Summary of Contents for Cyclades PM IPDU
- Page 1 ® Cyclades P M IPDU Installer/Administrator/User Guide...
-
Page 2: Fcc Warning Statement
FCC Warning Statement The Cyclades PM IPDU has been tested and found to comply with the limits for Class A digital devices, pursu- ant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful in- terference when the equipment is operated in a commercial environment. - Page 3 Cyclades PM IPDU Installer/Administrator/User Guide Avocent, the Avocent logo, The Power of Being There and Cyclades are registered trademarks of Avocent Corporation. All other marks are the property of their respective owners. © 2006 Avocent Corporation. All rights reserved. 590-667-501A...
-
Page 4: Dangerous Voltage
Instructions This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. Dangerous Voltage This symbol is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 5: Table Of Contents
Alarms and monitoring ... 1 Sequential power up ... 1 Support for daisy chaining ... 2 Creation of user accounts... 2 Integration with Cyclades management products ... 2 Hardware Configuration Options... 2 Standalone configuration ... 2 Daisy chained configuration... 3 Integrated configuration... - Page 6 Cyclades PM IPDU Installer/Administrator/User Guide Supplied with the PM IPDU ... 13 Modular input power cables for the PM IPDU ... 14 Optional outlet cable package ... 16 Rack Mounting the Cyclades PM IPDU ... 16 Installation environment... 17 Daisy Chaining PM IPDUs ... 19 Plugging Devices Into PM IPDU Outlets...
- Page 7 Table of Contents hwocp ... 44 id ... 45 interval ... 46 list... 47 lock... 48 name... 48 off ... 49 on ... 50 passwd... 50 reboot ... 51 restore ... 53 save ... 53 status ... 54 syslog ... 55 temperature ...
- Page 8 Cyclades PM IPDU Installer/Administrator/User Guide...
-
Page 9: List Of Figures
Figure 2.2: Rack Mounting Holes on the PM8i IPDU, PM10 IPDU and PM10i IPDU ... 18 Figure 2.3: PM10 IPDU with Mounting Brackets Installed ... 18 Figure 2.4: Rack Mount for the Cyclades PM8i IPDU, PM10 IPDU or PM10i IPDU... 19 Figure 2.5: Connecting a Local Work Station to the Cyclades PM IPDU... 21 Figure 3.1: Sending Firmware using HyperTerminal ... - Page 10 Cyclades PM IPDU Installer/Administrator/User Guide...
-
Page 11: List Of Tables
LIST OF T A BL ES List of Tables Table 2.1: PM IPDU Shipping Box Contents, Part Numbers and Description... 13 Table 2.2: PM8i-10A IPDU and PM10i-10A IPDU Power Cables ... 15 Table 2.3: PM10i-15A IPDU Power Cables ... 16 Table 2.4: PM10i-16A IPDU and PM 20i-16A IPDU Power Cables ... - Page 12 Cyclades PM IPDU Installer/Administrator/User Guide Table A.19: Pinouts for IN and OUT RS-232 Serial Ports... 72 Table C.1: Circuit Breaker Trip Time ... 83...
-
Page 13: Chapter 1: Introduction
LED digital display. Users have the ability to set a current alarm threshold that, once exceeded, will cause the Cyclades PM IPDU to sound an alarm or send a notification message, or both. The LED current display also blinks when the alarm threshold is exceeded. -
Page 14: Support For Daisy Chaining
When used with the ACS advanced console server, the TS terminal server, the OnSite branch office appliance or the KVM switch, the Cyclades PM IPDU offers a superior feature set that is not fully covered in this manual. Please refer to the appropriate product documentation for more information on how to use the Cyclades PM IPDU with your specific implementation. -
Page 15: Daisy Chained Configuration
Figure 1.1: Standalone Configuration NOTE: The previous graphic displays the PM IPDU being connected to the local work station with the RJ-45 to DB-9F adaptor that is shipped with the product. If your work station does not have a DB-9M COM port, you may need to use a USB serial adaptor in order to connect to the computer’s USB port. -
Page 16: Integrated Configuration
Figure 1.2: Daisy Chained Configuration NOTE: The previous graphic displays the PM IPDU being connected to the local work station with the RJ-45 to DB-9F adaptor that is shipped with the product. If your work station does not have a DB-9M COM port, you may need to use a USB serial adaptor in order to connect to the computer’s USB port. -
