ASROCK N73V-S Brochure

N73V-S
®
NVIDIA GeForce 7050 / nForce 610i Chipset
Product Brief
®
- NVIDIA GeForce 7050, DX 9.0 VGA, Pixel
Shader 3.0, Max. shared memory 256MB
- Supports ASRock Instant Boot
- Supports Smart BIOS, ASRock OC Tuner
(Up to 164% CPU frequency increases)
- Supports Intelligent Energy Saver (Up to 35%
CPU Power Saving)
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
www.as rock.com

Detail Specification

- Micro ATX Form Factor: 9.6-in x 7.0-in, 24.4 cm x 17.8 cm
Platform
CPU - LGA 775 for Intel
TM
Core 2 Duo / Pentium
®
/ Celeron , supporting Penryn Quad Core Yorkfield and
Dual Core Wolfdale processors
- Supports FSB1333/1066/800/533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
®
Chipset - NVIDIA GeForce 7050 / nForce 610i
- 2 x DDR2 DIMM slots
Memory
- Supports DDR2 800/667/533 non-ECC, un-buffered
memory
- Max. capacity of system memory: 16GB
- 1 x PCI Express x16 slot
Expansion Slot
- 1 x PCI Express x1 slot
- 2 x PCI slots
- Integrated NVIDIA
Graphics
- DX9.0 VGA, Pixel Shader 3.0
- Max. shared memory 256MB
Audio - 5.1 CH Windows
(ALC662 Audio Codec)
LAN - Realtek PHY RTL8201EL
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
Rear Panel I/O
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Part: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector
- 4 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0,
RAID 1 and JBOD ), NCQ, AHCI and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x Print port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
®
OS - Microsoft Windows
64-bit compliant
Certifications - FCC, CE
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 133 Cable (Optional)
- 1 x SATA Data Cable (Optional)
- 1 x SATA 1 to 1 Power Cable (Optional)
® TM TM
Core 2 Extreme / Core 2 Quad /
® ®
Dual Core / Celeron Dual Core
®
GeForce 7050
® Vista™ Premium Level HD Audio
® TM TM
XP / XP 64-bit / Vista / Vista
