User Manual RKD-KVM-20 / RKDS-KVM-20 Series - 1U 20" LCD keyboard drawer - Resolution up to 1600 x 1200 - Full range KVM options WRKD-KVM-19 / WRKDS-KVM-19 Series - 1U widescreen 19" LCD keyboard drawer - Resolution up to 1440 x 900 - Full range KVM options... -
Page 2: Table Of Contents
Contents Chapter 1 Getting Started Important Safeguards ............1 Regulatory Notice ..............2 Package Contents ..............3 Before Installation ..............4 Unpacking ................4 Optional Accessories ............. 4 Peripheral Products ............... 5 Structure Diagram ..............6 Installation ................7-12 1.10 How to Use the Slide ............13 1.11 How to Use LCD Keyboard Drawer ........ - Page 3 Contents Chapter 4 Optional Specification KVM Options .................26 DVI-D Input Option ...............26 BNC+ S-Video Option ............26 Audio Option .................27 DC power Options ..............28 Chapter 5 Troubleshooting ........Chapter 6 Dimensions ..........
-
Page 5: Important Safeguards
Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover Any product, on which the serial number has been defaced, modi ed or removed. -
Page 6: Regulatory Notice
Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 7: Package Contents
Chapter 1 1.3 Package Contents LCD keyboard drawer x 1 pc KVMCB-6 USB 2-in-1 KVM cable x 1 pc KVMCE-6 Combo 4-in-1 KVM cable x 1 pc (for LS / WS series) (for L / W series) User manual x 1 pc Power cord x 1 pc Auto switch power adapter ( for external power version) x 1 pc Mounting bracket x 2 pcs... -
Page 8: Before Installation
Chapter 1 1.4 Before Installation It is very important to locate the LCD Keyboard Drawer in a suitable environment. The surface for placing and fixing the LCD Keyboard Drawer should be stable and level or mounted into a suitable cabinet. Make sure the place has good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. -
Page 9: Peripheral Products
Chapter 1 1.7 Peripheral Products Item Description Matrix Cat6 16 port KVM Matrix IP Cat6 16 port KVM Matrix Cat6 KVM Matrix Cat6 32 port KVM Matrix IP Cat6 32 port KVM Matrix DB-15 8 port KVM Matrix IP DB-15 8 port KVM Matrix DB-15 KVM Matrix DB-15 16 port KVM Matrix IP DB-15 16 port... -
Page 10: Structure Diagram
Chapter 1 1.8 Structure Diagram REGULAR / SUN series WIDESCREEN / SUN WIDESCREEN series... -
Page 11: Installation
Chapter 1 1.9 Installation For REGULAR & SUN series... - Page 12 Chapter 1 1.9 Installation...
- Page 13 Chapter 1 1.9 Installation...
- Page 14 Chapter 1 1.9 Installation P.10...
- Page 15 Chapter 1 1.9 Installation For WIDESCREEN & SUN WIDESCREEN series P.11...
- Page 16 Chapter 1 1.9 Installation P.12...
