AlterPath™ Manager
E2000, 2500, and 5000
QuickStart Guide
This guide provides a summary of basic AlterPath™ Manager installation tasks for installers who
already know how to install and configure Cyclades AlterPath products.
The following table lists basic tasks in the order they should be performed. For more-detailed
procedures, go to the listed page numbers.
1.

Rack Mounting the AlterPath Manager

To Bracket Mount an APM
To Rail Mount an APM 2500 or 5000
2
Making the Ethernet Connection
To Set up a Single Network
To Set up a Private Network
3
Running the First Time Configuration Wizard
4
Connecting to the Web Management Interface (WMI)
1. Rack Mounting the AlterPath Manager
For the AlterPath Manager E2000, 2500 and 5000, two brackets and the necessary mounting
screws are supplied. For the AlterPath Manager 2500 and 5000, a set of sliding rails are also
provided (the small "ear" brackets are already attached).
To Bracket Mount an APM
1. Attach the mounting brackets to the sides of the APM E2000 towards the front of the box. Use
a screwdriver to firmly tighten the mounting brackets (already attached to the APM 2500 and
APM 5000).
2. Mount the APM securely to the vertical bars of the rack. Screws should go in through the front
of the brackets into the outside front of the vertical bars. Be sure to locate the APM so the
brackets line up correctly with the holes. Be sure the right and left brackets are at the same
height.
To Rail Mount an APM 2500 or 5000
1. Remove the inner rails from the rail assemblies. Slide each inner rail out until it stops. Then
depress the exposed locking tab to unlock the inner rail and slide it out the rest of the way.
2. Attach the inner rails to the sides of the APM 2500 or APM 5000. When the inner rails are
correctly positioned, the tabs will be to the rear of the APM, and the front three holes in the
inner rails will line up with the holes in the sides of the APM.
3. Attach the outer rails to the rack, using the end brackets. Be sure the open end of each outer
rail is located towards the front of the rack.
Page 1
Page 1
Page 1
Page 2
Page 3
Page 4
Page 5
Page 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AlterPath Manager 2500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cyclades AlterPath Manager 2500

Summary of Contents for Cyclades AlterPath Manager 2500

  • Page 1 1. Rack Mounting the AlterPath Manager For the AlterPath Manager E2000, 2500 and 5000, two brackets and the necessary mounting screws are supplied. For the AlterPath Manager 2500 and 5000, a set of sliding rails are also provided (the small “ear” brackets are already attached).
  • Page 2 AlterPath Manager E2000, 2500, 5000 Quick Start Guide a. The shorter end brackets mount onto the front of the outer rails. Use the two round screw holes in each front end bracket to mount it in a fixed position to its respective outer rail. b.
  • Page 3 Press and hold for 1 second to power on the system. Press and hold for 4 seconds to reset the system. Press and hold for 10 seconds to shut down the system. Figure 5: APM 5000 Front View with Control Buttons Fans Redundant connectors...
  • Page 4 AlterPath Manager E2000, 2500, 5000 Quick Start Guide Figure 7: Single Network Setup To Set up a Private Network 1. Connect an Ethernet cable from the “Eth1” port on the AlterPath Manager to a hub or switch that is connected to your public Ethernet LAN. Refer to the “Private Network Setup” diagram that follows.
  • Page 5 Figure 8: Private Network Setup 3. Running the First Time Configuration Wizard The First Time Configuration Wizard includes parameters such as root and admin passwords, network configuration parameters, and time and date.You need to run the First Time Configuration Wizard from a serial terminal (or terminal emulator such as Hyper Terminal) connected to the serial console port on the AlterPath Manager.
  • Page 6 Boot information will scroll up on the screen for a short time until the system is ready for initial configuration input data. Welcome to Cyclades-APM! Since this is the first time you are booting your APM, you need to answer some basic configuration questions. Once this is done, the other APM configuration parameters can be set through its Web Management Interface (WMI).
  • Page 7 3) 10 Mbps, half duplex 4) 100 Mbps, full duplex 5) 100 Mbps, half duplex 6) 1000 Mbps, full duplex 7) 1000 Mbps, half duplex • Enter the system's hostname (max 30 characters) • Enter the system's domain name (max 60 chars) •...
  • Page 8 APM during the First Time Configuration session. 3. When the Login screen appears, log in to the APM as admin. Use the password that you assigned to admin during the First Time Configuration session. Cyclades Corporation 3541 Gateway Boulevard Fremont, CA 94538 USA 1.888.CYCLADES (292.5233)
