P55 Deluxe3
Intel
P55 Chipset
®
Product Brief
- ASRock DuraCap (2.5 x longer life time), 100% Japan-made
high-quality Conductive Polymer Capacitors
- Advanced V8 + 2 Power Phase Design
- Supports Dual Channel DDR3 2600+ (OC)
- Supports ATI™ CrossFireX™ and Quad CrossFireX™
- Supports NVIDIA
Quad SLI™ and SLI™
®
- 1 x Powered eSATAIII/USB Connector, 2 x SATA3 6.0 Gb/s
connector, 2 x USB 3.0 Ports
- EuP Ready, Combo Cooler Option (C.C.O.) , Dr. Debug
- Smart Swith Design : Power / Reset / Clear CMOS Switch
with LED
- Supports ASRock Instant Boot, Instant Flash, OC DNA,
Good Night LED, Multi-Speed Fan Control, OC Tuner, IES
- 7.1 CH HD Audio with Content Protection, DAC with 110dB
dynamic range (VIA
VT2020 Audio Codec) , support
®
Premium Blu-ray audio
- Free Bundle: CyberLink DVD Suite - OEM and Trial;
Creative Sound Blaster X-Fi MB - Trial
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
ww w. a s ro ck. c om
Detail Specification
- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
Platform
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
CPU
- Supports Intel
LGA1156 Package
- Advanced V8 + 2 Power Phase Design
- Supports Intel
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
Chipset
- Intel
P55
®
- Dual Channel DDR3 memory technology
Memory
- 4 x DDR3 DIMM slots
- Supports DDR3 2600+(OC)/2133(OC)/1866(OC)/1600/1333/1066
non-ECC, un-buffered memory
- Max. capacity of system memory: 16GB
- Supports Intel
- 2 x PCI Express 2.0 x16 slots (Single at x16 or Dual at x8/x8 mode)
Expansion Slot
- 2 x PCI Express 2.0 x1 slots (2.5GT/s)
- 2 x PCI slots
- Supports ATI
TM
- Supports NVIDIA
Audio
- 7.1 CH HD Audio with Content Protection
- DAC with 110dB dynamic range (VIA
- Premium Blu-ray audio support
LAN
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Coaxial SPDIF Out Port
- 1 x Optical SPDIF Out Port
- 5 x Ready-to-Use USB 2.0 Ports
- 1 x Powered eSATAIII/USB 2.0 Connector
- 2 x Ready-to-Use USB 3.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- 1 x IEEE 1394 Port
- 1 x Clear CMOS Switch with LED
- HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
- 2 x SATA3 6.0 Gb/s connectors by Marvell SE9128, support
SATA3
hardware RAID (RAID 0 and RAID 1), NCQ, AHCI and "Hot Plug"
functions (SATA3_2 connector is shared with eSATA3 port)
USB 3.0
- 2 x USB 3.0 ports by NEC MPD720200, support USB 1.0/2.0/3.0 up
to 5Gb/s
Connector
- 6 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1,
RAID 10, RAID 5, JBOD and Intel
Hot Plug functions
- 2 x SATA3 6.0 Gb/s connectors
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- 1 x IEEE 1394 header
- 1 x TPM header
- 1 x Chassis Intrusion header
- 1 x Power LED header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- CD in header
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
- 1 x Dr. Debug with LED
Smart Switch
- 1 x Power Switch with LED
- 1 x Reset Switch with LED
- 1 x Clear CMOS Switch with LED
BIOS Feature
- 16Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM, SB, VTT, PCH PLL Voltage Multi-adjustment
- Supports I. O. T. (Intelligent Overclocking Technology)
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version), ASRock Software
Suite (CyberLink DVD Suite - OEM and Trial; Creative Sound Blaster
X-Fi MB - Trial)
Unique Feature
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- Combo Cooler Option (C.C.O.)
- Good Night LED
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- CPU/Chassis Fan Multi-Speed Control
- CASE OPEN detection
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft
Windows
OS
®
64-bit compliant
Certifications
- FCC, CE, WHQL
- EuP Ready (EuP ready power supply is required)
Accessories
- 1 x ASRock SLI_Bridge_2S Card
- Quick Installation Guide, Support CD, I/O Shield
- Floppy/ATA 133 Cables
- 4 x SATA Data Cables (Optional)
- 2 x SATA 1 to 1 Power Cables (Optional)
®
Core
TM
i7 / i5 / i3 and Pentium
®
G6950 Processors in
Turbo Boost Technology
®
®
Extreme Memory Profile (XMP)
CrossFireX
and Quad CrossFireX
TM
TM
SLI
and Quad SLI
®
TM
TM
VT2020 Audio Codec)
®
®
Rapid Storage), NCQ, AHCI and
7 / 7 64-bit / Vista
/ Vista
64-bit / XP / XP
®
TM
