21541-21542
21541 Parts List:
Item
Description
1
Ratcheting Rhino Grip
2
KXP Ratcheting Base
3
Kwik Clip
4
Nylon Washer
5
Rubber Expander*
6
Threaded Rod
Designed to hold guns, bows, fishing poles, shovels, etc.,
safely and securely while traversing on an ATV or UTV.
21541 Assembly:
1. Place the rubber expander on the threaded rod. Place
the nylon washer on top of the rubber expander and
thread the rod into the threaded insert in the bottom
of the base.
* NOTE: the rubber expander for both systems has a
counter-bored relief that mates to the threaded rod.
Please be sure to install correctly!
2. Place the expander in the Lock & Ride hole and twist
the base clockwise. As you twist the threaded rod will
compress the rubber expander and secure the grip to
your Sportsman ATV Rack.
3. Place the Rhino Grip into the base, orient the grip as
desired and secure with the Kwik Clip.
** NOTE: The Kwik Clip can only be inserted on one
side of the grip, the push button side. There is a note
on the grip also letting you know what side the clip
has to be used on. **
4. To remove from the rack, simply turn the base counter
clockwise and remove from the Sportsman Rack.
5. To clamp your tool, simply push the single arm down
on the tool. The arm will clamp down and hold item
secure.
6. To release, push the push button on the grip and the
arm will swing open to release the tool.
Kolpin now offers many accessory options for Polaris ATV and UTV models. For a complete listing of these KXP
accessories and Kolpin's KXP Plungers that are compatible with Polaris® Lock & Ride® System, be sure to check
out www.kolpinpowersports.com/products/kxp-accessories.html.com, as new items will be coming soon.
Kolpin Outdoors, Inc., 205 N. Depot Street, Fox Lake, WI Phone #: (877) 9KOLPIN or (920) 928-3118
Rev. 1
KXP Ratcheting Rhino Grip
Quantity
2
2
2
2
2
2
1
3
2