Page 17: Figure 1.3: The Cyclades Pm Ipdu With A Cyclades Management Device
• The Cyclades PM IPDU inherits the security of the console server to which it is connected. Daisy chaining PM IPDUs with the Cyclades ACS console server or Cyclades TS terminal server is similar to the daisy chained configuration as described in Daisy chained configuration on page 3;... -
Page 18: Accessing The System Console
Accessing the System Console Users and administrators may access the Cyclades PM IPDU either by making a direct console connection to the PM IPDU’s IN port or by connecting the PM IPDU to a Cyclades console or KVM switch management device. -
Page 19: Component Overview
Cyclades PM20i IPDU on page 10 If needed, see Appendix A: Specifications on page 63 for more electrical, hardware and environment details about each model. See Supplied with the PM IPDU on page 13. Cyclades PM8 IPDU The Cyclades PM8 IPDU has the following features: •... -
Page 20: Cyclades Pm8I Ipdu
Cyclades PM IPDU Installer/Administrator/User Guide Cyclades PM8i IPDU The Cyclades PM8i IPDU has the following features: • One 240VAC/8A power inlet (IEC320-C14). See PM8i-10A IPDU and PM10i-10A IPDU power cables on page 15 for a list of which power cables are supplied by region. -
Page 21: Cyclades Pm10I Ipdu
Two 240VAC/15A magnetic circuit breakers with “press to reset” function • Horizontal (1U) mounting Refer to Figure 1.7 on page 9 and Figure 1.8 on page 9 for images of the Cyclades PM10i-L30A IPDU. Cyclades PM10i-32A IPDU The Cyclades PM10i-32A IPDU has the following features: •... -
Page 22: Cyclades Pm10I-32Au Ipdu
Cyclades PM IPDU Installer/Administrator/User Guide • Horizontal (1U) mounting Refer to Figure 1.7 on page 9 and Figure 1.8 on page 9 for images of the Cyclades PM10i-32A IPDU. Cyclades PM10i-32Au IPDU The Cyclades PM10i-32Au IPDU has the following features: •... -
Page 23: Cyclades Pm20I-32A Ipdu
240VAC/two 16A magnetic circuit breakers with accidental-off protection function • Vertical mounting (zero U) Refer to Figure 1.10 on page 11 for an image of the Cyclades PM20i-32A IPDU. Cyclades PM20i-32Au IPDU The Cyclades PM20i-32Au IPDU has the following features: •... - Page 24 Cyclades PM IPDU Installer/Administrator/User Guide...
-
Page 25: Chapter 2: Installation
• A PC running a terminal emulation program See the following section for the list of other necessary items that come with the PM IPDU. Supplied with the PM IPDU All PM IPDU models are shipped with the PM IPDU itself along with the items shown in Table 2.1. -
Page 26: Modular Input Power Cables For The Pm Ipdu
Modular input power cables for the PM IPDU If your PM IPDU model does not have a fixed power input cable, it may ship with one of the modular cables listed in the following sections. Depending on your site’s location, the modular input power cables included in the box vary. -
Page 27: Table 2.2: Pm8I-10A Ipdu And Pm10I-10A Ipdu Power Cables
PM8i-10A IPDU and PM10i-10A IPDU power cables Table 2.2: PM8i-10A IPDU and PM10i-10A IPDU Power Cables Country/Region CAB0089 CAB0055 Australia and New Zealand CAB0087 Continental Europe CAB0088 United Kingdom and Ireland Chapter 2: Installation... -
Page 28: Optional Outlet Cable Package
Rack Mounting the Cyclades PM IPDU You may mount the PM IPDU on a rack or wall or place it on a desktop or other flat surface. Two brackets are supplied with six Phillips screws for attaching the brackets to the PM8i IPDU, the PM10 IPDU and the PM10i IPDU for mounting. -
Page 29: Installation Environment
NOTE: When mounting a Cyclades PM IPDU zero U model to a wall stud, securely mount it by using a #10 or larger screw or use a drywall fastener rated min. 25 lb. (11.34 kg). -
Page 30: Figure 2.2: Rack Mounting Holes On The Pm8I Ipdu, Pm10 Ipdu And Pm10I Ipdu
