- Page 1 MCR Series TRANSMITTERS Instruction Manual...
- Page 3 Specifications may change without prior notice. Manufacturer info@PreSens.de PreSens Am BioPark 11 Phone +49 941 94272100 www.PreSens.de Precision Sensing GmbH 93053 Regensburg, Germany +49 941 94272111 © 2023 PreSens Precision Sensing GmbH www.PreSens...
-
Page 5: Table Of Contents
Table of Contents Preface ........................... 7 Intended Use ......................... 8 Safety Notes ........................9 Description of the MCR Series Devices ..............11 Set-Up .......................... 12 Connecting MCR Series Devices................12 Troubleshooting for USB Handling ................14 Technical Data ......................15 Operational Notes ...................... - Page 6 Tab. 3 Power supply specifications ..................15 Tab. 4 Digital interface specifications ................15 Tab. 5 Environmental conditions ..................15 Tab. 6 Device dimensions & weight ................... 16 Tab. 7 Device labelling ......................16 © 2023 PreSens Precision Sensing GmbH www.PreSens...
-
Page 7: Preface
You have chosen a new, innovative technology for measuring oxygen, pH and CO The MCR series devices are compact fiber optic meters. They are based on a novel technology, which creates very stable, internally referenced measured values. This allows a more flexible use of oxygen sensors in various fields of interest. -
Page 8: Intended Use
Intended Use MCR Series 2 Intended Use The MCR series devices are USB powered multichannel desktop meters for indoor use and wired O , pH, CO , and temperature measurements. The devices are designed for end users in the academic field, as well as for use in research and development. For pH and CO measurements only aqueous solutions with sufficient ionic strength (>... -
Page 9: Safety Notes
Basic research on non-human samples is not affected. Control of the device is only permitted via the PreSens Measurement Studio software. The manufacturer accepts no liability for control via other means. Process monitoring in industrial plants is explicitly excluded. This also includes the control and monitoring of food and its manufacturing processes. - Page 10 Safety Notes MCR Series PreSens is explicitly not liable for direct or indirect losses caused by the application of these measurement systems. In particular it has to be considered that malfunctions can occur due to the naturally limited lifetime of the sensor depending on the respective application. The set- up of backup measurement stations is recommended when using the sensors in critical applications to avoid consequential losses.
-
Page 11: Description Of The Mcr Series Devices
4 Description of the MCR Series Devices Fig. 1 MCR-O1P1C1 and MCR-O2P1C1 The MCR series are compact multi-channel meters for indoor use which have channels for oxygen (0 – 100 % O ), pH (5.5 – 8.5 pH) and CO (1 –... -
Page 12: Set-Up
MCR Series 5 Set-Up 4.1 Connecting MCR Series Devices Remove the protective cap from the male plug on the polymer optical fiber (or the probe) and insert it in the SMA connector of the MCR device. The safety nut must be screwed Fig. - Page 13 MCR will show in Device section. For further details on how to use the PreSens Measurement Studio please refer to the software instruction manual. © 2023 PreSens Precision Sensing GmbH...
-
Page 14: Troubleshooting For Usb Handling
PreSens Measurement Studio 2 Devices section, please consider making the following changes: PreSens recommends the use of a dedicated USB 2.0 PCI Card to connect and handle USB PreSens Devices with a Desktop PC. In order to enhance the system stability, avoid the use of USB hubs and connect PreSens Devices directly to your PC / notebook USB Ports. -
Page 15: Technical Data
Tab. 5 Environmental conditions ENVIRONMENTAL CONDITIONS Operating temperature 0 °C to + 50 °C Storage temperature - 20 °C to +70 °C Relative humidity 0 % to 80 % (non-condensing) Protection class No IP protection class © 2023 PreSens Precision Sensing GmbH... -
Page 16: Tab. 6 Device Dimensions & Weight
Tab. 6 Device dimensions & weight DIMENSIONS / WEIGHT W x L x H ca. 164 mm x 80 mm (with SMA connectors) x 50 mm Weight 430 g Tab. 7 Device labelling DEVICE LABELLING (Example) © 2023 PreSens Precision Sensing GmbH... -
Page 17: Operational Notes
Germany Phone +49 941 94272100 +49 941 94272111 info@PreSens.de www.PreSens.de Please contact our service team in case of any questions. We look forward to helping you and are open to any proposition or criticism. © 2023 PreSens Precision Sensing GmbH... -
Page 18: Concluding Remarks
8 Concluding Remarks Dear Customer, With this manual, we hope to provide you with an introduction to work with the MCR series fiber optic multiparameter meters. This manual does not claim to be complete. We are endeavored to improve and supplement this version. - Page 19 Manufacturer PreSens Precision Sensing GmbH Am BioPark 11 93053 Regensburg Germany Phone +49 941 94272100 +49 941 94272111 info@PreSens.de www.PreSens.de © 2023 PreSens Precision Sensing GmbH www.PreSens...
