Warning: Jordan Valve Control Valves must only be used, installed and repaired in accordance with these Installa-
tion & Maintenance Instructions. Observe all applicable public and company codes and regulations. In the event
of leakage or other malfunction, call a qualified service person; continued operation may cause system failure or
a general hazard. Before servicing any valve, disconnect, shut off, or bypass all pressurized fluid. Before disassem-
bling a valve, be sure to release all spring tension.
I
nstallatIon
Sudden release of pressure may result personal
injury or equipment damage if the valve assembly
is installed where service conditions could exceed
the limits on the nameplates. Provide a relief valve
for overpressure protection as required by govern-
ment or accepted industry codes and good engi-
neering practices to avoid such injury or damage.
Upon ordering, the valve configuration and con-
struction materials were selected to meet particular
pressure, temperature, pressure drop, and con-
trolled fluid conditions.
1. Prior to installation of the valve, inspect it and
any associated equipment for damage and
any foreign material. Ensure the valve interior
is clean, that pipelines are free of foreign
material, and that the valve is oriented so that
pipeline flow is in the same direction as the
arrow on the side of the valve.
2. Typical installation of the Mark EZ control
valve is with the actuator vertical above the
valve; however it may be installed in any orien-
tation unless limited by seismic criteria. Other
positions may result in uneven valve plug
and seat ring retainer wear, and
improper operation. With some applications,
the actuator may also need to be supported
when not in a vertical position. For more infor-
mation, contact your Jordan Valve Represen-
tative.
I & M Mark EZ Series
Installation & Maintenance Instructions for the
Mark EZ Series Globe Style Control Valves
3. Use accepted piping and welding prac-
tices when installing the valve in the line.
During the welding procedure internal
elastomeric parts may stay in place.
For flanged valves, use a suitable
gasket between the valve body flange
and pipeline flanges.
Note:
Post weld heat treating may be required depend-
ing on valve body materials used. It is recom-
mended that all trim components be removed
if post weld heat treating is to be performed to
prevent damage to internal elastomeric and plas-
tic parts, as well as internal metal parts. Shrunk-
fit pieces and threaded connections may also
loosen. Contact your Jordan Valve representative
for more information.
4. With a leak-off bonnet construction,
remove the pipe plugs (key 14) to hook up
the leak-off piping.
Install a three-valve bypass around the
control valve assembly if continuous
operation is required during inspection
or maintenance.
5. Refer to the actuator mounting procedure
in the appropriate instruction manual if the
actuator and valve are shipped
separately.
Personal injury could result from packing leak-
age. Valve packing was tightened prior to ship-
ment; however, the packing might require some
readjustment to meet specific service condi-
tions.
