Summary of Contents for Prolux PLCC460S
- Page 2 Important Information Please read the instructions carefully before using this product. Notification - to reduce the risk of fire, electric shock / personal injury / property damage Do not operate the machine unless trained and authorized Still cause the material to cause an explosion or fire, do not use flammable materials in the water tank as a cleaning agent in the machine.
-
Page 3: Specifications
Specifications Model C460S Working width（in） 30.7 Squeegee width（in） Solution tank（L） Recovery tank （L） Drive type Pad assist Brush speed （rpm） Brush pressure （lbs） 17200 Efficiency （sq.ft/h） Voltage（V） 0.73 Suction motor（HP） 0.73 Brush motor（HP） Net weight(lbs) Gross weight(lbs) Package measurement(in) 45*19*43... -
Page 4: Machine Components
Machine Components 1. Control panel 11. Charger case 2. Recovery tank 12. Suction hose assembly 3. Recovery tank cover 13. Squeegee 4. Cap 14. Water level tube 5. Guard wheel 15. Suction motor switch 6. Brush pad 16. Power switch 7. -
Page 5: Packaging Information
Packaging information 1) machine 2）squeegee 3）brush pad/pad driver 4) two batteries 5) battery charger Before the machine is set up or used： 1) Check if the hoe assembly is properly installed 2) Check if the brush is installed correctly 3) The working surface is sufficient to support the weight of the machine 4) Ensure that the recovery tank cover is closed before use Connecting battery 1. -
Page 6: Squeegee Installation
Squeegee installation Loosen the two four-star nuts on the hoe assembly and connect the suction pipe to the suction port on the boring head assembly. Align the four-star nut with the slot of the boring bracket and tighten the nut Brush/pad holder installation and removal... -
Page 7: Solution Tank
Disconnect the power Place the brush/disc under the head assembly. Place the three buttons on the brush/disc in the corresponding mounting holes on the machine head and lock them by turning them clockwise. Press the brush button switch to fully lock the brush/disc ... - Page 8 Adjust the amount of water by adjusting the water valve knob Close the brush and suction button switch at the same time after use Raise the suction assembly by lifting the squeegee lifting rod Machine storage Store in a dry indoor environment ...
-
Page 9: Monthly Maintenance
Maintenance Daily maintenance Wipe the entire machine with a clean/supermarket cloth Empty the water tank by opening the drain valve at the bottom of the clean water tank Drain and flush the recovery tank with clean water ... - Page 10 Rubber strip replacement Remove the hoe assembly from the machine (refer to the hoe installation instructions) Loosen the stainless steel buckle to remove the rubber strip Replace the new strip and reassemble the boring head assembly...
-
Page 11: Troubleshooting
Troubleshooting Problem Phenomenon Solve No power No power connected Connecting battery Insufficient battery, please charge; or Functional No electricity the contactor does not pick up failure Please check the vacuum motor and Vacuum motor does not related circuits, including motor plugs, work relays ... - Page 12 Under no circumstances will Prolux Cleaners or the seller be liable for any loss, damage, expense, or consequential damage arising in connection with the use or inability to use these products.
- Page 13 Product Category Polyethylene Steel Switches, Motors and Structural Body Electrical Parts Labor Foam Parts Paid Machine Years Years Years Years 3yr Switches 3yr or 700hrs (whichever Battery Walk Behind comes first) on the motor Scrubbers 14” and 3yr Electrical Parts 18”...
- Page 14 6. Ozone Generators: Warranty does not ozone cover plates or filters. Warranty shall commence six (6) months from the purchase date by the Prolux Cleaners distributor, or on the purchase date by the original end user. Whichever comes first.
- Page 15 All repair times are subject to the flat rate schedule enclosed in this document. If any operation is not covered in this flat rate schedule, Prolux Cleaners will determine a labor rate when a claim is made based on actual repair times by our own service technicians.
- Page 16 2. If the battery is deemed to be within the warranty period, Prolux Cleaners will arrange a date to inspect and replace (upon inspection approval) the battery with the OEM. 3. The OEM will pick-up and test/inspect the battery to determine the defect.
- Page 17 Freight damage is not covered under the Prolux Cleaners warranty policy. Replacement Parts: Prolux Cleaners will not honor any warranty claims for parts, labor, or travel if the replacement part was not purchased through Prolux Cleaners. Prolux cleaners reserves the right to review or modify the above document at any time without specific written or prior notice.
