Summary of Contents for KVMSwitchTech RKM-8U-19QD
- Page 1 RKM-8U-19QD 8U Quad Display Options : - DC power User Manual 19” Widescreen LCD 1440 x 900 UM-RKM-8U-W19QD www.kvmswitchtech.com...
- Page 2 Re-position or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. UM-RKM-8U-W19QD www.kvmswitchtech.com...
-
Page 3: Table Of Contents
Contents < Part. 1 > RKM-8U-19QD Package Content Structure Diagram & Dimension P.1 - 2 Installation < Part. 2 > Specifications / OSD Product Speci cations P.4 - 5 On-screen Display Operation ( OSD ) < Part. 3 > Options 48V, 24V or 12VDC power <... -
Page 4: Package Content
< Part 1 > < 1.1 > Package Content RKM-8U-19QD unit X 1 - 6ft VGA cable X 1 - Power adapter X 1 - Power cord X 1 < 1.2 > Structure Diagram UM-RKM-8U-W19QD www.kvmswitchtech.com... - Page 5 < 1.2 > Dimension RKM-8U-19QD Front View Side View UNIT : 1mm = 0.03937 inch Bottom View Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 480 x 72.5 x 354.8 mm 539 x 129 x 529 mm 9.5 kg...
-
Page 6: Installation
Mount the display panel with M6 screw set. M6 screw x 8 pcs required ( Left & right side ). M6 screw sets are not provided. S t e p Fix the LCD into the rack. UM-RKM-8U-W19QD www.kvmswitchtech.com... -
Page 7: Product Specifications
< Part 2 > < 2.1 > Product Specifications RKM-8U-19QD Manufacturer Panel Panel Size ( diagonal ) 19-inch Widescreen TFT color LCD Display pixel ( dots x lines ) 1440 x 900 Brightness ( typ. ) Contrast Ratio ( typ. ) - Page 8 848 x 480 x 60Hz 800 x 600 x 60 / 72 / 75Hz 720 x 400 x 70Hz 640 x 480 x 60 / 72 / 75Hz 640 x 400 x 70Hz 640 x 350 x 70Hz UM-RKM-8U-W19QD www.kvmswitchtech.com...
-
Page 9: On-Screen Display Operation ( Osd )
< 2.2 > On-screen Display Operation ( OSD ) RKM-8U-19QD UM-RKM-8U-W19QD www.kvmswitchtech.com... -
Page 10: Part. 3 > Options
36 — 75V Input range: Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA Output rating Output voltage: 12-Volt 12-Volt 12-Volt Output current: 4.16A 4.16A 4.16A Efficiency UM-RKM-8U-W19QD www.kvmswitchtech.com... -
Page 11: Qd Connection
< Part 4 > < 4.1 > QD Connection RKM-8U-19QD VCR in : This BNC connector is connected to video output from VCR/DVR. A pre-recorded quad screen signal from a tape can be played back through a VCR/DVR and displayed on the video output channels. Push the VCR button (#2) to switch the device to VCR Playback mode. -
Page 12: Qd Alarm Connection & Operation
*. In order to make use of the alarm called full screen display function, the VIDEO IN connector from the VCR has to be connected to LIVE monitor connector of the device. If more than one sensor are trigged, VCR will then record all the events in full screen mode accordingly. UM-RKM-8U-W19QD www.kvmswitchtech.com... - Page 13 < 4.2 > QD ALARM Connection & Operation RKM-8U-19QD 3 Sensor Activated Alarm The unit is equipped with 4 alarm sensor inputs. If any alarm is activated: the built-in buzzer and the alarm output control relay contact will be activated.
-
Page 14: Qd Remote Control Connection & Operation
< 4.3 > QD Remote Control Connection & Operation P.11 UM-RKM-8U-W19QD www.kvmswitchtech.com... - Page 15 < 4.3 > QD Remote Control Connection & Operation RKM-8U-19QD The device can be controlled via the male type 9 pin D-sub/RS-232 connector to a computer using ASCII code. 1. Pin assignment of the male type 9 pin D-sub connector:...
- Page 16 CH3 & 4 in Freeze mode XX-DF Buzzer/VCR ON CH1, 3, & 4 in Freeze mode XX-7F Security lock ON CH2, 3, & 4 in Freeze mode XX-3F Buzzer & Security lock ON (Stop) CH1, 2,3, & 4 in Freeze mode P.13 UM-RKM-8U-W19QD www.kvmswitchtech.com...
- Page 17 There are total 2 bytes of the status codes. Byte one, the rst 8 bits, shows the current status of the operation modes that the unit is in. Byte two, the second 8 bits, shows the current status of the alarm operations of the unit. P.14 UM-RKM-8U-W19QD www.kvmswitchtech.com...
- Page 18 Sensor activated Alarm Video Loss Alarm 0001 = CH1 activated 0001 = CH1 activated 0010 = CH2 activated 0010 = CH2 activated 0100 = CH3 activated 0100 = CH3 activated 1000 = CH4 activated 1000 = CH4 activated P.15 UM-RKM-8U-W19QD www.kvmswitchtech.com...
-
Page 19: Qd Osd Operation
< 4.4 > QD OSD Operation RKM-8U-19QD Lock: Security locks out button. Push this button for 2 seconds to enable control panel lock out function. Push this button again for 2 seconds to disable the function. VCR: Push this button to enter into VCR Playback/Zoom operation. In this mode, the output video is displaying the video signal from VCR. -
Page 20: Qd On-Screen Menu
YYYY HH:MM:SS” format for PAL model. 1.4 TITLE/TIME/DATE disable and enable on LIVE and QUAD video output channel: The Title/Time/Date display on each output channel can be enabled or disabled by setting ON or OFF in the corresponding entry. P.17 UM-RKM-8U-W19QD www.kvmswitchtech.com... - Page 21 < 4.5 > QD On-screen Menu RKM-8U-19QD 2 Page 2 of the setup menu- Alarm Setting Push Setup buttons (#1, #2) simultaneously and push (#1) button again to display page 2 of the setup menu on the screen. This Alarm Setting menu is used to set the desired alarm con guration like sensor type, sensor sensitivity, alarm hold duration, and buzzer.
- Page 22 Press the Sequence button (#3) to OFF to release this mode. P.19 UM-RKM-8U-W19QD www.kvmswitchtech.com...
-
Page 23: Qd Vcr Operation
< 4.6 > QD VCR Operation RKM-8U-19QD Zoom on VCR playback operation: Push VCR button (#2) to ON will switch the device to VCR playback mode. Under this mode, if the device is on quad display mode, a pr-recorded quad display video in the tape will be shown on the screen. If the device is in Full screen display mode, push any channel select buttons (#5) will select and expand the corresponding quadrants of the pre- recorded video to full screen display. - Page 24 The company reserves the right to modify product specifications without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2013 KVMSwitchTech All rights reserved. UM-RKM-8U-W19QD www.kvmswitchtech.com...
