Summary of Contents for Antigravity Batteries MICRO-START XP-15
- Page 1 ANTIGRA VITY BA TTERIES MICRO-ST ART XP-15 USER MANUAL...
-
Page 2: Table Of Contents
XP-15 USER MANUAL CONTENTS: WELCOME Page 1 SAFETY PRECAUTIONS Page 2 PRODUCT OVERVIEW Page 3 KIT ITEMS Page 4 PRODUCT SPECS PRODUCT USE Page 5 CHARGING THE XP-15 CHARGING DEVICES Page 6 USING AIR INFLATOR JUMP-STARTING VEHICLES Page 7 USING FORCED START MODE TROUBLESHOOTING Page 8 USING VOLTMETER... -
Page 3: Welcome
Welcome THANK YOU Thank you for purchasing the Antigravity Batteries MICRO-START XP-15. The XP-15 is an ultra compact Jump- Starter, Personal Power Supply and Tire Inflator. Just charge it and take Portable Power with you wherever you go, no electricity needed. It can jump-start your vehicles, inflate passenger Car and Truck Tires, and power or charge USB Devices. -
Page 4: Safety Precautions
XP-15 USER MANUAL Safety Precautions SAFETY PRECAUTIONS READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY RESULT IN ELECTRICAL SHOCK, EXPLOSION, FIRE, WHICH MAY RESULT IN SERIOUS INJURY, DEATH OR PROPERTY DAMAGE. Do not leave the product in, or expose product to extremely high temperatures such as on dashboards or other extremely hot areas above 110°F (43°C). -
Page 5: Product Overview
XP-15 USER MANUAL Product Overview USB-C IN/OUT (PD60W M DISPLAY SCREEN JUMP START USB-A OUT PORT (QC3.0, 5V/9V/12V) LED FLaSHLIGHT aIR INFLaTOR FLaSHLIGHT BUTTON POWER BUTTON TIRE PRESSURE PRESET BUTTON BaR/PSI BUTTON INFLaTOR STaRT-STOP BUTTON ANTIGRA VITY BA TTERIES 310 527 2330 INFO@ANTIGRAVITYBATTERIES.COM Page 3 of 12... -
Page 6: Kit Items
XP-15 USER MANUAL Kit Contents aIR HOSE* JUMPER CLaMPS xP-15 POWER SUPPLY USB-A to USB-C USB-C to USB-C CABLE CABLE *Also includes Presta Valve Adaptor, Nozzle Adapters, Ball Needle, and Accessories Bag Specifications CAPACITY: 55.5Wh STARTING CURRENT: 1000A PEAK CURRENT: 2000A PRODUCT DIMENSIONS (LWH): 10.375 x 6.375 x 2.5 in (264*162*64mm) USB-C IN/OUT: PD60W Max (5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A) USB-A OUT: QC3.0 18W Max (5V/3A, 9V/2A, 12V/1.5A) -
Page 7: Product Use
XP-15 USER MANUAL Product Use POWER ON/OFF Press the Power Button or the LED Light button to turn on the XP-15. It will automatically turn off when not powering anything. DIGIT AL DISPLA Y SCREEN Fast-Charging Indicator XP-15 is being recharged LED Power Indicator USB Output Port(s) active Abnormal State Error Indicator... -
Page 8: Charging Devices
XP-15 USER MANUAL CHARGING USB DEVICES (USB-C & USB-A OUT) The XP-15 charges a variety of USB Devices. It has one USB-C and one USB-A Quick Charge port. Two cables are included but you can also use other cables you may have. Plug the provided USB Cable (or any standard one) into corresponding USB Output Port on XP-15. -
Page 9: Jump-Starting Vehicles
XP-15 USER MANUAL JUMP-ST ARTING A VEHICLE Caution should always be used when Jump Starting. READ ALL SAFETY INSTRUCTIONS. Make sure all the Vehicle’s Lights, Radios, Air Conditioning and Accessories are turned off. Confirm you are connecting to a 12-Volt Battery System. Connect the Clamps tip to the XP-15 Jump-Start Port, making sure it’s fully seated. -
Page 10: Troubleshooting
USER MANUAL Troubleshooting Error Code Cause Solution High cell voltage difference Stop using and contact Antigravity Batteries Overcharging protection Disconnect charging Low voltage protection Connect to a charger to recharge XP-15 Discharge over-temperature protection Do not use, wait until the device cools... -
Page 11: Using Voltmeter
XP-15 USER MANUAL Voltmeter USING THE VOL TMETER FUNCTION You can use the Voltmeter function by itself, without performing a jump-start. With the battery clamps connected to the XP-15 and vehicle battery, the Display will show a flashing START icon along with Voltage, meaning it’s in Start mode. - Page 12 XP-15 USER MANUAL HOW DO I TURN IT OFF? The XP-15 will turn off automatically after 30s when it’s not used. Disconnect Clamps and other attachments when not in use. CAN THE XP-15 CHARGE OTHER DEVICES WHILE IT'S BEING CHARGED? Yes.
-
Page 13: Warranty
18 months from the date of purchase (the “Warranty Period”). Visit our website for full Warranty terms and to Register your MICRO-START XP-15. The Warranty is not Transferable. The Warranty is made to the original purchaser from ANTIGRAVITY BATTERIES and “Authorized Resellers” and does NOT extend to any other persons or entities. -
Page 14: Customer Service
XP-15 USER MANUAL Customer Service 18 Months Limited Warranty Service Lifetime Technical Support info@antigravitybatteries.com antigravitybatteries https://antigravitybatteries.com/help-center/ 310-527-2330 Mon-Fri PST 7:30am-4pm Live Chat with Our Techs Attention Be sure to follow all Safety Precautions and Operating Precautions found in the beginning of this manual. Do Not Submerge In or Expose to Water Do Not Disassemble Do Not Drop...
