NVMe PCI Express x16 Card
4 x internal M.2 Key M - Bifurcation
English
Description
This PCI Express card by Delock expands the PC by four M.2 slots. Up to four M.2
SSDs in format 2280, 2260, 2242 and 2230 can be connected. With the help of
the large heat sink sufficient cooling of the M.2 modules is guaranteed.
Specification
• Connectors:
internal:
4 x M.2 key M slot
1 x PCI Express x16, V4.0
• Interface: PCIe
• Supports M.2 modules in format 2280, 2260, 2242 and 2230 with key M or key
B+M based on PCIe
• Maximum height of the components on the module: 1.5 mm, application of
double-sided assembled modules supported
• Supports NVM Express (NVMe)
• 5 x LED indicator
• Bootable, ex UEFI version 2.3.1
• Supports S.M.A.R.T.
• Supports TRIM
• Dimensions heat sink (LxWxH): ca. 144 x 95 x 8 mm
System requirements
• Linux Kernel 5.19 or above
• Windows 10/10-64/11
• Windows Server 2019
• PC with one free PCI Express x16 / x32 slot
• Motherboard and BIOS with PCIe bifurcation support
Package content
• PCI Express card
• Heat sink
• Mounting material
• 4 x thermal conductive pad
• User manual