-
Page 17: How To Use The Slide
Chapter 1 1.10 How to Use the Slides P.13... -
Page 18: How To Use Lcd Keyboard Drawer
Chapter 1 1.11 How to Use LCD Keyboard Drawer P.14... -
Page 19: Rkds-Kvm-20 / Wrkds-Kvm-19 (Single Console) - Use Kvmcb-6 To Connect To Server Via Usb Interface
Chapter 1 1.12 RKDS-KVM-20 & WRKDS-KVM-19 (Single console) Figure 7. Example of connecting KVMCB-6 2-in-1 USB KVM cable to server via USB interface 1.13 RKDS-KVM-20 & WRKDS-KVM-19 (Single console) - Use KVMCB-6 to connect to KVM via USB interface Figure 8. Example of connecting KVMCB-6 2-in-1 USB KVM cable to KVM via USB interface Remarks : The above connection is only for the LCD keyboard without KVM switch built-in. -
Page 20: Use Kvmce-6 To Connect To Server Via Ps/2 Interface
Chapter 1 1.14 RKD-KVM-20 & WRKD-KVM-19 (Single console) - Use KVMCE-6 to connect to server via PS/2 interface Figure 9. Example of connecting KVMCE-6 4-in-1 Combo KVM cable to server via PS/2 interface 1.15 RKD-KVM-20 & WRKD-KVM-19 (Single console) - Use KVMCE-6 to connect to KVM via PS/2 interface Figure 10. -
Page 21: Rkd-Kvm-20 / Wrkd-Kvm-19 (Single Console) - Use Kvmce-6 To Connect To Server Via Usb Interface
Chapter 1 1.16 RKD-KVM-20 & WRKD-KVM-19 (Single console) Figure 11. Example of connecting KVMCE-6 4-in-1 Combo KVM cable to server via USB interface 1.17 RKD-KVM-20 & WRKD-KVM-19 (Single console) - Use KVMCE-6 to connect to KVM via USB interface Figure 12. Example of connecting KVMCE-6 4-in-1 Combo KVM cable to KVM via USB interface Remarks : The above connection is only for the LCD keyboard without KVM switch built-in. -
Page 22: On-Screen Display Operation
Chapter 2 2.1 On-screen Display Operation P.18... -
Page 23: On-Screen Menu
Chapter 2 2.2 On-screen Menu P.19... -
Page 24: Speci Fi Cations
Chapter 3 3.1 REGULAR & SUN series Specifications REGULAR P.20... -
Page 25: Speci Fi Cations
Chapter 3 3.1 WIDESCREEN & SUN WIDESCREEN series Specifications WIDESCREEN SUN WIDESCREEN Note: WRKD-KVM-19 / WRKDS-KVM-19 series in single console, with Combo Cat6 KVM or Combo DB-15 KVM integration is UL approved P.21... -
Page 26: Keyboard & Mouse
Chapter 3 3.2 Keyboard & Mouse For RKD-KVM-20 series P.22... - Page 27 Chapter 3 3.2 Keyboard & Mouse For WRKD-KVM-19 series P.23...
-
Page 28: Keyboard & Mouse
Chapter 3 3.2 Keyboard & Mouse For RKDS-KVM-20 & WRKDS-KVM-19 series P.24... -
Page 29: How To Use "Ns" Keyboard
Chapter 3 3.3 How to Use "NS" keyboard NS SUN-compatible keyboard incorporates SUN short-cut keys. P.25... -
Page 30: Kvm Options
Chapter 4 4.1 KVM Options Our KVM is designed to seamlessly integrate into the rear of our full range of LCD drawer solutions: For KVM operation, please refer to KVM user manual Option with Multiple consoles Matrix KVM Option with high density & cost efficient Combo KVM integration with either 8 / 16 / 32 ports Option with low cost PS/2 KVM Please ask your supplier for full KVM details Remarks... -
Page 31: Audio Option
Chapter 4 4.4 Audio Option P.27... -
Page 32: Dc Power Options
4.5 DC Power Options Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 — 18V 18 — 36V 36 — 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA Output rating Output voltage:... -
Page 33: Chapter 5 Troubleshooting
Chapter 5 5.1 Troubleshooting For RKDS-KVM-20 & WRKDS-KVM-19 series 1. How can I adjust the monitor resolution to 1152 x 900 for SUN Micro system ? The LS solution LCD keyboard drawer will automatically detect the 1152 x 900 resolution, so no user con guration should be necessary. -
Page 34: Chapter 6 Dimensions
Chapter 6 6.1 Dimensions Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 442 x 650 x 44 mm 589 x 856 x 168 mm 20 kg 26 kg RKD-KVM-20 17.4 x 25.6 x 1.73" 23.2 x 33.7 x 6.6"... - Page 36 The company reserves the right to modify product speci cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2010 AHS Ltd. All rights reserved. CV-LW3R-0111V4...
