Related Manuals for USCutter MH Basic Stand
Summary of Contents for USCutter MH Basic Stand
- Page 1 BASIC STAND SETUP Ver. 1.3, May 2024...
- Page 2 TABLE OF CONTENTS Basic Stand - Parts ....................................Page 3 Basic Stand - Setup ....................................Page 4-5...
- Page 3 BASIC STAND - PARTS Left Rollerbar Arm Right Rollerbar Arm Stand Hardware Right Leg Left Leg Crossbar (Length Determined By Cutter Width) Stand Feet (Left/Right) Rollerbar (Length Determined By Cutter Width)
- Page 5 BASIC STAND - SETUP Step 1: Attach the Crossbar (5) & Rollerbar Arm(1) to the Leg (3) With 2 bolts & washers form the Stand Hardware (Repeat for other side using parts 2,4,& 5). Parts Needed: Note: When Installing the Crossbar (5) the two holes in the center should face up to store extra bladeholders or the...
- Page 6 Step 3: Place the Rollerbar (7) in the slots on the Rollerbar Arms (1 & 2). Parts Needed: Note: To install a vinyl roll put the Rollerbar (7) through the center of the vinyl roll core. Step 4: Place the vinyl cutter feet into the corresponding holes on the Stand Legs (3 &...