Table 2.6: PM IPDU Optimum Installation Environment (Continued) Environment Factor Reliable Grounding NOTE: Install a Cyclades PM IPDU zero U model in a location where there is an adjacent and accessible wall socket outlet. To mount the Cyclades PM8i IPDU, PM10 IPDU or PM10i IPDU: Locate the appropriate sets of holes on the PM IPDU. -
Page 31: Daisy Chaining Pm Ipdus
NOTE: The suggested minimum screw size for wall-mounting the Cyclades PM IPDUs is #10 (4.8 mm or 0.19 in or 3/16 in) or larger. The RJ-45 cable included in the Cyclades PM IPDU package is minimum flame rated VW-1 or FT-1 and has a maximum length of 10 feet (3 meters). -
Page 32: Plugging Devices Into Pm Ipdu Outlets
Cyclades PM IPDU Installer/Administrator/User Guide To connect another PM IPDU to the slave, connect one end of an RJ-45 cable to the OUT port of the last PM IPDU in the chain. Repeat Step 3 until you have connected the desired number of PM IPDUs. -
Page 33: Figure 2.5: Connecting A Local Work Station To The Cyclades Pm Ipdu
Figure 2.5: Connecting a Local Work Station to the Cyclades PM IPDU To access the console: Perform the following steps to connect a computer to the console port of the PM IPDU. This procedure assumes that you know how to use a terminal emulation program. - Page 34 Cyclades PM IPDU Installer/Administrator/User Guide To log into the PM IPDU through the console (IN port): From your terminal emulation application, log into the console port as admin. AlterPath PM Copyright (c) 2002-2006 Avocent Corporation V 1.9.0 Jun 21, 2006...
-
Page 35: Chapter 3: Configuration
Command Prompt - Full configuration capabilities. • Browser - Available only when the PM IPDU is connected directly to an AUX port on a KVM switch or OnSite appliance or connected directly to a serial console port on an ACS console server, TS terminal server or OnSite appliance. -
Page 36: Initial Configuration Using The Command Prompt
Initial Configuration Using the Command Prompt To configure the PM IPDU, you must have a work station connected to the console (In) port on the PM IPDU and be logged in as the admin user. See Making a Direct Connection for Console Access on page 20 for instructions on connecting to the console. -
Page 37: Resetting The Admin Password
After one minute, you may remove the loopback connector from the OUT port of the Cyclades PM IPDU. Now the password for the user admin is reset to the default (pm8), and you should be able to log into the Cyclades PM IPDU using the default username/password. -
Page 38: Upgrading The Cyclades Pm Ipdu Firmware
Cyclades PM IPDU Installer/Administrator/User Guide If you need to recover the password of many Cyclades PM IPDUs connected in a daisy chain, go to step 1 and perform the procedure on each Cyclades PM IPDU in the chain. Upgrading the Cyclades PM IPDU Firmware Starting with version 1.1.0, the Cyclades PM IPDU firmware may be upgraded through its IN port. - Page 39 Enter choice (1 or 2): 1 Erasing firmware...done. Downloading image. Please send file in 10 seconds. Use your terminal emulator program to upload the Cyclades PM IPDU firmware file to the PM IPDU using the Xmodem protocol. To use HyperTerminal in Windows: From the top menu select Transfer-Send.
-
Page 40: Figure 3.1: Sending Firmware Using Hyperterminal
Cyclades PM IPDU Installer/Administrator/User Guide Figure 3.1: Sending Firmware using HyperTerminal Click the Browse button to set the proper path for the Cyclades PM IPDU firmware file located on your work station. NOTE: You must browse for the proper file and click the Send button within 10 seconds of selecting Transfer-Send. -
Page 41: Figure 3.2: Sending Firmware Using Minicom
If the file transfer is successful, the Cyclades PM IPDU console displays the login prompt. At this point, the upgrade process of the unit is complete; you may log into the Cyclades PM IPDU and perform actions as usual. - Page 42 Cyclades PM IPDU Installer/Administrator/User Guide In this case, select option 2 from the menu and repeat the firmware upload procedure. If the problem persists, contact Technical Support for assistance.
