Current NK Lighting Controls NXSMP2 Series Installation Instructions

PRECAUTIONS
Read and understand all instructions before beginning installation.
CAUTION: FOR USE WITH CLASS 2, LOW VOLTAGE SYSTEMS ONLY. DO NOT USE IN HIGH VOLTAGE APPLICATIONS.
NOTICE: Class 2 Device, 12-24V, 10mA
NOTICE: Suitable for Use in Other Environmental Air Space (Plenums) in Accordance with Section 300.22 (c) of the National
Electrical Code.
NOTICE: For installation by a licensed electrician in accordance with National and/or Local Electrical Codes and the following
instructions.
Confirm device ratings are suitable for application prior to installation. Use of this device in applications beyond its specified ratings
other than its intended use may cause an unsafe condition and will void manufacturer's warranty.
Use only approved materials and components (i.e. wire nuts, electrical box, etc.) as appropriate for installation.
NOTICE: DO NOT INSTALL IF PRODUCT APPEARS TO BE DAMAGED.
NOTICE: Do not use this equipment for other than its intended use.
REGULATORY INFORMATION
1. Contains Transmitter Module FCC ID: YH9NXSMP2 IC: 9044A-NXSMP2
1. This device complies with FCC part 15 Rules. Operation is subject to the following two conditions: This device may not cause
harmful inference.
2. This device must accept any interference received, including interference that may cause undesired operation.
2. FCC Interference Statement (Part 15.105(b)): This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
3. FCC Part 15 Clause 15.21: Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
4. ISED RSS-Gen Notice
This device complies with Industry Canada's license-exempt RSSs. Operation is subject to the following two conditions:
1. The device may not cause interference; and
2. This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes:
1. l'appareil ne doit pas produire de brouillage;
2. l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
SAVE THESE INSTRUCTIONS AND PROVIDE TO OWNER AFTER INSTALLATION IS COMPLETED
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
24
currentlighting.com
© 2022 HLI Solutions, Inc. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
NXSMP2 Series Sensors
Indoor & Outdoor Sensors
OMNI INSTALLATION INSTRUCTIONS
NXSMP2-OMNI_install_sheet_R01
93147266 Rev. A
Page 1 of 4
Rev 08/01 /22
