Draper LVC-IP Bridge Programming Instruction

LVC-IP Bridge - C156.329
Section 1 - Overview
The LVC-IP Bridge acts as an IP to Serial Gateway for controlling Draper lifts and screens when used in conjunction with an
LVC-IV or LVC-V.
IP A
IP B
Section 2 - Wiring
LVC-IP Bridge
Connection
to IP
Controller
Section 3 - Selecting LVC Model
By default, the device is set up for
1. Highlight LVC-V and press
2. Use to select LVC-IV.
3. Press to save selection.
Section 4 - IP Port Configuration
By default, the device is set up for
1. Highlight MODE and press
2. Use to select STATIC.
3. Press to save selection.
To alter IP configuration:
1. Highlight field to be modified and press
2. , configure the proper IP information for each field.
Use
3. to progress to the next # to be configured.
Press
to LVC-IV
or LVC-V
to 5V
Transformer
LVC-V. To change this:
.
DHCP. To change this:
.
.
To Device
5VDC
Input
USB-C
*Required only when
not connected to a
Powered Device
Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385
draperinc.com | 765.987.7999 | 800.238.7999
|
© 2024 All Rights Reserved
INSTRUCTION
PROGRAMMING
BACK
VIEW
FORM: C156.329_LVC_IP_Bridge_Inst24