-
Page 43: Chapter 4: Command Line Interface
If no PM IPDUs are daisy chained, the [PM]: IPDU: line appears only once, and the value is 1. If there are any PM IPDUs daisy chained to the first PM IPDU, the [PM]: IPDU: line appears once for each PM IPDU in the chain. For each PM IPDU, the value is incremented by 1. The final appearance of the [PM]: IPDU: line will show the total number of PM IPDUs in the daisy chain. -
Page 44: Logging In To The Pm Ipdu
After the Password: prompt, enter the password for the unsername entered. The default user is admin and the default password is pm8. After a successful login, the PM IPDU command prompt appears after which you may use any of the commands described in this chapter. -
Page 45: Adduser
41 NOTE: When a range of outlets is used in a command and the range spans more than one PM IPDU in a daisy chain, the range of outlets must not be specified by name. The range of outlets may only be specified by number in this situation. -
Page 46: Alarm
Cyclades PM IPDU Installer/Administrator/User Guide alarm The alarm command sets and reads the current threshold. This command is available to the admin user only. Syntax alarm | [<IPDU#>|<IPDU_ID>] | <threshold> Arguments number in a daisy chain <IPDU#> IPDU Identification string previously set by the id command. -
Page 47: Buzzer
Buzzer turned OFF on IPDU #2 current The current command displays the total current drawn by Cyclades PM IPDUs and the maximum current the unit has drawn (current peak). It may also be used to clear the saved peak current value. -
Page 48: Currentprotection
Cyclades PM IPDU Installer/Administrator/User Guide Syntax current [<IPDU#>|<IPDU_ID>]|reset Arguments <IPDU#> IPDU number in a daisy chain Identification string previously set by the id command <IPDU_ID> reset Clears the saved peak current value Examples To get the current status for all units, enter the following. -
Page 49: Currseg
Examples To display current protection status for all units, enter the following. pm> currentprotection status IPDU #1: Overcurrent protection is OFF. IPDU #2: Overcurrent protection is OFF. To enable current protection status for all units, enter the following. pm>currentprotection ON IPDU #1: Overcurrent protection turned ON. -
Page 50: Cycle
(see command name for details). Syntax cycle all|<outlet_string> Arguments all Cycles all outlets in the PM IPDU or PM IPDU daisy chain <outlet_string> Outlet number, such as “5”, outlet name such as “sunfire”, or group of outlets such as “1, 3-5” Examples To cycle one outlet, enter the following. -
Page 51: Dbsync
To cycle multiple outlets, enter the following. pm>cycle 2, 3, 5-7 2: Outlet turned off. 3: Outlet turned off. 5: Outlet turned off. 6: Outlet turned off. 7: Outlet turned off. 2: Outlet turned on. 3: Outlet turned on. 5: Outlet turned on. 6: Outlet turned on. -
Page 52: Display
PM IPDU to be mounted upside-down. This command is available to the admin user only. NOTE: The decimal point will be at the top of the display when the PM IPDU is mounted upside down. Syntax display [<IPDU#>|<IPDU_ID>... -
Page 53: Exit
Syntax factory_defaults [<IPDU#>|<IPDU_ID>] Arguments resets all PM IPDUs in the daisy chain to factory default no argument number of the PM IPDU in the chain <IPDU#> Identification string previously set by the id command <IPDU_ID> Chapter 4: Command Line Interface... -
Page 54: Help
Cyclades PM IPDU Installer/Administrator/User Guide Examples To reset the factory defaults, enter the following. pm>factory_defaults 1 Setting configuration to defaults on IPDU #1 1: Outlet turned on. 2: Outlet turned on. 3: Outlet turned on. 4: Outlet turned on. 5: Outlet turned on. -
Page 55: Humidity
The humidity command displays the Cyclades PM IPDU’s surrounding humidity and the maximum humidity the IPDU has registered (humidity peak). It may also be used to clear the saved peak humidity value. This command only works on PM IPDU models with a humidity sensor. Syntax humidity [<IPDU#>|<IPDU_ID>]|reset... -
Page 56: Hwocp
When the overcurrent protection is off or reset, the power is on and the PM IPDU is running in normal mode. If no string identifying the IPDU is given, all PM IPDUs in the daisy chain are affected by this command. This command is available to the admin user only. - Page 57 1 reset IPDU #1 was reset The id command sets or displays the ID of a PM IPDU. A maximum of 16 characters (not case sensitive) is allowed. Spaces, numbers, and special characters are allowed. This command is available to the administrator user only.
