 4 5 K V M p o r t s ( C AT 5 - b a s e d )
1 V G A H D 15 f e m a l e a n d 2 M i n i D I N 6
( P S / 2 ) u s e r i n t e r f a c e
1 R J - 4 5 u s e r i n t e r f a c e ( C AT 5 - b a s e d )
2 P C M C I A s l o t s ( 16 - b i t P C C a r d )
Powe r : 10 0 V / 24 0 V, 5 0 / 6 0 H z , 0 . 7 8 A / 0 . 4 6 A
F o r m F a c t o r : 1 U r a ck m o u n t a b l e ( r a ck m o u n t k i t s i n c l u d e d )
O p e r a t i n g
Te m p e r a t u r e : 32°F t o 122°F (0°C t o 50°C)
St o r a g e
Te m p e r a t u r e : –40°F t o 185°F (–40°C t o 85°C)
H u m i d i t y : 5 % t o 9 0 % n o n c o n d e n s i n g
D i m e n s i o n s :
( W x D x H ) K V M / n e t P l u s
17 x 15 x 1. 7 5 i n
( 4 3 .18 x 3 8 .1 x 4 . 4 5 c m )
K V M E x p a n d e r
12 x 2 . 5 x 1. 5 3 i n
( 3 0 . 4 8 x 6 . 3 5 x 3 . 87 c m )
K V M Te r m i n a t o r
1. 24 x 2 . 6 0 x 0 . 8 5 i n
( 3 .15 x 6 . 6 0 x 2 .16 c m )
K V M R P
9 x 9 x 1. 7 5 i n
( 2 2 . 8 6 x 2 2 . 8 6 x 4 . 4 5 c m )
C e r t i f i c a t i o n : C S A , F C C , C E , E N 6 0 9 5 0 , V C C I , C - T i ck
Part Number Model
ATP1601 AlterPath KVM/netPlus 1601
ATP1602 AlterPath KVM/netPlus 1602
ATP1604 AlterPath KVM/netPlus 1604
ATP3201 AlterPath KVM/netPlus 3201
ATP3202 AlterPath KVM/netPlus 3202
ATP3204 AlterPath KVM/netPlus 3204
ATP4610 AlterPath KVM Terminator PC PS/2
ATP4630 AlterPath KVM Terminator PC USB
ATP4620 AlterPath KVM Terminator Sun USB Server-side unit, Sun USB
ATP4710 AlterPath KVM RP
ATP4208 AlterPath KVM Expander 8
ATP4216 AlterPath KVM Expander 16
3541 Gateway Boulevard, Fremont, CA 94538 T: 510.771.6100 F: 510.771.6200 www.cyclades.com sales@cyclades.com
© 2006 Cyclades Corporation, all rights reserved.
Description
16-port KVM over IP switch, 3 users,
2 local and 1 remote user over the network
16-port KVM over IP switch, 4 users,
2 local and 2 remote user over the network
16-port KVM over IP switch, 6 users,
2 local and 4 remote user over the network
32-port KVM over IP switch, 3 users,
2 local and 1 remote user over the network
32-port KVM over IP switch, 4 users,
2 local and 2 remote user over the network
32-port KVM over IP switch, 6 users,
2 local and 4 remote user over the network
Server-side unit, PC PS/2
Server-side unit, PC USB
Remote user interface unit
8-port KVM expander module
16-port KVM expander module
Features
Accessibility
•16 or 32 server ports
•2 local users and 1, or 2 or 4 remote users over
IP network simultaneously
Security
•Local, RADIUS, TACACS+, LDAP, NTLM, NIS,
Active Directory and Kerberos authentication
•Token-based strong authentication (RSA SecurID)
•Local backup user authentication
•3DES and RC4 encryption (KVM over IP viewer only)
•User ACLs per port
•User access logging
•System event syslog
Server Management
•Access through Web management interface (WMI)
or on-screen display (OSD)
•Port name assignment
•Simultaneous access on the same port (port sharing
for local and remote users)
•Cascading with centralized port management
(access and configuration)
•Programmable cycling of screens
•Maximum resolution 1,600 x 1,200 @ 60 Hz (local
stations only); 1,280 x 1,024 @ 60 Hz (KVM over IP)
•Temperature monitoring
•Optional integrated power management with the AlterPath PM
•Optional 8- and 16-port expander modules
System Management
•WMI for configuration
Cabling
•CAT5-based terminators
•Compatible with PC PS/2, PC USB and Sun USB
keyboard/mouse interfaces
•CAT5, CAT5e, CAT6 and CAT7 UTP cabling
•Cable length up to 500 ft (152.4 m) distance
between terminator and KVM switch
Upgrades
•Upgrades available on FTP site
•Flash upgradeable
•TFTP support for network boot
