SPECIFICATIONS
Frequency Response, 1 Watt/1 Meter
on
Axis,
Swept Sine-Wave Input. Half-
Space Anechoic Environment. ±3 dB
(see Figure 1):
60-18.000 Hz
Low-Frequency 3-dB-Down Point:
60 Hz
Usable Low-Frequency Limit
(10-dB-down point):
47 Hz
Half-Space Reference Efficiency:
0.6%
Long-Term Average Power-Handling
Capacity per EIA Standard RS-426A
(see Power-Handling Capacity section):
100 watts
Maximum Woofer Acoustic Output:
0.6 watts
Sensitivity (SPL at t meter, 1 watt inpuL
anechoic environment, band-limited pink-
noise signal, 300-2.000 Hz):
88 dB
Dispersion Angle Included by 6-dB-Down
Points on Polar Responses, Horizontal
and Vertical Planes. Indicated One-Third-
Octave Bands of Pink Noise
(see Figure 2):
500-1.000 Hz:
170° ±30"
1,000-10,000 Hz:
120
' ±
20
"
10,000-20,000 Hz:
70" ±30"
Directivity Factor R, (Q), 800-16,000 Hz
Median (see Figure 4):
7.3 (+14 9, -4.5)
Directivity Index D,, 800-16,000 Hz Median
(see Figure 4):
8 6 dB +4.8/-4 1 dB
Distortion. 0.1 Full Power Input
(see Figure 5),
Second Harmonic,
100 Hz:
8
%
1,000 Hz:
<1%
10,000 Hz:
<
1
%
Third Harmonic,
100 Hz:
■ 1.4%
1,000 Hz: '
<
1
%
10,000 Hz:
<
1
%
Distortion, 0.01 Full Power Input
(see Figure 6),
Second Harmonic,
100 Hz:
7%
1,000 Hz:
<
1
%
10,000 Hz:
<
1
%
Third Harmonic.
100 Hz:
<
1
%
1,000 Hz:
<
1
%
10,000 Hz:
<
1
%
Transducer Complement,
High Frequency:
2.5- cm (1-in.) tweeter with 12 5-cm
(5-in.) Direktor'"
Low Frequency:
16.5- cm (6.5-in,) woofer
Box Tuning Frequency:
60 Hz
S-60/S-60T
Two-Way
Speaker System
• Two-way compact system
• Constant-directivity system
for uniform coverage
• 6.5-inch woofer
• One-inch tweeter with
dispersion-controlling
Direktor™
• Automatically resetting
tweeter-protection circuit
• Optional 60-W transformer
with selectable taps (S-60T)
• Available in paintable white
or black
Crossover Frequency:
2,500 Hz
Crossover Slope:
12 dB per octave
Impedance,
S-60,
Nominal:
8 ohms
Minimum:
5 ohms
S-60T:
See Table 1
Input Connections,
S-60:
'/4-inch phone jack with parallel 5-way
binding post
S-60T:
5-way binding post with weatherproof
cover
Materials.
Enclosure and Baffle Board:
Injection-molded plastic, black or white
Grille:
Punched metal, powder coated,
black or white
Mounting:
EV S-60MB mounting bracket or
OmniMount* Series 75 mounting
hardware, black or white'
Dimensions,
Height:
35.0 cm (13.8 in.)
Width:
22.0 cm (8.7 in.)
Depth:
21.1 cm (8.4 in.)
