ASROCK P43DE2 Specifications

P43DE2
Intel ® P43 + ICH10 Chipsets

Product Brief

- Solid Capacitor for CPU power
- Supports FSB1600/1333/1066/800 MHz CPUs
- Supports Dual Channel DDR2 1066
- PCIE Gigabit LAN
- Supports ASRock Instant Boot, Instant Flash,
OC Tuner, IES, OC DNA
- Free Software : CyberLink DVD Suite - OEM
and Trial; Creative Sound Blaster X-Fi MB -
Trial
- ErP/EuP Ready
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.

Detail Specification

Platform
CPU
Chipset
Memory
Featuring the
Intel P43 Express Chipset
®
Expansion Slot
Audio
LAN
Rear Panel I/O
Connector
BIOS Feature
Support CD
Unique Feature
Hardware Monitor
OS
Certifications
Accessories
www.as rock.com
- ATX Form Factor: 11.6-in x 7.5-in, 29.5 cm x 19.1 cm
- Solid Capacitor for CPU power
- LGA 775 for Intel Core 2 Extreme / Core
® TM
Core TM 2 Duo / Pentium ® Dual Core / Celeron
/ Celeron , supporting Penryn Quad Core Yorkfield and
®
Dual Core Wolfdale processors
- Supports FSB1600/1333/1066/800 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Northbridge: Intel P43
®
- Southbridge: Intel ICH10
®
- Dual Channel DDR2 memory technology
- 2 x DDR2 DIMM slots
- Supports DDR2 1066/800/667 non-ECC, un-buffered
memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express 2.0 x16 slot (blue @ x16 mode)
- 3 x PCI Express x1 slots
- 2 x PCI slots
- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111C
- Supports Wake-On-LAN
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
- 4 x SATAII 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug functions
- 1 x Power LED header
- 1 x IR header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 4Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU VID, VCCM, NB, SB, VTT, CPU PLL Voltage
Multi-adjustment
- Supports I. O. T. (Intelligent Overclocking Technology)
- Drivers, Utilities, AntiVirus Software (Trial Version)
ASRock Software Suite (CyberLink DVD Suite - OEM
and Trial; Creative Sound Blaster X-Fi MB - Trial)
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft Windows 7 / 7 64-bit / Vista
® ®
XP / XP 64-bit compliant
- FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
2 Quad /
TM
® Dual Core
/ Vista 64-bit /
TM TM
