- Page 1 L E A D E R T H E P A C K MANUFACTURER’S WARRANTY YEARS Laser Operations Guide...
-
Page 2: Table Of Contents
Introduction You now own the Pro Shot AlphaR, a high accuracy, servo leveled automatic laser for the most demanding leveling or grade checking operations. Please take a moment to read this manual. It contains vital information on safely operating and getting the best results from your new laser. -
Page 3: Case Contents
Getting Started Case Contents (will vary depending on package ordered) Getting Started Batteries Batteries Receiver Receiver Laser Operations Guide Battery Door Tab Instruction packet Battery Door Tab Laser Case Contents (will vary depending on package ordered) Battery Installation Battery Installation Pull on tab at base of door to remove. -
Page 4: Controls & Displays
Controls & Displays Alignment Sights X Axis Slope (Y) Axis Power & Low Battery Indicators Power Switch X Axis Leveling Rotation & Limit LEDs Speed Button & Indicator Y Axis Leveling & Limit LEDs Manual Slope Switch Y Axis Manual & Limit LEDs Manual Slope Battery Charging... -
Page 5: Laser Controls
Laser Controls • Alignment Sights are used to align the slope axis of the laser. • Power Switch turns the laser on and off. • X axis Leveling LEDs: green LED lights when unit is leveling, both red LEDs (X & Y axis) flash if a leveling limit is reached. •... -
Page 6: Safety
Warning Placards Safety Labels Note: The AlphaR is a CDRH class II laser and an IEC 60825 class 2 laser. It conforms to applicable EC directives regarding RFI and EMI, and to FDA performance standards 21 CFR subchapter J. -
Page 7: Initial Setup
The benchmarks should be 90º apart for greatest accuracy. Work as close to the laser as possible You can work up to 1000 feet (305M) from the AlphaR laser utilising the R10 receiver. As with all lasers and optical instruments, the farther you go, the more errors can add up. -
Page 8: Level Setup
Level Setup Level Setup Laser Power and Low Battery Laser Power and Rotation Speed Indicators Low Battery Indicators Rotation Speed Power Selector & Speed Power Selector & Speed Switch Switch Indicator Indicator X Axis Leveling X Axis Leveling (Green) & Limit (Green) &... -
Page 9: Slope Matching
Slope Matching Slope Matching Mode, Y axis manually adjusted, X axis auto levels • Use the sights on top of the laser to align it with the slope direction axis. • Press the power switch to turn the laser on. •... -
Page 10: Calibration
Calibration Calibration is your responsibility, check it often It is well worth the effort to check calibration before you first use your laser, and then periodically to ensure that you are doing the highest quality work. Always check calibration if the laser has been handled roughly. Follow the steps below to check the calibration of the laser and make adjustments if necessary. - Page 11 Rotate the laser 90 degrees so that either direction of the Y axis is aimed at the target. Allow the laser to re-level and make an elevation mark at the target. If the distance between this mark and the true level mark is within the laser’s accuracy specification, calibration is Calibration complete.
-
Page 12: R10 Receiver
R10 Receiver The R10 senses the plane of laser light projected by the Alpha transmitter and indicates a height position relative to the plane (high, low, or on grade). The R10 uses a five channel front and rear LCD display to convey elevation information. -
Page 13: Rechargeable Battery Kit
Rechargeable Battery Option The optional NiMH rechargeable battery kit is an environmentally friendly and economical alternative to alkaline batteries. NiMH batteries can be charged up to 500 times under optimum conditions and contain no hazardous materials. To use the NiMH batteries, install a set into the laser and charge them fully prior to initial use (12 hours). -
Page 14: Maintenance & Troubleshooting
Maintenance • Calibration: Calibration should be checked periodically or if the laser has been handled roughly or shipped. • Batteries: Occasionally remove the batteries and check the contacts for corrosion. Remove the batteries if the laser is to be stored for an extended period. -
Page 15: Warranty & Specifications
8 Year Warranty The Pro Shot AlphaR laser transmitter is warranted for eight years from the date of new equipment purchase from an authorised dealer. During the warranty period, Laser Reference or its authorised service center will repair or replace, at Laser Reference’s sole discretion, laser transmitters (except for transportation costs), if the product is found to be defective in workmanship or materials. - Page 16 CONTACT DETAILS AUCKLAND: ACCURATE CALIBRATION & SERVICE CENTRE 192 Marua Road, Mt Wellington, Auckland 1051. Ph: 09 579-1777 CHRISTCHURCH: ACCURATE CALIBRATION & SERVICE CENTRE 4 Avenger Crescent, Wigram, Christchurch 8042. Ph: 03 348-9898 Customer Information Laser Serial Number ............ Receiver Serial Number ..........Date of Purchase ............