-
Page 58: Interval
Cyclades PM IPDU Installer/Administrator/User Guide To display the ID of PM IPDU 2, enter the following. pm>id 2 IPDU #2: id = QA To rename an ID to “sammy,” using an existing ID “QA,” enter the following. pm>id QA sammy IPDU #2 = sammy To display the IDs of all PM IPDUs in the daisy chain, enter the following. -
Page 59: List
To set the interval of outlets 2, 4, 5, and 6 to a value of 2.4, enter the following. pm>interval 2,4-6 2.4 2: Outlet power on interval set to 2.4 sec. 4: Outlet power on interval set to 2.4 sec. 5: Outlet power on interval set to 2.4 sec. -
Page 60: Lock
Cyclades PM IPDU Installer/Administrator/User Guide lock The lock command locks an outlet or group of outlets in the current state. The response to this command is a list of status lines, one per power port. This command works on all PM IPDUs in a daisy chain. -
Page 61: Off
<outlet_string> Outlet number, such as “5”, outlet name such as “sunfire”, or group of outlets such as “1, 3-5” CAUTION: The “all” argument will turn off all outlets in a PM IPDU or PM IPDU daisy chain. Examples To turn all outlets off, enter the following. -
Page 62: Passwd
This command works on outlets in a PM IPDU daisy chain. Syntax on all|<outlet_string> Arguments all Turns on all outlets in the PM IPDU or PM IPDU daisy chain Outlet number, such as “5”, outlet name such as “sunfire”, or group of outlets <outlet_string> such as “1, 3-5”... -
Page 63: Reboot
Username/password set for user alpha. reboot The reboot command reboots a PM IPDU. You may reboot a specific unit by issuing the reboot command followed by the unit’s logical number or the unit’s ID. Issuing the reboot command without a parameter reboots the first unit in a chain, not all the units in a chain. This command is available to the admin user only. - Page 64 Cyclades PM IPDU Installer/Administrator/User Guide Examples To reboot the first unit of the chain, or to reboot the unit in stand alone mode, enter the following. pm>reboot saving configuration to flash on IPDU #1 ... Done. ----------------------------- Copyright (c) 2003 Cyclades Corporation AlterPath PM/KVM Boot Loader Version 1.1...
-
Page 65: Restore
8: Outlet turned on. save The save command saves the current configuration in the flash device built in to all Cyclades PM IPDU units. This command saves the username/password database and the specific information pertaining to each outlet such as outlet name, outlet assignments, outlet state. This command is available to the admin user only. -
Page 66: Status
<outlet_string> Outlet number, such as “5”, outlet name such as “sunfire”, or group of outlets such as “1, 3-5” all Displays the status of all outlets in a PM IPDU or PM IPDU daisy chain Examples To display the status of outlet 1, enter the following. -
Page 67: Syslog
To display the status of all outlets, enter the following. pm>status all Outlet Name 2.40 2.40 2.40 0.50 0.50 syslog The syslog command displays or changes the syslog notification status. This command is available to the admin user only. Syntax syslog on|off|status Arguments on Enables message to be displayed in the console when there is an over current situation... -
Page 68: Temperature
Syslog turned OFF on IPDU #1 Syslog turned OFF on IPDU #2 temperature The temperature command displays the Cyclades PM IPDU’s surrounding temperature and the maximum temperature the unit has registered (temperature peak). It may also be used to clear the saved peak temperature value. -
Page 69: Unassign
<outlet_string> Outlet number, such as “5”, outlet name such as “sunfire”, or group of outlets such as “1, 3-5” all Unlocks all outlets in the PM IPDU or PM IPDU daisy chain Examples To unlock outlets 2, 3, 4, and 8, enter the following. -
Page 70: Upgrade
You may either upgrade or boot the firmware. NOTE: For details on upgrading using the upgrade command or using the reboot command, see Upgrading the Cyclades PM IPDU Firmware on page 26. Syntax upgrade <IPDU#>|<IPDU_ID>... -
Page 71: Ver
Examples To upgrade 1, type: pm>upgrade 1 saving configuration to flash on IPDU #1 ... Done. ----------------------------- Copyright (c) 2003 Cyclades Corporation AlterPath PM/KVM Boot Loader Version 1.1 ----------------------------- Boot Menu 1. Upgrade Firmware. 2. Boot Firmware. ----------------------------- Enter choice (1 or 2): 1 Erasing firmware...done. -
Page 72: Voltage
NOTE: If an IPDU has an id assigned to it, the ver command displays the word “id” followed by the name of the IPDU and the model number of the PM IPDU; however, if no id is configured for the IDPU, the ver command displays the word “id”... -
Page 73: Whoami
reserved for future use AB|AC|BC displays the RMS voltage on all units if voltage sensors are available no argument Examples whoami The whoami command shows the username of the user currently logged in. Syntax whoami Arguments none Examples To view the current username, enter the following. pm>whoami admin Chapter 4: Command Line Interface... - Page 74 Cyclades PM IPDU Installer/Administrator/User Guide...
