- Page 1 Form No. 3326-909 52 Rear Discharge Mower Groundsmaster 200 Series Model No. 30568—Serial No. 220000001 and Up Operator’s Manual Domestic English (EN)
-
Page 2: Table Of Contents
....... Dealer or Toro Customer Service and have the model and serial numbers of your product ready. -
Page 3: Safety
Safety – Never remove fuel cap or add fuel with engine running. Allow engine to cool before refueling. Do not smoke. This machine meets or exceeds the B71.4 1999 – Never refuel or drain the machine indoors. specifications of the American National Standards Institute, in effect at time of production. -
Page 4: Toro Mower Safety
Hydraulic fluid escaping under pressure can have The following list contains safety information specific to sufficient force to penetrate the skin and cause serious Toro products or other safety information that you must injury. know that is not included in the ANSI standards. -
Page 5: Safety And Instruction Decals
If major repairs are ever needed or if the body away from the cutting units, attachments, and assistance is desired, contact an Authorized Toro any moving parts. Distributor. - Page 6 93-7818 1. Warning—read the operator’s manual for further information on torquing the blade bolt. 105–9551 1. Warning—read the operator’s manual. 2. Lower the cutting deck when going down slopes. GM 225 units need 25 kg (55 lb.) of rear weight. GM 228D and four-wheel drive units do not need any rear weight.
-
Page 7: Specifications
Specifications General Specifications Width of Cut 51-3/4 in. (1.314 m) Height of Cut Adjustable from 1 to 3-1/2 in. (25 to 89 mm) in 1/2 inch (13 mm) increments Blade Tip Speed 15,764 ft./min. @ 3300 engine RPM Cutting Blades 3 heat-treated steel blades, each 3/16 in. -
Page 8: Setup
Engine Shield Kit, Model 30578, is required when mounting a 52 Rear Discharge Cutting Unit, Model 30568, to a Model 30223, 30200, 30330, or 30243 Traction Unit. Order the kit from your Authorized Toro Distributor. Note: Determine the left and right sides of the machine from the normal operating position. -
Page 9: Installing The Lift Arms
Danger If the engine is started and the PTO shaft is allowed to rotate, serious injury could result. Do not start the engine and engage the PTO lever when the PTO shaft is not connected to the gear box on the cutting unit. Installing the Lift Arms Figure 3 1. -
Page 10: Installing The Carrier Frame
Installing the Carrier Frame Note: If the rear cradle mounting holes are not in the lift arms, use the dimensions shown in Figure 7 to locate, mark, and drill the 3 holes (13/32 in. diameter) required in each Note: Grease the castor wheel shaft with No. 2 grease after lift arm. -
Page 11: Installing The Weight Transfer Kit
3. Place blocks under the cutting deck to prevent it from falling during assembly. Note: The mounting brackets for the weight transfer kit must be installed in different locations depending on the cutting deck. Refer to Figure 10 for mounting location. Figure 8 1. - Page 12 7. Mount the bottom of the knee link to the deck bracket with a shoulder bolt and locknut. 8. Align the slotted holes in the spring cover (slot toward the bottom) with the mounting bracket holes. Insert the lock pin assemblies into the bracket holes and secure each to the bracket with self-tapping screws (Fig.
-
Page 13: Installing Rear Weight
Refer to the chart in the traction unit Operator’s Manual to determine the combinations of weight required. Order the parts from your local Authorized Toro Distributor. Four Wheel Drive Groundsmaster 200 Series traction units do not need additional rear weight to comply with the... -
Page 14: Checking The Lubricant In The Gear Box
Checking the Lubricant in the Operation Gear Box Note: Determine the left and right sides of the machine The gear box is designed to operate on SAE 80–90 wt. gear from the normal operating position. lube. Although the gear box is shipped with lubricant from the factory, check the level before operating the cutting Adjusting the Tension Spring unit. -
Page 15: Maintenance
Maintenance Note: Determine the left and right sides of the machine from the normal operating position. Greasing the Bearings and Bushings The cutting unit must be lubricated regularly. If the machine is operated under normal conditions, lubricate the castor bearings and bushings with No. 2 general purpose lithium base grease or molybdenum base grease after every 8 hours of operation or daily, whichever comes first. -
Page 16: Separating The Cutting Unit From The Traction Unit
Separating the Cutting Unit from the Traction Unit 1. Position the machine on a level surface, raise the cutting unit, engage the parking brake, put the traction pedal in neutral, the PTO lever in the Off position, shut the engine off, and remove the ignition key. Caution The counterbalance spring is in tension when the Figure 24... -
Page 17: Servicing The Castor Wheel And Bearing
4. Insert a pin punch into the top or bottom of the Servicing the Castor Wheel mounting tube and drive the bushing out of the tube and Bearing (Fig. 25). Also drive the other bushing out of the tube. Clean the inside of the mounting tube to remove any The castor wheel rotates on a high-quality roller bearing dirt. -
Page 18: Checking For A Bent Blade
The blade must be replaced if a solid object is hit, the blade Two areas must be considered when checking and servicing is out-of-balance, worn, or bent. Always use genuine Toro the cutting blade: the sail and the cutting edge. Both cutting... -
Page 19: Checking And Correcting Mismatch Of Blades
Inspect the blade periodically for wear or damage. Replace a worn or damaged blade with a new Toro blade to ensure continued safety Figure 31 certification of the product. 6. Note the measurement attained at “A”, rotate the blades SHARPEN AT THIS to the “B”... -
Page 20: Adjusting The Idler Pulley
8. Compare the measurements at various positions. All Adjusting the Idler Pulley dimensions must be equal within 1/4 in. (6 mm) from any 2 adjacent blades. The difference between the The idler pulley applies force against the belt so that power dimensions of all 3 blades must not exceed 3/8 in. -
Page 21: Replacing The Drive Belt
Replacing the Drive Belt The blade drive belt, tensioned by the adjustable idler, is very durable. However, after many hours of use, the belt will show signs of wear. Signs of a worn belt are: squealing when belt is rotating, blades slipping when cutting grass, frayed edges, burn marks, and cracks. -
Page 22: Troubleshooting
UNIT WILL NOT CUT OR CUTS POORLY INSPECT INSPECT INSPECT INSPECT INSPECT CUTTER SPINDLE CUTTER DECK GEAR BOX GEAR BOX BLADES BOLTS BELTS PULLEY SHAFTS DULL OR LOOSE OR BROKEN LOOSE LOOSE BENT BROKEN TIGHTEN SHARPEN RETORQUE TIGHTEN REPLACE 85 TO 110 REPLACE REPLACE FOOT POUNDS... -
Page 24: The Toro General Commercial Products Warranty
If for any reason you are dissatisfied with your Distributor’s service or have difficulty obtaining guarantee information, contact the Toro importer. If all other remedies fail, you may contact us at Toro Warranty Company.
