Toro 30477 Installation Instructions Manual

Right-Hand and Left-Hand Replacement Mower
Decks
2011 and After Groundsmaster
Model No. 30476—Serial No. 403300001 and Up
Model No. 30477—Serial No. 403300001 and Up
WARNING
CALIFORNIA
Proposition 65 Warning
Use of this product may cause exposure
to chemicals known to the State of
California to cause cancer, birth defects,
or other reproductive harm.
Safety
Safety and Instructional
Decals
Safety decals and instructions are
easily visible to the operator and are
located near any area of potential
danger.
© 2019—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
133-8061
Register at www.Toro.com.
® 4000-D Traction Unit
Installation
Removing the Hydraulic
Motor
1. Park the machine on a level surface, lower the
mower deck, engage the parking brake, shut off
the engine, and remove the key.
2. Ensure that the traction pedal is in the
position and the PTO lever is in the
3. Remove the bolts securing the hydraulic motor
to the deck
4. Lift the motor off the deck and lay it on a clean
surface out of the way.
Note:
aluminum coupler.
decal133-8061
1. Hydraulic motor
5. Remove the elastomeric spider from inside the
pulley coupler. Inspect it for wear and replace it
if it is worn. Otherwise, retain it to install on the
new deck
Note:
replace it if it is worn
Form No. 3434-423 Rev A
Installation Instructions
(Figure 1).
Ensure that you do not damage
Figure 1
2. Mounting bolts
(Figure 2).
Inspect the spider hub for wear and
(Figure 2).
Original Instructions (EN) All Rights Reserved *3434-423* A
Printed in the USA
NEUTRAL
position.
OFF
g011511