-
Page 75: Appendices
A P P EN D IC ES Appendices Appendix A: Specifications Table A.1: PM8-15A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Specifications 100-125 VAC 15A (de-rated to 12A) -
Page 76: Table A.2: Pm8-20A Ipdu And Pm8-L20A Ipdu Specifications
Cyclades PM IPDU Installer/Administrator/User Guide Table A.2: PM8-20A IPDU and PM8-L20A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.3: PM8i-10A IPDU Specifications... -
Page 77: Table A.4: Pm10-15A Ipdu Specifications
Table A.4: PM10-15A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Environmental Max Output Current Each Outlet Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.5: PM10-20A IPDU and PM10-L20A IPDU Specifications Characteristics Electrical Input Voltage... -
Page 78: Table A.6: Pm10-L30A Ipdu Specifications
Cyclades PM IPDU Installer/Administrator/User Guide Table A.6: PM10-L30A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.7: PM10i-10A IPDU Specifications... -
Page 79: Table A.8: Pm10I-15A Ipdu Specifications
Table A.8: PM10i-15A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.9: PM10i-16A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental... -
Page 80: Table A.10: Pm10I-20A Ipdu Specifications
Cyclades PM IPDU Installer/Administrator/User Guide Table A.10: PM10i-20A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.11: PM10i-32A IPDU and PM10i-32Au IPDU Specifications... -
Page 81: Table A.12: Pm10I-L30A Ipdu Specifications
Table A.12: PM10i-L30A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.13: PM20-20A IPDU and PM20-L20A IPDU Specifications Characteristics Electrical Input Voltage... -
Page 82: Table A.14: Pm20-L30A Ipdu Specifications
Cyclades PM IPDU Installer/Administrator/User Guide Table A.14: PM20-L30A IPDU Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.15: PM20i-16A IPDU Specifications... -
Page 83: Table A.16: Pm20I-20A Ipdu And Pm20I-L20A Ipdu Electrical Specifications
Table A.16: PM20i-20A IPDU and PM20i-L20A IPDU Electrical Specifications Characteristics Electrical Input Voltage Max Output Current Total Max Output Current Each Outlet Environmental Operating Temperature Relative Humidity Mechanical Weight Physical Dimensions (W x D x H) Table A.17: PM20i-L30A Specifications Characteristics Electrical Input Voltage... -
Page 84: Table A.18: Pm20I-32A Ipdu And Pm20I-32Au Ipdu Specifications
Weight Physical Dimensions (W x D x H) Interface Pinouts The following table illustrates the Cyclades PM IPDU's pinouts for the IN and OUT RS-232 serial ports (RJ-45F connectors). Table A.19: Pinouts for IN and OUT RS-232 Serial Ports Signal... -
Page 85: Appendix B: Safety Instructions
IMPORTANT: To help protect the Cyclades PM from electrical power fluctuations, use a surge suppressor, line conditioner, or uninterruptible power supply. IMPORTANT: Be sure that nothing rests on the cables of the Cyclades PM and that they are not located where they may be stepped on or tripped over. - Page 86 Wichtig: Um den Cyclades PM IPDU vor elektrischen Spannungsschwankungen zu schützen empfehlen wir den Einsatz von Überspannungsreglern, Spannungsglättern oder USVs. Wichtig: Bitte stellen Sie sicher, daß keine Gegenstände auf den Kabeln des Cyclades PM IPDU liegen und die Kabel so geführt sind, daß niemand darauf treten oder darüber stolpern kann.
-
Page 87: Istruzioni Di Sicurezza
Importante: Per proteggere le Cyclades PM IPDU da fluttuazioni di corrente elettrica, utilizzare un limitatore di sovracorrente, un condizionatore di linea, o un gruppo di alimentazione continua, UPS. Importante: Assicurarsi che niente giaccia sui cavi dell'Cyclades PM IPDU e che questi non causino intralcio al passaggio. -
Page 88: Instruções De Segurança
Importante: Garanta que não haja nenhum objeto sobre os cabos do Cyclades PM IPDU e que eles não estejam em locais de transito de pessoas para que não sejam pisados e para que não causem quedas ou acidentes. -
Page 89: Instrucciones De Seguridad
No utilice adaptadores de enchufe, ni quite el conector de tierra. No utilice extensores con el Cyclades PM IPDU. ¡PELIGRO! No empuje ningun objeto en las aberturas del Cyclades PM IPDU. El hacerlo puede causar fuego o descargas eléctricas poniendo en cortocircuito los componentes interiores. - Page 90 être interrompue. Important: Soyez sûr que rien ne repose sur les cables de l'Cyclades PM IPDU, qu'ils ne sont pas sur un lieu de passage, qu'ils ne peuvent pas être piétiné et que l'on ne peut pas trébucher dessus.
-
Page 91: Appendix C: Circuit Breakers
Appendix C: Circuit Breakers The PM IPDU circuit breakers are designed to shut the power off to some or all of the PM IPDU outlets in case the rated current is exceeded. The circuit breaker mechanism for each PM IPDU model is explained the in the following sections. -
Page 92: Figure C.1: Pm10-L30A Ipdu Circuit Breakers
Cyclades PM IPDU Installer/Administrator/User Guide Figure C.1: PM10-L30A IPDU Circuit Breakers PM10i-L30A IPDU The PM10i-L30A IPDU has two 15-amp circuit breakers. The first circuit breaker controls outlets 6 through 10; the second controls outlets 1 through 5. In the event that the total current flow to outlets 6 through 10 exceeds 15 amps due to equipment connected to these outlets, the first circuit breaker will trip causing outlets 6 through 10 to shutdown. -
Page 93: Figure C.3: Pm20-L30A Ipdu Circuit Breakers
will trip causing outlets 6 through 10 to shutdown. This does not affect outlets 1 through 5, which are controlled by the second circuit breaker. As the PM10i-32A has the controller powered from the line side of one of the circuit breakers, the whole unit will be inoperative only if both circuit breakers trip, but the controller will still function. -
Page 94: Figure C.4: Pm20I-L30A Ipdu, Pm20I-32A Ipdu And Pm20I-32Au Ipdu Circuit Breakers
Cyclades PM IPDU Installer/Administrator/User Guide When either circuit breaker trips, only the power outlets of that segment will be affected, and half of the outlets remain operative. Figure C.4: PM20i-L30A IPDU, PM20i-32A IPDU and PM20i-32Au IPDU Circuit Breakers PM20i-32A IPDU and PM20i-32Au IPDU The PM20i-32A IPDU and the PM20i-32Au IPDU have two 16-amp circuit breakers. - Page 95 Circuit Breaker Trip Time Depending on the model, the Cyclades PM IPDU uses either one 10 amp, one 20 amp, two 15 amp, or two 16 amp circuit breakers. The following table shows the circuit breaker trip time for all PM IPDU models.
- Page 96 Cyclades PM IPDU Installer/Administrator/User Guide...
-
Page 97: Index
Continental Europe 15, 16 creating users 24 current command 35 currentprotection command 36 currseg command 37 Cyclades management device 5 cycle command 38 daisy chain overview 3, 4 daisy chaining PMs 2, 19 DB-9 serial port 21 default configuration parameters 23... - Page 98 17 ambient temperature 17 circuit overloading 17 grounding 18 mechanical loading 17 temperature 17 installation environment 17 integration with Cyclades management products 2 interface pinouts 72 interfaces 7 interval command 46 introduction 1 Ireland 15, 16 Kermit 2, 21...
- Page 99 overview, PM 1 part numbers 13 passwd command 50 pinouts, In and Out RS-232 serial ports 72 plugging devices into outlets 20 PM10 8 -15A model 65 -20A model 65 -L20A model 65 -L30A model 66, 79, 80 PM10i 9, 79 -10A model 15, 66 -15A model 16, 67 -16A model 16, 67...
- Page 100 Cyclades PM Installer/Administrator/User Guide RJ-45 to RJ-45 7ft. CAT5 cable 13 save command 25, 53 save configuration 53 sequential power up 1 shipping box contents 13 software upgrade 26 specifications PM10-15A 65 PM10-20A 65 PM10i-10A 66 PM10i-15A 67 PM10i-16A 67...
- Page 102 For Technical Support: www.avocent.com/support Avocent Corporation 4991 Corporate Drive Huntsville, Alabama 35805-6201 USA Tel: +1 256 430 4000 Fax: +1 256 430 4031 Avocent Asia Pacifi c Singapore Branch Offi ce 100 Tras Street, #15-01 Amara Corporate Tower Singapore 079027 Tel: +656 227 3773 Fax: +656 223 9155 Avocent Canada...
